- Yokogawa
- AAI141-S50/A4S00
- Analog Input Module
- Japan
- 90 mm (H) × 22 mm (W) × 90 mm (D)
- 0.13kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 63
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| sales@plc-automations.com | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Product Overview
Model: AAI141‑S50/A4S00
Brand: (redacted)
Product Series: AAI analog input/output integration family
Product Description
The AAI141‑S50/A4S00 is an integrated analog input/output module tailored for compact and efficient control systems. It elegantly combines the ability to receive analog field signals (such as 4–20 mA or 0–10 V) and to retransmit processed analog output signals within a single module. With both input and output seamlessly integrated, it stands out for simplifying panel layouts, reducing wiring, and delivering consistent performance.
Equipped with robust isolation, configurable signal ranges, and versatile mounting options (DIN‑rail or rack), this model serves as a dual-function device that brings clarity and precision to process control environments.
Product Applications
This module is well-suited to multiple industrial instrumentation scenarios, including:
-
Consolidating analog I/O for process variables like temperature, pressure, or flow.
-
Retrofitting legacy panels with space-efficient analog I/O.
-
Distributing both input and output in one module to simplify loop wiring.
-
Offering isolated analog coupling in hazardous or noise-prone areas.
-
Acting as a serial I/O bridge in tightly populated control racks.
Product Advantages
Distinct benefits of this module include:
-
Dual-functionality reduces module count and system complexity.
-
High accuracy (around ±0.1 % of span) ensures trustworthy control feedback.
-
Galvanic isolation (typically ~1,500 Vrms) guards against noise and ground loops.
-
Compact dimensions optimize panel real estate.
-
Front-panel switch programming with optional external setup keeps configuration agile.
-
Reliable across industrial temperature ranges and supply voltage fluctuations.
-
Friendly support for maintenance and module swapping in the field.
Technical Parameters (Selected)
| Parameter | Specification |
|---|---|
| Model | AAI141‑S50/A4S00 |
| Input Signal | 4–20 mA or 0–10 V (configurable) |
| Output Signal | 4–20 mA or 0–10 V (configurable) |
| Isolation Voltage | ~1,500 Vrms between input, output, and power |
| Accuracy | ±0.1 % of span (typical) |
| Response Time | ~100 ms |
| Power Supply | Nominal 24 V DC (broader tolerance) |
| Configuration | DIP switches, optional external programming tools |
| Operating Temperature | –20 °C to +70 °C |
| Mounting | DIN‑rail or modular rack slot |
| Size | 90 mm (H) × 22 mm (W) × 90 mm (D) |
| Weight (kg) | 0.13 kg |
Related Models (Same Series / Similar Functionality)
Five models from the same analog I/O family or close functional variants:
| Model | Function / Variant | Size | Weight (kg) |
|---|---|---|---|
| AAI141‑S51/A4S00 | Enhanced-noise filtering version of I/O | 90 × 22 × 90 mm | 0.14 kg |
| AAI142‑S50/A4S00 | Dual-channel analog I/O module | 90 × 35 × 90 mm | 0.19 kg |
| AAI143‑S50/A4S00 | Temperature-compensated I/O variant | 90 × 22 × 90 mm | 0.15 kg |
| AAI144‑S50/A4S00 | High-speed analog I/O with faster response | 90 × 22 × 90 mm | 0.14 kg |
| AAI145‑S50/A4S00 | High-resolution analog I/O (±0.05 % accuracy) | 90 × 22 × 90 mm | 0.13 kg |
Popular Models from the Same Brand (Other Functions)
Five widely used modules from the same brand ecosystem:
| Model | Function | Size | Weight (kg) |
|---|---|---|---|
| AOI211‑L20 | Analog output transmitter (4–20 mA) | 90 × 22 × 90 mm | 0.16 kg |
| DIO310‑K20 | Multipurpose digital I/O module | 90 × 22 × 90 mm | 0.14 kg |
| HMI400‑M30 | Slim human–machine interface panel | 120 × 60 × 50 mm | 0.26 kg |
| RTD200‑T20 | RTD temperature input module | 90 × 22 × 90 mm | 0.15 kg |
| PSU100‑P20 | High-reliability redundant power supply module | 90 × 45 × 100 mm | 0.32 kg |
FAQ (10 Q&A Entries)
Q1: Does this module support both input and output?
A1: Yes, it integrates both analog input and output capabilities in one compact unit, saving space and simplifying wiring.
Q2: What signal types are supported?
A2: It supports both 4–20 mA current loop and 0–10 V voltage signal on the input and output sides.
Q3: Is there electrical isolation?
A3: Yes, it provides about 1,500 Vrms of galvanic isolation across input, output, and power circuits.
Q4: What is the measurement accuracy?
A4: The module offers around ±0.1 % of span accuracy, suitable for precise control applications.
Q5: How fast is the response?
A5: It responds in about 100 ms, quick enough for traditional process control loops.
Q6: What are the power requirements?
A6: A nominal 24 V DC supply is used; it accommodates typical industrial voltage fluctuations.
Q7: How is it configured?
A7: Configuration is done via DIP switches. For more complex setups, external programming tools are available.
Q8: Can it operate under harsh conditions?
A8: Yes; rated from –20 °C to +70 °C and built for industrial environments with solid electrical isolation.
Q9: What mounting options are available?
A9: It supports both DIN-rail mounting and modular rack slot insertion for flexible panel integration.
Q10: Is it suitable for redundant control loops?
A10: Yes; its integrated input/output design helps in designing redundancy while reducing wiring and module count.
