Product Overview
The Schneider VW3A1112 Door Mounting Kit is a mounting accessory for installing a compatible Altivar operator terminal or interface through an electrical cabinet or control-panel door.
It is particularly useful where the Altivar drive remains inside the enclosure but the operator needs access to the display or control interface from the front of the panel. The mounting arrangement separates the operator-access function from the physical location of the drive, which can make the overall control panel easier to operate.
In retrofit work, the VW3A1112 can also be used when an existing Altivar installation needs its operator interface repositioned to a more accessible location.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Model | VW3A1112 |
| Product Family | Altivar |
| Product Type | Door Mounting Kit |
| Primary Function | Operator Terminal Door Mounting |
| System Role | Mechanical Mounting Accessory |
| Application | Altivar Drive Control Panels |
| Installation | Electrical Cabinet / Control Panel Door |
| Dimensions | 120 × 55 × 100 mm |
| Weight | 0.068 kg |
Product Features
- Schneider Electric Altivar Door Mounting Kit
- Model VW3A1112
- Intended for panel-door mounting arrangements
- Supports accessible operator-interface installation
- Suitable for Altivar control cabinets
- Allows the drive to remain inside the enclosure
- Useful for front-panel operator access
- Suitable for machine-control panels
- Applicable to retrofit and maintenance projects
- Compact mounting accessory
Working Principle
The VW3A1112 provides the mechanical interface needed to position a compatible operator terminal at the front of a control-panel or enclosure door.
Operator Terminal → VW3A1112 → Control Panel Door → Altivar Drive
The kit itself does not process control signals or communicate with the drive. Its function is to secure and position the associated terminal so that the operator can access the interface from the outside of the enclosure.
Once installed, the operator can interact with the terminal while the Altivar drive and other electrical components remain housed within the cabinet.
Role in an Altivar Control System
| System Element | Function |
|---|---|
| VW3A1112 | Provides door mounting for the operator interface |
| Operator Terminal | Displays and controls applicable drive functions |
| Altivar Drive | Controls motor operation |
| Control Cabinet | Houses electrical equipment |
| Communication Connection | Links the terminal with the drive |
| Electric Motor | Converts electrical power into mechanical output |
| Machine / Process | Uses the motor-driven equipment |
The VW3A1112 belongs to the mechanical installation portion of the operator-interface arrangement rather than the drive-control electronics.
Industrial Applications
| Application | Typical Use |
|---|---|
| Motor Control Panels | Front-panel terminal mounting |
| Machine Automation | Operator-interface installation |
| Conveyor Systems | Accessible drive interface |
| Pumping Equipment | Cabinet-door operator access |
| HVAC Control Panels | Drive interface mounting |
| Material Handling | Remote operator access |
| Process Machinery | Panel-mounted drive interface |
| Industrial Automation | Control-panel modification |
Installation and Maintenance
- Confirm the VW3A1112 model before installation.
- Verify compatibility with the intended Altivar operator interface.
- Check the control-panel door and mounting location.
- Confirm the required panel opening.
- Position the mounting kit correctly.
- Secure the mounting hardware.
- Install the associated terminal according to the applicable arrangement.
- Check that the terminal sits firmly in the panel.
- Inspect mounting points during routine maintenance.
- Check for looseness caused by repeated door movement.
- Inspect the terminal and surrounding panel for mechanical damage.
- Verify terminal operation after installation.
- Check the associated communication connection where applicable.
If the operator terminal moves excessively or does not remain securely positioned, inspect the mounting arrangement before investigating the electrical system.
Related Components
| Component | Function |
|---|---|
| Schneider Electric VW3A1112 | Door Mounting Kit |
| VW3A1111 | Altivar Graphic Display Terminal |
| VW3A1101 | Altivar Remote Graphic Terminal |
| VW3A1006 | Altivar Remote Terminal |
| VW3A1007 | Altivar Remote Terminal |
| Altivar Drive | Variable speed motor control |
| Control Cabinet | Houses drive equipment |
| Communication Cable | Connects applicable interface components |
Recommended Related Models
| Model / Product Family | Product Type | Typical Application |
|---|---|---|
| Schneider Electric VW3A1112 | Door Mounting Kit | Operator terminal door mounting |
| Schneider Electric VW3A1111 | Altivar Graphic Display Terminal | Drive monitoring and operation |
| Schneider Electric VW3A1101 | Altivar Remote Graphic Terminal | Remote drive configuration |
| Schneider Electric VW3A1006 | Altivar Remote Terminal | Remote drive operation |
| Schneider Electric VW3A1007 | Altivar Remote Terminal | Remote drive operation |
| Schneider Electric VW3A1102 | Altivar Variable Speed Door Mounting Kit | Remote terminal installation |
| Schneider Electric ATV61 | Altivar Variable Speed Drive | Industrial motor control |
| Schneider Electric ATV71 | Altivar Variable Speed Drive | High-performance motor control |
Key Advantages
- Altivar Door Mounting Kit
- Model VW3A1112
- Supports front-panel operator-interface installation
- Suitable for electrical cabinet doors
- Keeps the drive inside the enclosure
- Provides convenient operator access
- Useful for machine and process control panels
- Suitable for retrofit and maintenance applications
- Compact mechanical accessory
Technical FAQs
What is the VW3A1112 used for in an Altivar installation?
The VW3A1112 is used to mount a compatible Altivar operator interface through a control-panel or electrical enclosure door, allowing the interface to remain accessible from the front of the panel.
Does the VW3A1112 provide electrical communication with the drive?
No. The VW3A1112 is a mechanical mounting accessory. Any required electrical or communication connection between the operator terminal and Altivar drive is handled separately.
What is the benefit of mounting the operator interface on the cabinet door?
Door mounting allows operators and maintenance personnel to access the drive interface without opening the electrical enclosure, which is useful for equipment requiring frequent status checks or parameter access.
What mechanical checks are useful after installation?
Check that the mounting hardware is secure, the terminal is firmly seated, and repeated cabinet-door movement has not caused looseness or mechanical stress around the mounting area.
