Technical Specification and Product Overview – Schneider 140XBP00600
1. Product Identification
Model: 140XBP00600
Product Type: High-Speed Backplane Connector Module
Category: Modular PLC System Interconnection Hardware
2. Product Introduction
The 140XBP00600 is a high-speed backplane connector module designed for modular PLC (Programmable Logic Controller) systems that demand enhanced signal transmission and rapid data communication between multiple racks. Unlike standard backplane connectors, this module is optimized to handle higher data throughput and lower latency, making it ideal for automation systems with intensive control requirements or high I/O densities.
The module acts as an interconnection backbone between PLC racks, ensuring that all signals and power lines are transmitted with minimal interference. Its design accommodates industrial conditions, offering robust protection against vibration, electrical noise, and temperature fluctuations. By providing high-speed bus connectivity, the 140XBP00600 allows integrators to implement complex control architectures, including distributed and redundant PLC configurations, without sacrificing performance.
With easy rack-mounted installation, this module simplifies system expansion, reduces wiring complexity, and ensures precise alignment for reliable connectivity. It is particularly suited for applications where timing and communication speed are critical, such as motion control systems, real-time monitoring, and high-speed manufacturing lines.
3. Brand and Series Information
Brand: Schneider
Renowned for industrial automation and control solutions, the brand provides scalable and reliable PLC components and system accessories suitable for both discrete manufacturing and continuous process industries.
Series: Modular PLC Backplane & Connector Series
This series focuses on modular PLC connectivity components, including single and redundant backplane connectors, high-speed connectors, bridge modules, and power distribution modules, all designed to ensure flexible, reliable, and scalable automation architectures.
4. Product Specifications
| Parameter | Details |
|---|---|
| Model | 140XBP00600 |
| Module Type | High-Speed Backplane Connector |
| Function | Enhances signal and data throughput between PLC racks |
| Bus Architecture | 32-bit high-speed extension bus |
| Slots Supported | Connects up to 2 PLC racks |
| Signal Integrity | Shielded connectors for minimal interference |
| Voltage Rating | 5 V / 24 V system support |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity Range | 5%–95% non-condensing |
| Mounting Type | Rack-mounted connector |
| Dimensions (H × W × D) | 130 × 50 × 160 mm |
| Weight (kg) | 1.25 kg |
| Electrical Interface | Backplane high-speed connectors |
| Environmental Rating | Industrial grade |
| Isolation | Bus isolation from chassis ground |
5. Product Applications
The 140XBP00600 is widely used in industrial automation setups that require high-speed data transfer, precise control, and modular expandability. Key applications include:
High-Speed Manufacturing Lines: Suitable for automated production lines requiring rapid signal processing and low latency communication.
Motion Control Systems: Supports applications where precise timing and synchronization across multiple PLC racks are essential.
Distributed PLC Systems: Allows multiple racks to communicate efficiently in complex automation architectures.
Redundant Configurations: Can be combined with redundant modules to maintain continuity during maintenance or fault conditions.
Process Control Systems: Enhances signal integrity for high-density analog and digital I/O modules in process automation.
6. Product Advantages
High-Speed Performance: Optimized for low-latency and high-bandwidth interconnections.
Reliable Connectivity: Shielded connectors ensure minimal signal degradation.
Industrial Robustness: Built for extreme temperatures, vibration, and electrical noise conditions.
Modular and Expandable: Simplifies the addition of PLC racks without re-wiring.
Ease of Installation: Rack-mounted design allows straightforward integration and maintenance.
Reduced Downtime: Supports redundant or backup pathways to maintain system operation.
7. Related or Same Series Models
| Model | Module Type | Function | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| 140XBP00600 | High-Speed Backplane Connector | High-speed bus interconnection | 130 × 50 × 160 | 1.25 |
| 140XBP00200 | Backplane Connector | Standard rack interconnection | 130 × 50 × 150 | 1.20 |
| 140XBP00300 | Redundant Backplane Connector | Dual bus redundancy | 130 × 60 × 150 | 1.35 |
| 140XBP00400 | Multi-Rack Bus Connector | Multi-rack expansion | 130 × 70 × 150 | 1.50 |
| 140XBP00500 | Backplane Bridge Module | Connects disparate racks | 130 × 80 × 150 | 1.60 |
| 140XBP00700 | Power & Backplane Distribution | Bus + power distribution | 130 × 90 × 160 | 1.75 |
8. Popular Models – Same Brand
| Model | Product Type | Primary Function | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| 140CPU65150 | PLC Processor | Central logic control | 130 × 80 × 170 | 1.20 |
| 140NRP95400 | Remote I/O Processor | Distributed control | 130 × 80 × 170 | 1.15 |
| 140NWM050000 | Ethernet Communication Module | Network interface | 130 × 35 × 150 | 0.72 |
| 140DDI35300 | Digital Input Module | Discrete input signals | 130 × 35 × 150 | 0.57 |
| 140ACI04000 | Analogue Input Module | Signal acquisition | 130 × 35 × 150 | 0.58 |
9. Frequently Asked Questions (FAQ)
Q1: What is the main purpose of the 140XBP00600?
A1: It provides high-speed interconnection between PLC racks, improving signal throughput and reducing latency.
Q2: How many racks can it connect?
A2: It supports interconnection of up to 2 PLC racks.
Q3: What is the weight of the module?
A3: The module weighs 1.25 kg.
Q4: What are the physical dimensions?
A4: Dimensions are 130 × 50 × 160 mm.
Q5: Can it operate in harsh industrial environments?
A5: Yes, it is designed for industrial temperatures, vibration, and electrical noise conditions.
Q6: What type of bus architecture does it support?
A6: It supports a 32-bit high-speed backplane bus.
Q7: Is it compatible with redundant PLC configurations?
A7: Yes, it can be used alongside redundant modules to ensure continuous operation.
Q8: How does it affect signal integrity?
A8: Shielded connectors preserve signal quality, minimizing interference.
Q9: Is installation complex?
A9: No, it is a rack-mounted design for easy integration and maintenance.
Q10: Can it be used in high-density I/O systems?
A10: Yes, it is suitable for systems with high I/O density that require fast, reliable communication.
