Product Overview
The GE IC693ACC305 IC Chips are EEPROM memory modules designed for the GE Series 90-30 PLC system. These chips are used to store and retain program data, enabling PLC systems to maintain logic integrity even without continuous battery backup.
This module is commonly installed in the CPU or backplane “PROGRAM PROM” socket, where it supports program storage, duplication, and recovery functions in industrial automation systems.
It is widely used in maintenance, commissioning, and system backup applications where secure and non-volatile program storage is required.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE |
| Model | IC693ACC305 |
| Product Type | EEPROM IC Chips |
| System Compatibility | GE Series 90-30 PLC |
| Memory Type | EEPROM (Electrically Erasable Programmable Read-Only Memory) |
| Quantity | Set of 4 chips |
| Function | Program storage & backup memory |
| Installation Location | CPU module / PROGRAM PROM socket |
| Memory Capacity | 28C256 class EEPROM architecture |
| Read/Write Capability | Yes (reprogrammable memory) |
| Data Retention | Non-volatile (no battery required) |
| Programming Method | Hand-held programmer / PLC programming tool |
| Operating Voltage | Low-voltage logic level (system dependent) |
| Dimensions | 45 × 25 × 5 mm |
| Weight | 0.02 kg |
| Operating Environment | Industrial control cabinet use |
| Temperature Range | 0°C to 60°C |
Function and Working Principle
The IC693ACC305 operates as a non-volatile memory storage unit within GE PLC systems.
Its working principle includes:
- Storing PLC program logic in EEPROM memory cells
- Retaining data even when system power is removed
- Allowing read/write operations for program updates
- Serving as backup memory for CPU RAM-based programs
- Enabling duplication of control logic across multiple systems
Once a program is developed in PLC RAM, it can be transferred into these EEPROM chips for permanent storage and system recovery purposes.
Role in Industrial Control Systems
Within GE Series 90-30 architectures, the IC693ACC305 plays a critical support role:
- Provides permanent program storage for PLC systems
- Eliminates dependency on battery-backed RAM alone
- Enables quick system recovery after power loss
- Supports duplication of control programs across machines
- Enhances system reliability and data integrity
It is essential in environments where downtime or data loss is unacceptable.
Industrial Applications
The GE IC693ACC305 is commonly used in:
- PLC program backup and recovery systems
- Factory automation control systems
- Industrial machine logic storage
- Power plant control systems
- Oil & gas automation systems
- Process manufacturing systems
- System commissioning and configuration backup
Installation and System Integration
Recommended installation practices include:
- Installing into PROGRAM PROM socket on CPU or backplane
- Ensuring correct polarity alignment before insertion
- Handling with electrostatic discharge protection
- Powering down system before installation or removal
- Using compatible GE Series 90-30 programming tools
Proper installation ensures stable memory operation and avoids data corruption.
Compatible System Components
The IC693ACC305 typically works with:
- GE Series 90-30 CPU modules
- Hand-held programmers (HHP)
- PLC backplane systems
- RAM memory modules
- EPROM / EEPROM programming tools
- Industrial control power supply systems
Together, these components support full PLC program lifecycle management.
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| IC693ACC305 | EEPROM IC Chips | Standard program memory backup | PLC data storage |
| IC693ACC306 | EPROM Chips | UV EPROM storage version | Legacy systems |
| IC693ACC301 | Battery Module | RAM backup power supply | Memory retention support |
| IC693ACC300 | Input Simulator | Signal simulation module | Testing & commissioning |
| IC693CPU364 | PLC CPU Module | Central processing unit | Control execution system |
Key Advantages
- Non-volatile memory ensures data retention without battery
- Supports secure PLC program backup and duplication
- Easy integration into GE Series 90-30 systems
- Enhances system reliability and recovery capability
- Suitable for industrial-grade continuous operation
- Compact and lightweight IC design
Technical FAQs
What is the main function of IC693ACC305?
It stores PLC program data in EEPROM memory for backup and retention.
Does it require battery support?
No, EEPROM memory retains data without battery power.
Where is it installed?
It is installed in the PROGRAM PROM socket of GE Series 90-30 CPU systems.
Can it be reprogrammed?
Yes, it supports read/write operations using programming tools.
Conclusion
The GE IC693ACC305 IC Chips are essential EEPROM memory components used in GE Series 90-30 PLC systems for secure program storage and backup. They ensure reliable data retention, simplify system recovery, and improve overall automation system stability.
For industrial engineers and system integrators, this module provides a dependable solution for safeguarding PLC programs and maintaining long-term operational integrity.
