Basic Information
-
Brand: GE
-
Series: Mark VIe / I/O Pack Modules
-
Model: IS220PTCCH1A
-
Product Type: Thermocouple Input Pack / Terminal Board Interface Module
Technical Specifications
| Parameter | Description |
|---|---|
| Model | IS220PTCCH1A |
| Brand | GE |
| Series | Mark VIe |
| Product Type | Thermocouple Input Pack (interface between I/O network & terminal board) |
| Number of Channels | Up to 12 thermocouple inputs per pack |
| Thermocouple Types | Types E, J, K, S (multi-type support) |
| Input Range | –8 mV to +45 mV typical |
| A/D Converter | 16-bit resolution |
| Dimensions | Approx. 82 × 122 × 60 mm |
| Weight | Approx. 0.36 kg |
| Operating Temperature | –30 °C to +65 °C |
| Communication Ports | Dual Ethernet ports (10/100 Mbps) |
| Mounting / Interface | Terminal board mount; DC‑37 connector; Ethernet RJ‑45 ports |
Product Description
The IS220PTCCH1A is a high-precision thermocouple input module designed for integration into Mark VIe I/O systems. It converts thermocouple sensor signals to digital data, feeding critical temperature information into control networks. With support for multiple thermocouple types (E, J, K, S), the module allows monitoring of turbines, industrial processes, and other high-temperature systems. Its compact design and dual Ethernet ports make it reliable for both new installations and system upgrades.
It is installed on terminal boards in control racks and communicates temperature data to the Mark VIe distributed I/O network. Onboard 16-bit ADC ensures accuracy, while diagnostic LEDs and monitoring ports simplify maintenance.
Applications
-
Temperature monitoring in gas/steam turbine plants.
-
High-precision temperature acquisition in industrial processes.
-
Integration with Mark VIe distributed I/O racks.
-
Retrofit or spare modules for existing control systems.
-
Dual-network critical monitoring systems for high reliability.
Advantages
-
High-precision thermocouple acquisition with 16-bit ADC.
-
Up to 12 channels per pack, reducing module count.
-
Dual Ethernet ports for network redundancy.
-
Compact and lightweight (~0.36 kg).
-
Industrial-grade operation: –30 °C to +65 °C.
-
Modular design simplifies maintenance and replacement.
-
Status LEDs and diagnostic ports for easy monitoring.
-
Seamless integration with turbine or process control systems.
Recommended Related Models
| Model | Description | Key Specifications (Dimensions / Weight) |
|---|---|---|
| IS220PTCCH1A | Thermocouple input pack (current product) | 82×122×60 mm / 0.36 kg |
| IS220PRTDH1A | RTD input pack | 82×122×65 mm / 0.5 kg |
| IS220PAICH1A | Analog input/output pack | 100×120×70 mm / 0.6 kg |
| IS220PCLAH1A | Core analog I/O pack | 110×130×80 mm / 1.0 kg |
| IS220PTURH1A | Turbine protection I/O pack | 100×140×70 mm / 0.8 kg |
Popular Models from the Same Brand
| Model | Description | Key Specifications (Dimensions / Weight) |
|---|---|---|
| IS215WEPAH2AB | Turbine pitch control module | 200×150×50 mm / 1.2 kg |
| IS200AEPAH1ACB | Control system power/interface module | 100×150×50 mm / 0.8 kg |
| IS215PMVPH1AA | Control processor/logic board | 330×100×200 mm / 2.0 kg |
| IS215VCMH2B | Communication/monitoring module | 258×160×40 mm / 1.9 kg |
| IS215REBFH1BA | Relay-output control board/I/O pack | 335×175×35 mm / 0.56 kg |
FAQ (Q&A)
Q1: What is the primary function of IS220PTCCH1A?
A1: Acquire thermocouple signals and convert them to digital data for the Mark VIe system.
Q2: Which series does it belong to?
A2: Mark VIe I/O Pack series.
Q3: What are the dimensions and weight?
A3: 82×122×60 mm; approx. 0.36 kg.
Q4: How many thermocouples can it handle?
A4: Up to 12 channels per pack.
Q5: Which thermocouple types are supported?
A5: Types E, J, K, S.
Q6: What is the operating temperature range?
A6: –30 °C to +65 °C.
Q7: Does it support redundant networks?
A7: Yes, dual Ethernet ports provide redundancy.
Q8: Can it be used as a spare module?
A8: Yes, it is compatible with existing Mark VIe racks.
Q9: Are there diagnostic features?
A9: Yes, it has status LEDs and a diagnostic port.
Q10: What should be verified before purchase?
A10: Ensure terminal board compatibility, correct revision, ambient conditions, and network/power requirements.
