Product Introduction
The IS220PPROS1B is a dedicated Emergency Turbine Protection I/O Pack module designed for high‑availability control systems in turbine and power‑generation applications. It is part of the IS220 family of modular I/O packs used in the Mark VI/Mark VIe system architecture.
It functions as a backup trip logic interface, interfacing into turbine emergency trip boards (e.g., TREG, TREL, TRES, TREA) and providing redundant monitoring of overspeed, deceleration fault, generator synchronisation and other critical protection signals. In a typical triple‑modular redundant (TMR) protection configuration, three IS220PPROS1B modules form a robust backup path independent of the main control module.
The design emphasises fast response, high reliability, redundant communications, rugged industrial operation, and seamless integration into existing I/O racks—making it suitable for mission‑critical turbine installations.
Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | Emergency Turbine Protection I/O Pack |
| Primary Function | Backup trip logic, overspeed protection, turbine synchronisation |
| Supply Voltage | Nominal ~28 V DC (with variants ~24 V DC) |
| Number of Ethernet Ports | 2 RJ‑45 ports (10/100 Mbps) for network redundancy |
| Typical Channels | Relay output channels (e.g., 12 outputs) and speed logic inputs |
| Operating Temperature | Approx. –30 °C to +65 °C (some listings –20 °C to +70 °C) |
| Storage Temperature | Approx. –40 °C to +85 °C |
| Dimensions | Approx. 143 mm × 231 mm × ? mm (varied listings) |
| Weight (kg) | Approx. 0.45 kg to ~1.1 kg (depending revision) |
| Mounting | Plug‑in module for I/O rack or direct to trip terminal board |
| Redundancy Support | TMR (Triple Modular Redundant) configuration compatible |
| Certifications | Hazardous‑area approved (e.g., Zone 2, Group IIC) in some variants |
Note: Size and weight figures vary by revision and configuration; values shown are typical approximations.
Applications
The IS220PPROS1B module is used extensively in the following environments:
-
Gas & Steam Turbine Systems: Employed as the backup trip I/O pack interfacing to emergency trip boards, monitoring overspeed sensors, deceleration faults and generating trip signals independent of the main controller.
-
Power Generation Plants: Integrated into turbine‑control cabinets where reliability and redundancy are paramount, managing critical protection logic that must operate even when the main control system fails.
-
Oil & Gas Platforms and Offshore Installations: Placed in harsh, demanding environments where stand‑alone protection logic is required for continuous operation, often in explosion‑risk zones.
-
Industrial Process Plants: In systems requiring fail‑safe, redundant I/O packs for safety or protection roles (e.g., large compressors, generators, spinning masses) where the module acts as a safety interface.
-
Retrofit / Upgrade Projects: Where legacy turbine protection modules are replaced by modern packs compatible with Mark VI/Mark VIe rack architecture, enabling improved diagnostics and maintainability without full system redesign.
Advantages
When selecting the IS220PPROS1B module, the benefits include:
-
Dedicated protection‑grade interface: Designed specifically for turbine emergency trip logic rather than generic I/O, ensuring optimized response and reliability.
-
High redundancy architecture support: Compatible with TMR configurations so the system remains operational even if one or two modules fail.
-
Dual‑Ethernet communication paths: Network fault tolerance with automatic fallback ensures trip logic continues uninterrupted.
-
Compact, serviceable design: With modest weight (~0.45 kg to ~1.1 kg) and plug‑in form factor, the module is easy to install or replace in dense control cabinets.
-
Wide industrial environmental tolerance: Designed to operate in ambient conditions from –30 °C (or –20 °C) up to +65 °C (or +70 °C) with storage up to +85 °C.
-
System ecosystem integration: Fully compatible with IS220 family racks and turbine control boards, enabling seamless upgrades and reducing risk.
-
Improved diagnostics and maintainability: Enhanced self‑test, LED indicators, and standardized installation reduce troubleshooting time and maintenance cost.
Brand and Series
-
Brand: GE Fanuc
-
Series: IS220 I/O Pack Series (Mark VI / Mark VIe architecture)
-
Category: Emergency Turbine Protection / Backup Trip I/O Pack
The IS220 series covers multiple pack types including analog I/O, discrete I/O, communication modules, servo/valve output packs and turbine‐specific protection modules such as this one. The “PPROS” designation indicates a Protection/Relay Output System pack for emergency trip logic.
Related Models – Same Series or Compatible
Here are five other models in the IS220 family (or closely compatible) with brief descriptions and approximate size/weight.
| Model | Function Description | Approx. Size / Weight |
|---|---|---|
| IS220PTURH1A | Primary Turbine I/O Pack – speed/protection input module | ~165 mm × 100 mm × 35 mm ; ~0.68 kg |
| IS220PPDAH1B | Power Distribution / Feedback I/O Pack | ~160 mm × 160 mm × 120 mm ; ~1 kg |
| IS220PAICH2A | Analog Input/Output Pack – high‐density analog I/O | ~170 mm × 100 mm × 35 mm ; ~0.72 kg |
| IS220PSVOH1A | Servo Valve Output Pack – analog/PWM output for valves | ~224 mm × 89 mm × 100 mm ; ~0.45 kg |
| IS220PSCAH1A | Serial Communication I/O Pack – RS‑232/422/485 devices | ~292 mm × 130 mm × 27 mm ; ~0.36 kg |
Popular Models – Same Brand
Here are five widely used modules from the GE Fanuc IS220 series which many integrators and plants have in use:
| Model | Function Description | Approx. Size / Weight |
|---|---|---|
| IS220UCSAH1A | Controller Pack – main CPU module for Mark VIe systems | ~233 mm × 177 mm × 44 mm ; ~2.27 kg |
| IS220PAOCH1B | Analog Output Pack – precision analog output module | ~132 mm × 94 mm × 35 mm ; ~0.20 kg |
| IS220PAICH1A | Analog Input/Output Pack – earlier generation analog I/O | ~150 mm × 100 mm × 50 mm ; ~0.70 kg |
| IS220PCLAH1B | Power/Control Distribution Module – rack DC power unit | ~227 mm × 175 mm × 88 mm ; ~1.30 kg |
| IS220PPRFH1A | PROFIBUS Gateway Pack – integrates PROFIBUS field devices | ~263 mm × 58 mm × 28 mm ; ~0.43 kg |
FAQ (10 Questions & Answers)
Q1: What is the primary role of the IS220PPROS1B?
A1: It serves as a backup turbine protection I/O pack, providing independent trip logic, overspeed and synchronisation protection for turbines.
Q2: What supply voltage does the module require?
A2: Typically about 28 V DC (some variants ~24 V DC) for the module’s internal circuits.
Q3: What are its typical dimensions and weight?
A3: Dimensions vary by revision, but approximately 143–231 mm in length, and weight around 0.45 kg to ~1.1 kg.
Q4: What operating temperature range does it support?
A4: Designed for industrial use from roughly –30 °C up to +65 °C or +70 °C, with storage capability to +85 °C.
Q5: Is the module compatible with redundancy architectures?
A5: Yes — it supports dual network ports and is used in TMR (triple modular redundant) protection configurations.
Q6: Which applications is this module used for?
A6: Gas or steam turbines, power‑generation control systems, oil & gas platforms, industrial plants requiring independent emergency trip logic.
Q7: What is the difference between this and a generic I/O pack?
A7: This module is purpose‑built for turbine trip protection, with independent logic, redundancy, and integration to turbine trip boards rather than general I/O tasks.
Q8: Does it support hazardous locations?
A8: Yes — some variants of the module have certification for hazardous zones (e.g., Zone 2, Group IIC) as required in turbine/control environments.
Q9: How does network redundancy work in this pack?
A9: It features two Ethernet ports; if one network path fails, the other remains active, maintaining I/O availability for trip logic.
Q10: What are the maintenance benefits of this module?
A10: Plug‑in design allows quick module swaps, built‑in diagnostics and LED indicators help identify faults, and its compatibility with the IS220 rack system ensures ease of replacement.
