Product Overview
In GE Mark V turbine control systems, stable and reliable power distribution is essential for maintaining the operation of processors, I/O hardware, communication circuits, and other control-system components. The GE DS200UPSAG1AGD MARK V Power Board is a dedicated power-related board designed for use within this industrial control architecture.
The DS200UPSAG1AGD belongs to the GE DS200 family and is identified as a Mark V Power Board. Its primary role is associated with power distribution, conditioning, and electrical support for connected control-system circuitry.
Unlike a processor board, the DS200UPSAG1AGD is not primarily responsible for executing turbine-control logic. It instead provides an important electrical infrastructure function that allows associated Mark V hardware to receive the required power.
The board can operate as part of a larger Mark V cabinet together with control processors, I/O boards, communication modules, terminal boards, and other power-related components.
The specified dimensions of the DS200UPSAG1AGD are 200 × 150 × 25 mm, with a specified weight of 0.93 kg.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE |
| Model | DS200UPSAG1AGD |
| Product Series | Mark V DS200 |
| Product Type | Power Board |
| Functional Family | UPSA |
| Main Function | Control-system power support |
| System Architecture | GE Mark V |
| Application | Turbine control and industrial automation |
| Board Function | Power distribution / conditioning |
| Board Type | Industrial power PCB |
| Dimensions | 200 × 150 × 25 mm |
| Weight | 0.93 kg |
| Installation | Mark V control cabinet |
| Typical Equipment | Gas turbines, steam turbines and power-generation systems |
| System Role | Power interface and support |
| Operating Environment | Industrial control environment |
Function and Working Principle
The main function of the DS200UPSAG1AGD is to provide power-related support within the Mark V control architecture.
A turbine control system contains numerous electronic circuits that require stable electrical power. Processor boards, I/O modules, communication interfaces, and other control hardware depend on appropriate power distribution to operate correctly.
The general power relationship can be represented as:
System Power Source → DS200UPSAG1AGD → Mark V Control Circuits → Processor / I/O / Communication Hardware
The board participates in the electrical power path and helps provide the required power interface for associated circuitry.
Depending on the system configuration, power-related functions can support:
- Control processors
- I/O engines
- Communication hardware
- Digital I/O modules
- Analog I/O modules
- Interface boards
- Control cabinet circuitry
- Auxiliary control equipment
A power-board failure can therefore have effects beyond the board itself. Loss of a required supply can cause downstream control hardware to shut down, reset, generate diagnostic alarms, or lose communication.
For this reason, power-related troubleshooting should consider the complete electrical path rather than examining the board in isolation.
Role in Industrial Control Systems
The DS200UPSAG1AGD plays a supporting role in the power architecture of GE Mark V turbine control systems.
The Mark V architecture contains multiple specialized hardware groups. CPU boards process control algorithms, I/O boards acquire and generate field signals, communication boards exchange information, and power boards provide the electrical infrastructure required by these components.
The DS200UPSAG1AGD belongs to the power-support portion of this architecture.
It can work alongside:
- Mark V control processors
- I/O engine CPU boards
- Digital I/O boards
- Analog I/O boards
- LAN communication hardware
- Terminal boards
- Power input boards
- Auxiliary power circuits
- Control cabinet distribution hardware
Its role is especially important in legacy turbine systems where the original power architecture must remain compatible with the existing control hardware.
Industrial Applications
The GE DS200UPSAG1AGD is primarily associated with GE Mark V turbine automation systems.
Typical applications include:
- Gas turbine control
- Steam turbine control
- Combined-cycle power plants
- Turbine generator systems
- Industrial turbine packages
- Mechanical-drive turbines
- Compressor-drive turbine systems
- Power-generation automation
- Turbine control cabinets
- Legacy GE Speedtronic installations
In these environments, reliable power distribution is necessary for maintaining stable operation of the complete control system.
The DS200UPSAG1AGD can therefore serve as an important supporting component in systems where multiple Mark V boards depend on the same power architecture.
Installation and System Integration
Correct installation is essential because the DS200UPSAG1AGD is associated with the electrical power system of the control cabinet.
Before replacing the board, technicians should document the original installation and verify the electrical characteristics of the replacement.
Recommended procedures include:
- Follow the approved turbine shutdown procedure.
- Isolate the appropriate control-system power.
- Verify the complete DS200UPSAG1AGD part number.
- Record the board revision.
- Document all cables and connector positions.
- Identify the original cabinet location.
- Inspect the replacement board for physical damage.
- Check connectors and power-related components.
- Compare the replacement with the original board.
- Install the board in the designated Mark V position.
- Reconnect wiring according to approved documentation.
- Verify associated power-input and power-output connections.
- Check downstream power circuits.
- Restore power according to approved procedures.
- Verify power-system indications.
- Check Mark V diagnostic information.
- Confirm operation of connected control hardware.
- Verify communication and I/O functionality.
- Perform system-level testing before returning equipment to service.
ESD protection should be used whenever handling the PCB.
Power-related boards should never be substituted solely according to physical dimensions. The electrical characteristics, connector configuration, revision, and system application must be checked before installation.
Compatible System Components
The DS200UPSAG1AGD can work with a range of components in a GE Mark V installation.
| Component | Function |
|---|---|
| Mark V Control Processor | Executes turbine-control logic |
| I/O Engine CPU Board | Performs local I/O processing |
| Digital I/O Boards | Process discrete field signals |
| Analog I/O Boards | Process analog measurements |
| LAN Communication Hardware | Supports system communication |
| Terminal Boards | Provide field wiring interfaces |
| DC Power Input Boards | Provide power-input functions |
| Power Distribution Hardware | Distributes electrical power |
| Control Cabinet | Houses Mark V equipment |
| Auxiliary Control Circuits | Support additional turbine functions |
The actual combination of components depends on the turbine model and original Mark V system design.
Recommended Alternative Models
The following models may be considered when evaluating related GE Mark V power hardware:
| Model | Type | Key Feature | Application |
|---|---|---|---|
| DS200UPSAG1AGD | Power Board | Dedicated Mark V power support | Turbine control |
| DS200UPLAG1BEA | LAN Power Circuit Board | LAN power circuitry | Mark V communication |
| DS200UPLAG1BDA | LAN Power Supply Board | LAN power support | Mark V network |
| DS200TCPSG1ARE | DC Power Input Board | DC power interface | Mark V power system |
| DS200TCPSG1AME | DC Input Power Board | DC input function | Mark V control |
These boards are related to Mark V power functions but have different intended applications.
The DS200UPSAG1AGD should not automatically be replaced by a LAN power board or DC input board simply because the boards have similar physical characteristics.
Compatibility should be determined using the complete part number, board revision, electrical specifications, connector configuration, and original turbine-control architecture.
Key Advantages
The GE DS200UPSAG1AGD provides several advantages in Mark V turbine-control applications:
- Provides dedicated power-system functionality
- Supports stable operation of control hardware
- Integrates with GE Mark V architecture
- Supports processors and I/O-related circuitry
- Supports power distribution within the control cabinet
- Suitable for turbine automation applications
- Supports maintenance of legacy Speedtronic systems
- Compact industrial PCB design
- Provides a dedicated electrical support function
- Helps maintain the availability of connected control hardware
Its main value is its role as part of the power infrastructure that supports the operation of other Mark V electronic components.
Technical FAQs
What is GE DS200UPSAG1AGD?
The GE DS200UPSAG1AGD is a MARK V Power Board designed to provide power-related support within GE turbine control systems.
What is the main function of DS200UPSAG1AGD?
Its primary function is to support power distribution and electrical supply functions for associated Mark V control-system circuitry.
What are the dimensions of DS200UPSAG1AGD?
The specified dimensions are 200 × 150 × 25 mm.
What is the weight of DS200UPSAG1AGD?
The specified weight is 0.93 kg.
Is DS200UPSAG1AGD a processor board?
No. It is a power board rather than a CPU or turbine-control processor.
Is DS200UPSAG1AGD a LAN power board?
No. It is identified as a general Mark V Power Board, while the DS200UPLAG family is associated specifically with LAN power-related functions.
Can DS200UPSAG1AGD replace DS200UPLAG1BEA?
It should not automatically be treated as a direct replacement. Their system functions are different even though both are related to power within the Mark V architecture.
Can DS200TCPSG1ARE replace DS200UPSAG1AGD?
Direct substitution should not be assumed. The DS200TCPSG1ARE is a DC Power Input Board and may have a different electrical role and system assignment.
What should be checked before replacing DS200UPSAG1AGD?
The complete part number, board revision, electrical specifications, connectors, wiring, cabinet position, associated loads, and Mark V system configuration should be verified.
Conclusion
The GE DS200UPSAG1AGD MARK V Power Board is a specialized power-related component used within GE Mark V turbine control systems.
Its primary purpose is to provide electrical support for associated control-system circuitry, helping processors, I/O hardware, communication equipment, and other Mark V components receive the required power through the appropriate system architecture.
The specified dimensions are 200 × 150 × 25 mm, with a weight of 0.93 kg.
The DS200UPSAG1AGD can operate alongside Mark V processors, I/O engine hardware, communication boards, terminal interfaces, and other power-related components.
For maintenance engineers, system integrators, and spare-parts procurement teams, accurate identification of the complete DS200UPSAG1AGD part number is essential before replacement. Related GE power boards may look similar while having different electrical functions and system assignments.
When correctly matched with the original Mark V configuration, the DS200UPSAG1AGD provides a dedicated power-board solution for maintaining reliable electrical support within legacy GE turbine automation systems.
