Bently Nevada 330500-06-00 Proximity Transducer System Product Overview
1. Product Introduction
The Bently Nevada 330500-06-00 is a high-precision proximity transducer system designed for monitoring the operating condition of critical rotating machinery. It belongs to the 3300 XL Proximity Transducer System series and is mainly used for measuring shaft vibration, radial displacement, and axial position changes in industrial equipment.
The product adopts eddy current sensing technology, allowing the sensor to measure the distance between the probe tip and the rotating shaft without direct physical contact. This measurement principle provides excellent accuracy, repeatability, and long-term reliability in demanding industrial environments.
The 330500-06-00 configuration is designed for applications requiring extended installation distance between the sensing point and monitoring equipment. The longer cable configuration improves installation flexibility, especially for large rotating machines where the monitoring cabinet is located away from the equipment.
The system is commonly applied to steam turbines, gas turbines, compressors, generators, pumps, and large industrial motors. It provides continuous information about shaft movement, helping operators identify abnormal conditions and perform preventive maintenance before equipment failure occurs.
The complete proximity transducer system consists of a proximity probe, extension cable, and signal processing electronics. The probe detects shaft movement, the cable transfers the measurement signal, and the electronics convert the signal into a standardized output for machinery monitoring systems.
<br>
2. Product Basic Information
| Item | Description |
|---|---|
| Model | Bently Nevada 330500-06-00 |
| Brand | Bently Nevada |
| Product Series | 3300 XL Proximity Transducer System |
| Product Type | Eddy Current Proximity Transducer System |
| Sensor Type | 8 mm Proximity Probe |
| Measurement Principle | Non-contact eddy current sensing technology |
| Main Function | Shaft vibration and displacement measurement |
| Cable Configuration | 6-meter system configuration |
| Application Field | Rotating machinery condition monitoring |
| Installation Type | Industrial fixed installation |
| Measurement Object | Rotating shaft movement |
| Output Signal | Proportional voltage output |
| Product Purpose | Machinery protection and predictive maintenance |
<br>
3. Detailed Technical Parameters
| Parameter | Specification |
|---|---|
| Model | 330500-06-00 |
| Product Series | 3300 XL Proximity Transducer System |
| Sensor Technology | Eddy Current Displacement Measurement Technology |
| Probe Diameter | 8 mm |
| Cable Length | 6 meters |
| Measurement Type | Shaft vibration, radial displacement, axial position measurement |
| Measurement Method | Non-contact electromagnetic sensing |
| Probe Material | Stainless steel alloy construction |
| Probe Type | Industrial proximity sensor |
| Sensitivity | Approximately 7.87 V/mm |
| Operating Voltage | -24 VDC nominal |
| Output Type | Analog voltage proportional to shaft displacement |
| Frequency Response | Suitable for high-speed rotating machinery monitoring |
| Operating Temperature | Approximately -40°C to +177°C depending on installation conditions |
| Cable Material | Industrial flexible protective cable |
| Mounting Method | Threaded mechanical installation |
| Environmental Resistance | Resistant to vibration, temperature variation, and industrial conditions |
| Signal Stability | Stable output during continuous operation |
| Recommended Equipment | Turbines, compressors, generators, motors, pumps |
| Installation Distance | Suitable for large equipment requiring extended cable length |
| Dimensions | Probe diameter approximately 8 mm × cable length approximately 6000 mm |
| Weight | Approximately 0.45 kg |
<br>
4. Product Structure Description
Proximity Probe
The proximity probe is the primary sensing component responsible for measuring shaft movement.
The probe generates an electromagnetic field near the rotating shaft surface. When the shaft position changes, the electromagnetic field changes accordingly, allowing the system to accurately determine displacement.
The probe provides:
- High measurement precision
- Non-contact operation
- Excellent repeatability
- Long operating life
- Reduced mechanical maintenance
<br>
Extension Cable
The 6-meter extension cable provides additional installation flexibility for large industrial equipment.
It allows the sensing probe to remain close to the rotating shaft while the monitoring electronics can be installed in a protected control area.
Main advantages:
- Suitable for large machinery layouts
- Flexible installation distance
- Reliable signal transmission
- Stable measurement performance
<br>
Signal Processing Electronics
The signal processing section receives the probe output and converts it into a usable monitoring signal.
The processed data can support:
- Machinery protection systems
- Vibration analysis
- Alarm monitoring
- Preventive maintenance decisions
<br>
5. Product Applications
Steam Turbine Monitoring
The 330500-06-00 is widely suitable for steam turbine shaft monitoring applications.
It provides continuous monitoring of:
- Rotor vibration
- Shaft displacement
- Mechanical imbalance
- Bearing condition changes
By detecting abnormal shaft movement early, maintenance teams can reduce the risk of unexpected equipment shutdown.
<br>
Gas Turbine Monitoring
Gas turbines require accurate and reliable monitoring because they operate at high speed and under severe conditions.
The product supports:
- Rotor position monitoring
- Vibration protection
- Mechanical condition evaluation
- Equipment reliability improvement
<br>
Compressor Applications
Large compressors require continuous shaft monitoring to maintain stable operation.
The product can help detect:
- Rotor instability
- Shaft misalignment
- Excessive vibration
- Mechanical wear
<br>
Generator Monitoring
Generators are critical rotating machines that require reliable condition monitoring.
The proximity transducer system provides shaft movement information to support:
- Equipment protection
- Maintenance planning
- Operational reliability
<br>
Industrial Pump and Motor Monitoring
The product can be installed on large industrial motors and pumps.
Typical applications include monitoring:
- Shaft vibration
- Rotor imbalance
- Mechanical looseness
- Alignment problems
<br>
6. Product Advantages
High Measurement Accuracy
The product provides precise shaft displacement measurement through eddy current technology.
The non-contact measurement method avoids mechanical contact errors and provides reliable measurement during continuous machine operation.
<br>
Extended Installation Flexibility
The 6-meter cable configuration allows installation on large machines where the sensing point and monitoring equipment are separated by distance.
This improves system layout flexibility and simplifies equipment installation.
<br>
Non-Contact Measurement Design
The probe does not physically contact the rotating shaft.
Benefits include:
- Reduced mechanical wear
- Longer service life
- Lower maintenance requirements
- Stable measurement performance
<br>
Excellent Long-Term Stability
The system is designed for continuous industrial operation.
It maintains consistent output performance under long working cycles and demanding machinery conditions.
<br>
Strong Environmental Adaptability
The product is suitable for environments with:
- Continuous vibration
- Temperature changes
- Heavy industrial equipment operation
- Long-term operation requirements
<br>
Reliable Machinery Protection
The product provides early warning information by monitoring shaft movement changes.
It helps maintenance teams identify potential failures before serious damage occurs.
<br>
7. Brand Information
| Item | Description |
|---|---|
| Brand | Bently Nevada |
| Industry Field | Industrial Machinery Monitoring |
| Main Product Categories | Proximity Sensors, Vibration Monitoring Systems, Machinery Protection Equipment |
| Application Areas | Energy, Manufacturing, Process Equipment, Heavy Industry |
| Product Characteristics | High precision, stable operation, industrial reliability |
<br>
8. Product Series Information
3300 XL Proximity Transducer System Series
The 3300 XL Proximity Transducer System series is designed for continuous monitoring of critical rotating machinery.
The series includes different probe sizes, cable lengths, and configurations to meet various installation requirements.
Main characteristics:
- High precision shaft vibration measurement
- Eddy current non-contact sensing technology
- Stable signal output
- Long operating life
- Suitable for machinery protection applications
The 330500-06-00 belongs to the 3300 XL 8 mm proximity probe family and uses a 6-meter cable configuration designed for large equipment installations requiring extended sensor placement distance.
<br>
9. Recommended Same Series or Related Models
| Model | Series | Main Parameters | Dimensions | Weight (kg) |
|---|---|---|---|---|
| 330500-05-00 | 3300 XL Proximity Transducer System | 8 mm probe, 5-meter cable configuration, shaft vibration monitoring | Approx. 8 mm diameter × 5000 mm cable length | 0.42 kg |
| 330500-04-00 | 3300 XL Proximity Transducer System | 8 mm probe, 4-meter cable configuration | Approx. 8 mm diameter × 4000 mm cable length | 0.38 kg |
| 330500-03-06 | 3300 XL Proximity Transducer System | 8 mm probe, 6-meter cable configuration for extended installation | Approx. 8 mm diameter × 6000 mm cable length | 0.45 kg |
| 330101-00-08-10-02-00 | 3300 XL Series | Standard 8 mm proximity probe system | Approx. 8 mm diameter × 1000 mm length | 0.28 kg |
| 330180-50-00 | 3300 XL Probe Series | Precision proximity probe for shaft displacement measurement | Approx. 8 mm diameter × 1000 mm length | 0.27 kg |
<br>
10. Recommended Popular Models From The Same Brand
| Model | Series | Main Parameters | Dimensions | Weight (kg) |
|---|---|---|---|---|
| 3500/42M 140734-01 | 3500 Monitoring System | Four-channel vibration monitoring module supporting proximity signals | Approx. 241 mm × 24 mm × 119 mm | 0.60 kg |
| 3500/22M 138607-01 | 3500 Monitoring System | Machinery data interface module for monitoring applications | Approx. 241 mm × 24 mm × 119 mm | 0.55 kg |
| 330180-50-00 | 3300 XL Series | 8 mm proximity probe for shaft vibration and displacement measurement | Approx. 8 mm diameter × 1000 mm length | 0.27 kg |
| 330130-040-00-00 | 3300 XL Extension Cable Series | Extension cable for proximity sensor systems | Approx. 4000 mm cable length | 0.20 kg |
| 3300 XL 8 mm Proximity Probe | 3300 XL Series | Standard proximity sensor for industrial shaft monitoring | Approx. 8 mm diameter × various length options | 0.25 kg |
<br>
11. Product Selection Summary
The Bently Nevada 330500-06-00 is a high-reliability proximity transducer system designed for monitoring large rotating machinery.
With its 8 mm eddy current probe and 6-meter cable configuration, the product provides accurate shaft displacement measurement and excellent installation flexibility for large industrial equipment.
The system is suitable for turbines, compressors, generators, motors, and pumps where continuous monitoring and machinery protection are required.
Its main advantages include accurate measurement, non-contact operation, long-term stability, strong environmental resistance, and flexible installation capability.
As a member of the 3300 XL Proximity Transducer System series, the 330500-06-00 provides dependable performance for rotating equipment condition monitoring, predictive maintenance, and machinery protection applications.
