Bently Nevada 330301-000-016-10-90-01-00
Detailed Product Introduction, Technical Specifications, Applications, Advantages, Product Series, and Recommended Models
Product Introduction
The Bently Nevada 330301-000-016-10-90-01-00 is a precision 8 mm Eddy Current Proximity Probe Assembly designed for continuous monitoring of rotating machinery. It belongs to the 3300 XL Proximity Transducer System Series and is used for non-contact measurement of shaft vibration, radial displacement, and rotor position.
The product is a key sensing element in machinery protection and condition monitoring systems. It uses eddy current measurement technology to detect the distance between the probe tip and the rotating shaft surface without physical contact.
The 330301-000-016-10-90-01-00 is designed for applications where accurate shaft movement detection and reliable long-term operation are required.
The probe provides measurement capability for:
- Radial shaft vibration
- Shaft displacement
- Rotor position
- Mechanical movement analysis
- Rotating equipment condition monitoring
- Machinery protection systems
Unlike contact-type sensors, the eddy current proximity probe does not require mechanical contact with the rotating shaft. This allows continuous measurement without wear caused by friction.
The probe assembly normally works together with:
- Extension cable
- Proximitor sensor module
- Monitoring system
- Machinery protection equipment
The product provides an electrical signal proportional to the distance between the probe tip and the shaft target surface.
This allows monitoring systems to detect changes in:
- Shaft vibration amplitude
- Rotor movement
- Mechanical alignment
- Bearing condition
- Machine operating stability
The product is suitable for critical rotating equipment where early detection of abnormal conditions is important.
Typical installation environments include:
- Turbine systems
- Compressors
- Pumps
- Motors
- Generators
- Industrial rotating machinery
The probe design focuses on:
- High measurement accuracy
- Stable electrical characteristics
- Excellent environmental resistance
- Long operating life
- Reliable signal output
Brand
Bently Nevada is an industrial brand specializing in rotating machinery monitoring, vibration measurement, and equipment protection technologies.
The product range includes:
- Eddy current proximity probes
- Extension cable assemblies
- Proximitor sensor modules
- Vibration monitoring modules
- Machinery protection components
These products are commonly used in industries requiring high equipment reliability, including:
- Power generation
- Oil and gas
- Petrochemical
- Chemical processing
- Marine systems
- Heavy manufacturing
- Large rotating equipment
The brand is widely recognized for precision measurement solutions and reliable machinery condition monitoring technology.
Product Series
3300 XL Proximity Transducer System Series
The 3300 XL Proximity Transducer System Series is a high-performance non-contact measurement platform designed for monitoring rotating machinery.
The system uses eddy current technology to measure shaft movement by detecting changes in the electromagnetic field between the probe tip and the rotating shaft.
A complete measurement system usually consists of:
- Proximity Probe
- Extension Cable
- Proximitor Sensor
- Monitoring Module
The proximity probe is the primary sensing element and provides the initial measurement signal.
Main functions of the series include:
- Shaft vibration measurement
- Radial displacement monitoring
- Axial position measurement
- Rotor condition analysis
- Machinery protection
The 3300 XL series is widely applied in industries where equipment reliability and continuous monitoring are required.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 330301-000-016-10-90-01-00 |
| Product Type | Eddy Current Proximity Probe Assembly |
| Product Series | 3300 XL Proximity Transducer System |
| Sensor Technology | Eddy Current Non-contact Measurement |
| Probe Diameter | 8 mm |
| Measurement Type | Shaft Displacement and Vibration Measurement |
| Target Measurement | Rotating Shaft Surface |
| Operating Principle | Electromagnetic Eddy Current Detection |
| Thread Size | Industrial Probe Mounting Thread |
| Probe Length | Approximately 160 mm |
| Extension Compatibility | Compatible with 3300 XL Extension Cable System |
| Signal Output | Dynamic Displacement Signal |
| Frequency Response | DC to approximately 10 kHz |
| Measurement Range | Standard 8 mm Probe Range |
| Operating Temperature | Approximately -52°C to +177°C |
| Storage Temperature | Approximately -55°C to +200°C |
| Environmental Resistance | Industrial High Temperature Environment |
| Installation Type | Threaded Mechanical Installation |
| Housing Material | Stainless Steel / Industrial Metal Construction |
| Cable Connection | Compatible Probe Connector System |
| Application | Rotating Machinery Monitoring |
| Protection Function | Vibration and Position Monitoring |
| Probe Tip Material | Wear Resistant Conductive Material |
| Overall Dimensions | Approximately 160 × 8 × 8 mm |
| Weight | Approximately 0.15 kg |
Product Structure and Working Principle
The 330301-000-016-10-90-01-00 operates using eddy current measurement technology.
The working process includes several stages.
1. Electromagnetic Field Generation
The probe generates a high-frequency electromagnetic field at the probe tip.
When the probe approaches the rotating shaft, the shaft surface affects the electromagnetic field.
2. Distance Measurement
Changes in the gap between the probe and shaft create corresponding electrical variations.
The system converts these changes into measurement information.
3. Signal Transmission
The probe sends the measurement signal through the extension cable to the signal conditioning module.
4. Signal Processing
The Proximitor sensor processes the signal and converts it into a standardized output for monitoring equipment.
5. Machinery Condition Analysis
The monitoring system evaluates:
- Shaft vibration
- Rotor position
- Mechanical stability
- Equipment operating condition
This allows early detection of possible mechanical problems.
Product Applications
1. Steam Turbine Monitoring
The probe is widely used in steam turbine protection systems.
Typical applications:
- Shaft vibration measurement
- Rotor displacement monitoring
- Turbine operating analysis
- Mechanical fault detection
2. Gas Turbine Applications
Gas turbines require accurate monitoring due to high-speed operation.
The probe supports:
- Rotor position measurement
- Vibration monitoring
- Mechanical stability analysis
- Equipment protection
3. Compressor Monitoring
Large compressors require continuous shaft monitoring.
Applications include:
- Rotor vibration detection
- Shaft movement analysis
- Mechanical condition evaluation
- Predictive maintenance
4. Pump and Motor Monitoring
The product can be applied to:
- Large industrial pumps
- Electric motors
- Drive systems
- Process equipment
Functions include:
- Vibration monitoring
- Shaft displacement measurement
- Equipment protection
5. Generator Monitoring
The probe is suitable for generator applications.
It helps monitor:
- Rotor movement
- Shaft stability
- Mechanical operating conditions
Product Advantages
1. Non-contact Measurement Technology
The probe measures shaft movement without physical contact.
Advantages:
- No mechanical wear
- Long operating life
- Continuous monitoring capability
2. High Measurement Accuracy
The product provides accurate displacement measurement.
Benefits:
- Reliable vibration analysis
- Improved fault detection
- Better machinery protection
3. Excellent Temperature Resistance
The probe is designed for demanding industrial environments.
It can operate under:
- High temperature conditions
- Continuous machine operation
- Industrial vibration environments
4. Stable Electrical Performance
The probe provides consistent signal characteristics.
This improves:
- Monitoring reliability
- Signal repeatability
- System accuracy
5. Wide Industrial Application
The product can be applied across multiple industries.
Suitable equipment includes:
- Turbines
- Compressors
- Pumps
- Motors
- Generators
6. Supports Predictive Maintenance
Accurate vibration information helps maintenance teams identify problems early.
Benefits include:
- Reduced downtime
- Improved maintenance planning
- Extended equipment life
7. Easy System Integration
The probe works with compatible extension cables and monitoring modules.
This allows flexible installation in existing monitoring systems.
Recommended Models from the Same Series or Related Models
| Model | Product Type | Main Function | Probe Size / Specification | Operating Temperature | Dimensions | Weight (kg) |
|---|---|---|---|---|---|---|
| 330301-000-016-10-90-01-00 | Eddy Current Proximity Probe | Shaft Vibration Measurement | 8 mm Probe | -52°C to +177°C | 160 × 8 × 8 mm | 0.15 |
| 330103-00-05-10-02-00 | 8 mm Proximity Probe | Shaft Displacement Measurement | 8 mm Probe | -52°C to +177°C | 100 × 8 × 8 mm | 0.15 |
| 330103-00-05-10-02-CN | Proximity Probe Assembly | Rotor Monitoring | 8 mm Probe | -52°C to +177°C | 100 × 8 × 8 mm | 0.15 |
| 330190-085-01-00 | Extension Cable Assembly | Probe Signal Extension | 8.5 m Cable | -52°C to +177°C | 8500 × 8 × 8 mm | 0.62 |
| 330300-90-00 | Extension Cable Assembly | Signal Transmission | 9 m Cable | -52°C to +177°C | 9000 × 8 × 8 mm | 0.65 |
Recommended Popular Models from the Same Brand
| Model | Product Type | Main Function | Compatible System | Operating Temperature | Dimensions | Weight (kg) |
|---|---|---|---|---|---|---|
| 330301-000-016-10-90-01-00 | Eddy Current Probe | Shaft Measurement | 3300 XL Series | -52°C to +177°C | 160 × 8 × 8 mm | 0.15 |
| 330130-085-11-05 | Extension Cable | Probe Signal Extension | 3300 XL System | -52°C to +177°C | 8500 × 8 × 8 mm | 0.62 |
| 330180-X1-05 161255-02 | Proximitor Sensor | Signal Conditioning | 3300 XL System | -35°C to +85°C | 120 × 80 × 55 mm | 0.58 |
| 3500/42M | Vibration Monitoring Module | Machinery Protection | 3500 System | 0°C to +65°C | 241 × 24 × 242 mm | 0.82 |
| 3500/22M | Communication Interface Module | Monitoring Communication | 3500 System | 0°C to +65°C | 241 × 24 × 242 mm | 0.79 |
Installation and Maintenance Recommendations
For reliable operation of the 330301-000-016-10-90-01-00, proper installation and maintenance are important.
Recommended practices include:
- Verify correct probe mounting position
- Maintain correct probe gap distance
- Ensure compatible extension cable selection
- Protect cable connections from damage
- Avoid excessive mechanical stress
- Keep installation area clean
- Check signal stability during operation
Regular inspection helps maintain measurement accuracy and extends the service life of the monitoring system.
Conclusion
The 330301-000-016-10-90-01-00 is a high-precision 8 mm Eddy Current Proximity Probe belonging to the 3300 XL Proximity Transducer System Series.
With accurate non-contact measurement capability, excellent temperature resistance, stable signal performance, and reliable industrial durability, it is suitable for critical rotating machinery monitoring applications.
The product provides essential shaft vibration and displacement information for machinery protection systems.
By improving measurement accuracy and supporting predictive maintenance strategies, the 330301-000-016-10-90-01-00 helps reduce unexpected failures, improve equipment reliability, and extend the operating life of important industrial rotating machinery.
