Product Overview

The Bently Nevada 330130-085-13-RU is a 3300 XL Standard Extension Cable used in the Bently Nevada 3300 XL proximity transducer system.

It provides the electrical connection between the 3300 XL proximity probe and the Proximitor sensor, ensuring accurate transmission of vibration, displacement, and Keyphasor signals for machinery condition monitoring and protection applications.

With an 8.5-meter cable length, this model is suitable for large-scale industrial installations requiring extended routing and robust mechanical performance. The “-RU” suffix indicates a specific configuration or regional variant within the Bently Nevada ordering system. Its 0.876 kg weight reflects a reinforced, heavy-duty construction.

Technical Specifications

Function and Working Principle

The 330130-085-13-RU operates as a low-loss coaxial signal transmission cable, carrying analog signals from the proximity probe to the Proximitor sensor while preserving measurement accuracy over long distances and harsh environments.

Signal Flow

1. The proximity probe detects shaft vibration using eddy-current technology.
2. Mechanical motion is converted into an analog electrical signal.
3. The extension cable transmits the signal with strong shielding against electrical noise.
4. The Proximitor sensor conditions the signal for monitoring and protection systems.

Vprobe→VProximitorV_{probe} \rightarrow V_{Proximitor}Vprobe​→VProximitor​

Key Functions

• Transmits vibration, displacement, and Keyphasor signals accurately
• Maintains signal integrity over an 8.5-meter cable length
• Provides reinforced mechanical durability for harsh industrial environments
• Reduces electromagnetic interference (EMI) and signal noise
• Supports continuous machinery condition monitoring
• Integrates into a calibrated 3300 XL measurement system

System Role

The cable is part of the 3300 XL proximity transducer system, consisting of:

• 3300 XL 8 mm Proximity Probe
• 330130-085-13-RU Standard Extension Cable
• 3300 XL Proximitor Sensor

Together, these components provide:

• Shaft vibration monitoring
• Radial displacement measurement
• Rotor dynamic analysis
• Machinery protection
• Predictive maintenance diagnostics

Industrial Applications

• Steam turbines
• Gas turbines
• Centrifugal compressors
• Industrial pumps
• Electric generators
• Large rotating motors
• Fans and blowers
• Petrochemical facilities
• Oil and gas processing plants
• Power generation systems

Installation Guidelines

• Ensure ClickLoc connectors are fully engaged and locked.
• Avoid excessive bending or mechanical stress on the cable.
• Route separately from high-voltage power cables to reduce EMI.
• Maintain proper grounding and shielding practices.
• Use only with compatible 3300 XL probes and Proximitor sensors.

Compatible Components

• Bently Nevada 3300 XL 8 mm Proximity Probes
• Bently Nevada 3300 XL Proximitor Sensors
• Bently Nevada 3500 Machinery Protection System
• Bently Nevada 3300 Monitoring System
• Industrial vibration monitoring systems

Key Advantages

• Extended 8.5-meter routing capability
• Heavy-duty reinforced construction (0.876 kg)
• High resistance to vibration, abrasion, and industrial conditions
• Excellent electromagnetic interference shielding
• Stable low-noise signal transmission
• Fully compatible with 3300 XL systems
• Supports long-term predictive maintenance and machine protection

Technical FAQs

Q1: What is the purpose of this extension cable?
It transmits analog vibration and displacement signals from the proximity probe to the Proximitor sensor.

Q2: What does the “RU” suffix indicate?
It represents a regional or configuration variant within the Bently Nevada product coding system.

Q3: Why is this cable heavier than other variants?
The 0.876 kg weight indicates reinforced construction with enhanced mechanical protection and shielding.

Q4: What equipment uses this cable?
It is commonly used in turbines, compressors, pumps, generators, and other critical rotating machinery systems.

Conclusion

The Bently Nevada 330130-085-13-RU 3300 XL Standard Extension Cable is a heavy-duty 8.5-meter industrial signal cable designed for reliable performance in demanding environments. Its reinforced construction and stable signal transmission make it a key component in the 3300 XL proximity transducer system for machinery protection and condition monitoring.
