Product Overview

The Bently Nevada 330130-085-02-00 is a 3300 XL Standard Extension Cable used in the Bently Nevada 3300 XL proximity transducer system.

It connects the 3300 XL proximity probe to the Proximitor sensor, enabling reliable transmission of vibration, displacement, and Keyphasor signals used in rotating machinery monitoring and protection systems.

With an 8.5-meter cable length, this model is designed for installations requiring slightly extended routing while maintaining stable signal integrity and system calibration.

Technical Specifications

Function and Working Principle

The 330130-085-02-00 functions as a low-loss coaxial transmission cable, carrying analog signals from the proximity probe to the Proximitor sensor while preserving measurement accuracy over extended distance.

Signal Flow

1. The proximity probe detects shaft vibration using eddy-current sensing.
2. Mechanical motion is converted into an analog electrical signal.
3. The extension cable transmits the signal with minimal attenuation.
4. The Proximitor sensor conditions the signal for monitoring and protection systems.

Vprobe→VProximitorV_{probe} \rightarrow V_{Proximitor}Vprobe​→VProximitor​

Key Functions

• Transmits vibration, displacement, and Keyphasor signals accurately
• Maintains signal integrity over an 8.5-meter cable length
• Reduces electromagnetic interference (EMI) in industrial environments
• Supports continuous machinery condition monitoring
• Integrates into a calibrated 3300 XL measurement system

System Role

The cable is part of the 3300 XL proximity transducer system, which includes:

• 3300 XL 8 mm Proximity Probe
• 330130-085-02-00 Standard Extension Cable
• 3300 XL Proximitor Sensor

Together, these components enable:

• Shaft vibration monitoring
• Radial displacement measurement
• Rotor dynamic analysis
• Machinery protection
• Predictive maintenance diagnostics

Industrial Applications

• Steam turbines
• Gas turbines
• Centrifugal compressors
• Pumps
• Electric generators
• Industrial motors
• Fans and blowers
• Petrochemical plants
• Oil and gas facilities
• Power generation systems

Installation Guidelines

• Secure ClickLoc connectors fully before operation.
• Avoid tight bends or mechanical stress on the cable.
• Route separately from high-voltage cables to minimize EMI.
• Maintain proper grounding and shielding practices.
• Use only with compatible 3300 XL probes and Proximitor sensors.

Compatible Components

• Bently Nevada 3300 XL 8 mm Proximity Probes
• Bently Nevada 3300 XL Proximitor Sensors
• Bently Nevada 3500 Machinery Protection System
• Bently Nevada 3300 Monitoring System
• Industrial vibration monitoring systems

Key Advantages

• Extended routing capability (8.5 meters)
• Stable low-noise signal transmission
• Strong resistance to electromagnetic interference
• Durable industrial-grade construction
• Fully compatible with 3300 XL systems
• Supports reliable predictive maintenance and protection strategies

Technical FAQs

Q1: What is the purpose of this extension cable?
It connects a proximity probe to a Proximitor sensor and transmits vibration and displacement signals.

Q2: Is this cable interchangeable with other 8.5 m variants?
Only if the system configuration suffix and compatibility match the 3300 XL requirements.

Q3: Can it operate alone?
No. It must be used as part of a complete probe–cable–Proximitor system.

Q4: Where is it typically used?
In turbines, compressors, pumps, generators, and other critical rotating machinery systems.

Conclusion

The Bently Nevada 330130-085-02-00 3300 XL Standard Extension Cable is a precision-engineered 8.5-meter signal transmission cable designed for reliable operation in the 3300 XL proximity transducer system. Its stable performance and low-noise characteristics make it well-suited for industrial machinery protection and condition monitoring applications.
