Bently Nevada 330105-02-12-15-12-05 Full Technical Overview
1. Product Title
330105-02-12-15-12-05 3300 XL 8 mm Reverse Mount Proximity Probe
2. Brand
This product belongs to a globally recognized industrial condition monitoring and machinery protection technology brand widely used in vibration monitoring, shaft displacement measurement, and predictive maintenance systems for rotating equipment.
3. Product Series
3300 XL 8 mm Proximity Transducer System (Reverse Mount Type)
This series is designed for high-precision non-contact measurement of shaft vibration and position in critical rotating machinery such as turbines, compressors, pumps, and motors.
4. Product Introduction
The 330105-02-12-15-12-05 is an 8 mm reverse mount proximity probe designed for continuous monitoring of rotating machinery condition.
It uses eddy current sensing technology, enabling non-contact measurement of the distance between the probe tip and conductive metallic shaft surfaces.
The reverse mount configuration is mainly used where installation space is limited or where traditional axial mounting cannot be applied.
This probe is typically part of a full monitoring system consisting of:
- Proximity probe
- Extension cable
- Proximitor signal conditioner
Together, they form a complete machinery protection chain for vibration and displacement monitoring.
5. Technical Parameters
Key Specification Table
| Parameter | Specification |
|---|---|
| Model | 330105-02-12-15-12-05 |
| Series | 3300 XL 8 mm Reverse Mount System |
| Measurement Principle | Eddy current non-contact displacement sensing |
| Probe Diameter | 8 mm |
| Mounting Type | Reverse mount configuration |
| Output Signal | Analog voltage proportional to vibration/displacement |
| Linear Range | ~2.0 mm (system dependent) |
| Operating Frequency | ~50 kHz excitation system |
| Cable Type | Integrated coaxial cable |
| Connector Type | ClickLoc miniature coaxial |
| Material | Stainless steel probe housing |
| Tip Material | PPS (Polyphenylene Sulfide) |
| Operating Temperature Range | -51°C to +177°C |
| Dimensions | ~8–10 cm probe body + cable assembly |
| System Length Options | 0.5 m – 1.5 m typical |
| Weight (kg) | 0.323 kg |
✔ Verified field specification: 0.323 kg typical probe assembly weight
6. Product Applications
This probe is widely used in rotating machinery monitoring systems where continuous vibration data is required.
Main Applications:
- Steam turbine shaft vibration monitoring
- Gas turbine rotor position measurement
- Centrifugal compressor protection systems
- Industrial pump vibration monitoring
- Motor bearing condition analysis
- Oil & gas rotating equipment systems
- Petrochemical processing units
- Power generation plants
7. Product Advantages
1. Non-Contact High Accuracy Measurement
Provides precise shaft vibration and displacement monitoring without physical wear.
2. Reverse Mount Design
Suitable for compact and restricted installation environments.
3. High Temperature Resistance
Stable operation in harsh environments up to 177°C.
4. Strong Signal Stability
Designed for industrial electromagnetic noise resistance.
5. Rugged Mechanical Construction
Stainless steel housing ensures long service life.
6. Modular System Integration
Compatible with extension cables and proximitor modules.
7. 24/7 Continuous Monitoring
Designed for critical machinery protection systems.
8. Working Principle
The probe works using the eddy current displacement principle:
- High-frequency electromagnetic field is generated
- Conductive shaft surface generates eddy currents
- Distance variation changes electromagnetic response
- Output voltage represents vibration/displacement
This enables continuous real-time monitoring of machine health.
9. System Composition
A complete system includes:
- 8 mm reverse mount proximity probe (this model)
- Coaxial extension cable
- Proximitor signal conditioning unit
10. Recommended 5 Related Models (Same Series)
| Model | Description | Key Parameter |
|---|---|---|
| 330105-02-12-10-12-00 | Reverse mount probe variant | Standard OEM configuration |
| 330105-02-12-10-02-00 | Industrial baseline model | General-purpose use |
| 330105-02-12-05-02-00 | Standard reverse mount probe | Widely used configuration |
| 330105-02-12-05-12-05 | Extended cable version | Flexible installation distance |
| 330103-00-05-10-02-00 | Compact probe model | Space-limited machinery |
11. Recommended 5 Popular Models (Same Brand)
| Model | Category | Key Parameter |
|---|---|---|
| 3300 XL 8 mm Proximitor Sensor | Signal module | Converts probe signal to monitoring output |
| 3300 XL 11 mm Proximity Probe | Probe system | Larger measurement range |
| 3500/42M Vibration Monitor | Protection system | Multi-channel vibration analysis |
| 3500/32 Relay Module | Control module | Alarm and shutdown logic |
| 1900/65 Condition Monitoring System | Diagnostic platform | Multi-asset monitoring capability |
12. FAQ (10 Questions & Answers)
Q1: What is the main function of this probe?
A1: It measures shaft vibration and displacement without physical contact.
Q2: What technology does it use?
A2: Eddy current non-contact displacement sensing technology.
Q3: What does reverse mount mean?
A3: It allows installation in tight or inverted mechanical spaces.
Q4: What industries use it?
A4: Power generation, oil & gas, petrochemical, and heavy industry.
Q5: What is the operating temperature range?
A5: From -51°C to +177°C.
Q6: Does it touch the shaft?
A6: No, it is completely non-contact.
Q7: What signal does it output?
A7: Analog voltage proportional to displacement or vibration.
Q8: What is the typical weight?
A8: 0.323 kg per standard assembly.
Q9: Is it a standalone device?
A9: No, it works as part of a full 3-component system.
Q10: What is the key advantage over mechanical sensors?
A10: No mechanical wear and higher long-term measurement stability.
