Bently Nevada 330101‑00‑13‑10‑02‑00 — Technical & Functional Overview
Technical Specifications
| Parameter | Specification / Typical Estimate |
|---|---|
| Model | 330101‑00‑13‑10‑02‑00 |
| Series | 3300 XL 8 mm Proximity Probe Series |
| Probe / Tip Diameter | 8 mm |
| Mounting Thread | 3/8‑24 UNF |
| Case Length Code “13” | ~1.3 inch body length (longer than “12” standard) |
| Cable Length Code “10” | 1.0 m standard cable |
| Connector / Interface | Miniature coaxial ClickLoc (code “02”) |
| Approval / Certification | Standard (no extra suffix) |
| Linear Measurement Range | ~2.0 mm (80 mils) typical for 8 mm family |
| Sensitivity / Scale Factor | ~7.87 V/mm (≈200 mV/mil) ±5% typical |
| DC Resistance | ~7.5 to 8 Ω (probe + cable) (estimate) |
| Cable Capacitance | ~70 pF / meter (estimate) |
| Weight | ~0.30–0.35 kg (including 1.0 m cable) (estimate) |
| Operating Temperature | –52 °C to +177 °C (typical 3300 XL rating) |
| Tip Material | PPS plastic |
| Body / Housing Material | Stainless steel (303/304) |
| Environmental Sealing | O-ring / sealing to resist moisture & dust |
⚠️ Note: Because detailed, published spec sheets for this exact model couldn’t be confirmed, many values above are extrapolated from the broader 3300 XL 8 mm probe family and vendor norms.
Product Introduction
The 330101‑00‑13‑10‑02‑00 is a proximity probe in the 3300 XL 8 mm family, designed for non-contact displacement and vibration measurement of rotating machinery. Its slightly extended “13” case length may help in installations needing extra clearance or deeper mounting positions compared to the “12” case versions.
Equipped with a 1.0 m cable and ClickLoc connector, it is intended to integrate with existing 3300 XL monitoring systems. The combination of robust stainless steel body, PPS tip, and typical 8 mm family performance ensures that it can serve in industrial environments — turbines, pumps, compressors, motors — for continuous monitoring.
Because it follows the architecture of the 3300 XL line, it offers good compatibility with existing module systems, facilitating upgrades or replacements while keeping measurement consistency across probes.
Applications
-
Shaft vibration and displacement monitoring for turbines, compressors, pumps, motors
-
Condition monitoring systems (predictive maintenance) for early fault detection: imbalance, misalignment, bearing degradation, rotor eccentricity
-
Retrofit replacement in systems currently using 8 mm 3300 XL probes
-
Use in heavy industrial settings: power plants, petrochemical, oil & gas, manufacturing
-
Installations requiring a bit more physical length (deeper mounting) while preserving standard electrical and mechanical interface
Advantages
-
Extended case length (“13”) gives extra mechanical flexibility for mounting in constrained spaces
-
Family compatibility ensures this probe can replace or complement other 3300 XL probes without major system changes
-
Proven sensitivity (~200 mV/mil) gives precise measurement in many applications
-
Robust design: stainless steel body + PPS tip stand up to mechanical and environmental stress
-
Standard interfaces (3/8‑24 thread, ClickLoc connector) simplify installation and maintenance
-
Predictable performance due to its alignment with the broader 8 mm probe family
-
Cost-effective variant: by using standard, non‑certified design, cost may be lower than hazardous-area versions
Related & Comparative Models
Here are five models from the same or related series you might consider:
| Model | Case Length | Cable Length | Connector | Certification | Weight (kg est) |
|---|---|---|---|---|---|
| 330101‑00‑12‑10‑02‑05 | 1.2 in | 1.0 m | ClickLoc | Certified | ~0.323 |
| 330101‑00‑12‑10‑02‑00 | 1.2 in | 1.0 m | ClickLoc | Standard | ~0.323 |
| 330101‑00‑12‑05‑02‑05 | 1.2 in | 0.5 m | ClickLoc | Certified | ~0.30 |
| 330101‑00‑12‑15‑02‑05 | 1.2 in | 1.5 m | ClickLoc | Certified | ~0.33 |
| 330101‑00‑11‑10‑02‑05 | 1.1 in | 1.0 m | ClickLoc | Certified | ~0.320 |
And five popular Bently Nevada models (from similar families) for cross-reference:
-
330101‑00‑24‑10‑02‑05 — longer case, extended reach
-
330101‑00‑44‑10‑02‑05 — very extended mechanical length
-
330101‑00‑40‑10‑02‑00 — alternate length variant
-
330101‑00‑20‑10‑02‑05 — variant with longer cable
-
330101‑00‑12‑10‑02‑05 — widely used baseline model
FAQ — Top 10 (QA Format)
Q1: What is the “13” in the model number?
A1: It indicates a case length approx. 1.3 in, slightly longer than the typical “12” case, to accommodate deeper mounting needs.
Q2: What is its linear measurement range?
A2: It is estimated around 2.0 mm (80 mils), standard for many 8 mm 3300 XL probes.
Q3: What is the typical sensitivity?
A3: About 7.87 V/mm (≈200 mV/mil) ±5%, consistent with 8 mm probe family.
Q4: Does this model have hazardous-area certification?
A4: No — the “00” suffix implies it’s the standard (non‑certified) version.
Q5: What is the weight including cable?
A5: Roughly 0.30 to 0.35 kg for the probe + 1.0 m cable (estimate).
Q6: What is the operating temperature range?
A6: –52 °C up to +177 °C, consistent with the typical rating for 3300 XL probes.
Q7: What materials are used in its construction?
A7: Tip: PPS plastic; Housing / body: stainless steel (303/304).
Q8: What connector interface does it use?
A8: ClickLoc miniature coaxial (code “02”) — standard for 3300 XL probes.
Q9: Can this replace an existing “12” case probe?
A9: Yes, if mounting space allows, since electrical and interface are compatible — slight mechanical difference.
Q10: Does it require calibration?
A10: Usually not — routine checks of gap voltage, connector integrity, and system alignment suffice.
