Product Overview
The Allen Bradley 1787-PLUG10R is a DeviceNet 10-Pin Connector Plug designed to provide a secure and reliable connection within DeviceNet networks. With dimensions of 80 × 20 × 50 mm and a weight of 0.18 kg, this compact plug is suitable for industrial automation applications requiring robust, deterministic communication between devices such as sensors, actuators, and controllers.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen Bradley |
| Model | 1787-PLUG10R |
| Product Type | DeviceNet 10-Pin Connector Plug |
| Dimensions | 80 × 20 × 50 mm |
| Weight | 0.18 kg |
| Network Type | DeviceNet |
| Application | Device connections within DeviceNet networks |
| Mounting | Inline connection for DeviceNet cabling |
| Environmental Rating | Industrial-grade, suitable for harsh environments |
| Compatibility | Allen Bradley DeviceNet devices and 10-pin connectors |
Function and Working Principle
The 1787-PLUG10R operates by:
- Providing a secure 10-pin connection between DeviceNet devices
- Maintaining signal integrity and deterministic communication
- Facilitating modular network connections for sensors, actuators, and controllers
- Allowing easy network assembly, maintenance, and troubleshooting
It is a critical component for ensuring reliable communication in DeviceNet networks.
Role in Industrial Automation
The 1787-PLUG10R is essential for:
- Connecting devices in DeviceNet networks securely
- Maintaining high-speed, deterministic communication
- Supporting modular and scalable network topologies
- Enabling straightforward installation and maintenance of devices
Industrial Applications
- Automation systems in manufacturing, chemical, and process industries
- DeviceNet networks requiring secure 10-pin connections
- Integration of sensors, actuators, and controllers in industrial networks
- Maintenance and expansion of DeviceNet networks in harsh environments
Installation and Usage
Installation steps:
- Align the 1787-PLUG10R with the corresponding DeviceNet port
- Insert and secure the plug to ensure a reliable connection
- Verify proper pin alignment and signal continuity
- Confirm network communication after installation
- Ensure cables are routed to avoid physical stress or interference
Its compact, rugged design allows easy installation in confined or modular spaces.
Compatible System Components
- Allen Bradley DeviceNet sensors and actuators
- DeviceNet controllers and I/O modules
- DeviceNet cabling and connectors
- Industrial automation networks requiring 10-pin connectivity
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| 1787-PLUG10R | DeviceNet Connector Plug | 10-pin secure connection | Connecting devices in DeviceNet networks |
| 1787-PLUG5R | DeviceNet Connector Plug | 5-pin version | Smaller device connections |
| 1787-TRAPLUG | DeviceNet Terminal Plug | Inline termination | DeviceNet network termination |
Key Advantages
- Compact and lightweight (0.18 kg)
- Maintains high-speed, deterministic DeviceNet communication
- Supports modular and scalable network layouts
- Industrial-grade durability for harsh environments
- Easy installation and maintenance
Technical FAQs
What is the primary function?
It provides a secure 10-pin connection between DeviceNet devices, maintaining signal integrity.
Which systems is it compatible with?
Compatible with Allen Bradley DeviceNet devices, controllers, and I/O modules.
Can it operate in harsh environments?
Yes, it is industrial-grade, suitable for vibration, dust, and temperature variations.
Is it suitable for modular network setups?
Yes, it allows easy integration and maintenance of modular DeviceNet networks.
Conclusion
The Allen Bradley 1787-PLUG10R DeviceNet 10-Pin Connector Plug is a reliable, industrial-grade solution for secure connections in DeviceNet networks. Its compact size, durability, and support for deterministic communication make it essential for industrial automation systems requiring modular, scalable, and robust network connectivity.
