Allen Bradley 1746-WS — Detailed Technical Overview
1. Product Introduction
The Allen Bradley 1746-WS is a weighing scale module designed for integration within the SLC 500 PLC platform. It is a specialized intelligent module used for industrial weighing and force measurement applications, combining signal acquisition, processing, and control in a single unit.
Unlike standard I/O modules, this module contains an internal microprocessor that allows it to directly process load cell signals without requiring external signal conditioners. It connects to the PLC backplane and operates as an independent weighing controller while still exchanging data with the main processor.
The module supports functions such as gross weight, net weight, and rate-of-change measurement. It is commonly used in systems where precise weight monitoring and control are required, such as batching, filling, and dosing operations.
2. Product Parameters
Technical Specifications
| Parameter | Value |
|---|---|
| Model | 1746-WS |
| Series | SLC 500 |
| Module Type | Weigh Scale Module |
| Input Type | Load Cell (mV/V signals) |
| Number of Channels | Typically 1 scale system (multi-load cell support) |
| Input Sensitivity | Approx. 2–3 mV/V |
| Excitation Voltage | ~5–10 V DC (for load cells) |
| Resolution | High-resolution (approx. 16–24 bit internal processing) |
| Measurement Modes | Gross, Net, Rate-of-Change |
| Calibration | Electronic / Test weight calibration |
| Update Rate | Fast update suitable for dynamic weighing |
| Communication | Backplane data exchange |
| Power Supply | Backplane powered |
| Power Consumption | Approx. 3–6 W |
| Filtering | Built-in digital filtering for vibration/noise |
| Status Indicators | Module status LEDs |
| Operating Temperature | 0 to 60°C |
| Installation Type | Rack-mounted |
| Dimensions (mm) | 145 × 35 × 130 |
| Weight (kg) | 0.4 kg |
3. Product Applications
The 1746-WS is widely used in industrial weighing and measurement systems.
Typical applications include:
- Batching and blending systems
- Filling and dispensing processes
- Checkweighing systems
- Hopper and tank weighing
- Force measurement and tension monitoring
- Level measurement based on weight
It is particularly suitable for applications where accurate and stable weight measurement is required in real time.
4. Product Advantages
Integrated Weighing Functionality
Eliminates the need for external weighing controllers by integrating measurement and processing into one module.
High Measurement Accuracy
Supports precise load cell signal processing with high resolution.
Built-in Filtering Technology
Reduces vibration and noise effects, improving measurement stability.
Flexible Calibration Options
Supports both electronic calibration and traditional weight calibration methods.
Efficient System Integration
Directly integrates into the PLC rack, simplifying system design and wiring.
Reliable Industrial Performance
Designed for continuous operation in demanding environments with mechanical vibration and electrical noise.
5. Brand Information
Allen Bradley is widely known in industrial automation for producing PLC systems, I/O modules, and control equipment.
Its products are used across manufacturing, processing, and infrastructure industries, valued for reliability and long-term stability.
6. Product Series
- Series Name: SLC 500
- Category: Specialty Module (Weigh Scale / Measurement Module)
The SLC 500 series is a modular PLC platform that supports a wide variety of digital, analog, and intelligent modules. It is widely used for medium-scale industrial control systems requiring flexibility and reliability.
7. Recommended Models (Same Series / Related)
Related Models Table
| Model | Function | Channels | Signal Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 1746-NT4 | Temperature Input | 4 | Thermocouple | 145 × 35 × 130 | 0.3 kg |
| 1746-NI8 | Analog Input | 8 | Voltage/Current | 145 × 35 × 130 | 1.0 kg |
| 1746-NO4I | Analog Output | 4 | Current | 145 × 35 × 130 | 0.3 kg |
| 1746-HSCE | High-Speed Counter | 2 | Encoder | 145 × 35 × 130 | 0.3 kg |
| 1746-BAS | Basic Module | 1 | Serial/Logic | 145 × 35 × 130 | 0.35 kg |
8. Recommended Popular Models (Same Brand)
Popular Models Table
| Model | Series | Function | Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 1756-EN2T | ControlLogix | Communication | Ethernet | 140 × 112 × 145 | 0.5 kg |
| 1756-IF8 | ControlLogix | Analog Input | 8-channel | 140 × 112 × 145 | 0.6 kg |
| 1769-L33ER | CompactLogix | Controller | CPU | 118 × 87 × 140 | 0.7 kg |
| 1769-OF4 | CompactLogix | Analog Output | 4-channel | 118 × 87 × 140 | 0.5 kg |
| 1606-XLS240E | Power Supply | DIN Rail PSU | 24V DC | 123 × 50 × 125 | 0.8 kg |
