Product Overview: ABB TC530 (3BUR000101R1)
Brand & Series
-
Brand: ABB
-
Series: S800 / AC 800M / 800xA Automation Accessories
-
Product Type: Termination and Coupling Module for S800 I/O Systems
Product Description
The TC530 (3BUR000101R1) is a termination and coupling module designed for ABB’s S800 series I/O systems. It functions as a bus segment terminator and interface module, ensuring reliable signal transmission and isolation between multiple I/O modules. This guarantees error-free communication across the AC 800M and 800xA distributed control systems.
The TC530 is compact, lightweight, and DIN-rail mountable, making it suitable for industrial environments where space is limited. Its passive design requires no external power, ensuring low maintenance and reliable long-term operation. The robust construction allows the module to function reliably in a range of industrial temperature and humidity conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | TC530 |
| Part Number | 3BUR000101R1 |
| Function | Termination and coupling module |
| Bus Compatibility | S800 I/O bus |
| Voltage Requirement | Passive, no external power required |
| Bus Connector | 25‑pin DB25 female / S800 bus compatible |
| Mounting Type | DIN rail / Panel mount |
| Dimensions (H×W×D) | 65 × 20 × 52 mm |
| Weight (kg) | 0.065 |
| Operating Temperature | 0–55 °C |
| Storage Temperature | −40–+70 °C |
| Humidity | 5–95 % non-condensing |
| Environmental Compliance | RoHS, CE, UL |
| Compatibility | S800 I/O, AC 800M, 800xA systems |
Applications
TC530 is used in industrial automation environments requiring robust bus termination and coupling:
-
Termination and coupling of S800 I/O bus segments
-
Process automation in chemical, petrochemical, and pharmaceutical industries
-
Power generation and distribution control systems
-
Water and wastewater treatment automation
-
Manufacturing production lines
-
Mining and raw material processing systems
It ensures signal quality, prevents reflections, and supports proper segmentation in distributed I/O networks.
Key Advantages
-
Signal Integrity: Maintains clean, reliable communication across S800 bus networks.
-
Compact & Lightweight: Small footprint, weight 0.065 kg, easy installation.
-
Maintenance-Free: Passive design requires no external power.
-
Flexible Installation: Supports DIN rail and panel mounting.
-
Industrial Compatibility: Works with AC 800M and 800xA distributed control systems.
-
Robust Design: Withstands wide temperature and humidity ranges for industrial environments.
Recommended Related Models (Same Series / Similar Function)
| Model | Description | Basic Parameters |
|---|---|---|
| TC520 | Termination & coupling module | 65×18×50 mm, Weight 0.06 kg, passive |
| TC512 | Termination & coupling module | 60×18×48 mm, Weight 0.05 kg, passive |
| TC511 | S800 bus termination module | DIN rail mount, passive |
| TU845 | S800 I/O termination unit | DIN rail mount, passive, signal integrity |
| CI872K01 | AC 800M communication interface | Interface module for bus networks |
Popular ABB Models (Other Hot Units)
| Model | Category | Key Features |
|---|---|---|
| PM861AK01 | AC 800M CPU module | Central controller CPU for AC 800M |
| PM867 | High-end processor | Redundant CPU, advanced computing |
| AI810 | Analog Input Module | 8-channel AI for S800 systems |
| DP840 | Pulse Counter Module | Specialty I/O for counting applications |
| CI840A | Profibus DP Interface | Communication interface for Profibus networks |
FAQ (10 Q&A)
Q1: What is the primary function of TC530?
A1: It provides termination and coupling for S800 I/O bus segments, ensuring signal integrity and isolation.
Q2: Does TC530 require external power?
A2: No, it is a passive module and does not require power.
Q3: Where should TC530 be installed?
A3: On DIN rails or panel mounts within S800 I/O networks in control cabinets.
Q4: Which systems is TC530 compatible with?
A4: S800 I/O modules in AC 800M and 800xA distributed control systems.
Q5: Can TC530 be reused in another system?
A5: Yes, if it remains functional and is installed correctly.
Q6: What happens if the module is not used?
A6: Signal reflections and communication errors may occur in the bus network.
Q7: What environmental conditions can TC530 handle?
A7: Operating temperature 0–55 °C, storage −40–+70 °C, humidity 5–95 % non-condensing.
Q8: How is TC530 mounted?
A8: On DIN rails or panels using standard screws.
Q9: Does TC530 provide diagnostic feedback?
A9: No, it is passive; system performance is monitored indirectly through bus signals.
Q10: Is TC530 compliant with environmental regulations?
A10: Yes, it meets RoHS, CE, and UL standards for industrial safety and environmental compliance.
