Product Overview
The ABB Bailey NTMP01 INFI 90 Multi-Function Processor Termination Unit is a termination and interface component used in ABB Bailey INFI 90 control systems. It provides the connection interface associated with processor hardware, organizing electrical connections between the processor side of the control system and the surrounding cabinet wiring.
In an INFI 90 architecture, processor termination hardware helps establish a structured connection between system processors, associated cables, and other control-system components. The NTMP01 is therefore an interface-level component rather than the processor itself; it does not replace the processing functions performed by the associated INFI 90 processor.
For maintenance and replacement work, the complete NTMP01 part number should be verified against the installed system. Processor connections, cable assemblies, terminal assignments, and the surrounding INFI 90 hardware should be checked before installation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB Bailey |
| Model | NTMP01 |
| Product Family | INFI 90 |
| Product Type | Multi-Function Processor Termination Unit |
| Unit Function | Processor Signal Termination and Interface |
| Application | Industrial Process Control |
| System | ABB Bailey INFI 90 |
| Module Type | Processor Termination Unit |
| Interface Function | Processor and Control System Interconnection |
| Dimensions | 73.66 × 233.68 × 213.36 mm |
| Weight | 0.38 kg |
Product Features
- Multi-function processor termination unit for ABB Bailey INFI 90 systems.
- Provides a structured interface for processor-related connections.
- Supports electrical interconnection between processor hardware and associated system wiring.
- Suitable for INFI 90 control cabinet installations.
- Helps organize processor-side connections for maintenance and troubleshooting.
- Functions as an interface component rather than an independent processor.
- Suitable for replacement and retrofit work on existing INFI 90 systems.
Working Principle
The NTMP01 operates as part of the processor-side connection path in an INFI 90 control system. Processor-related signals and connections are routed through the termination unit to establish the required interface with associated cables and control hardware.
A simplified connection path is:
INFI 90 Processor → NTMP01 → System Cabling / Control Hardware → INFI 90 Control Network
The termination unit does not execute application logic or replace the processing functions of the connected processor. Its role is to provide the physical electrical interface required by the system architecture.
When troubleshooting a processor-related communication or system fault, the NTMP01 connection points should be checked together with the processor, cable assemblies, connectors, and associated control-system hardware. This helps separate physical connection problems from processor or system-level faults.
Role in an INFI 90 Control Architecture
| System Element | Function |
|---|---|
| INFI 90 Processor | Executes configured control and processing functions |
| ABB Bailey NTMP01 | Provides processor-side termination and interconnection |
| Processor Cable Assemblies | Carry signals between processor and associated system hardware |
| INFI 90 Control Modules | Perform distributed control and system functions |
| INFI 90 Network | Transfers system and control data |
| I/O Modules | Interface process signals with the control system |
| Operator Interface | Provides process monitoring, alarms, and operator control |
| Field Devices | Provide process measurements and receive control commands |
The NTMP01 occupies the processor interface portion of the INFI 90 architecture. It helps maintain the required physical connection between processor hardware and the rest of the control system while leaving processing and control functions to the associated electronics.
Industrial Applications
| Application | Typical Use |
|---|---|
| Process Control | Processor-side termination within INFI 90 systems |
| Power Generation | Control-system processor interconnection |
| Chemical Processing | Processor and cabinet-level signal interface |
| Oil and Gas | INFI 90 processor hardware integration |
| Industrial Utilities | Control-system connection and termination |
| System Retrofit | Replacement of existing processor termination hardware |
| Maintenance Spares | Stock replacement for installed Bailey INFI 90 systems |
Installation and Maintenance
- Confirm the complete NTMP01 part number before removing the existing termination unit.
- Place the associated INFI 90 control system in the appropriate maintenance state.
- Isolate applicable electrical circuits according to site safety procedures.
- Record processor cable and terminal connections before disconnecting the existing unit.
- Inspect connectors, terminals, and cable assemblies for physical damage or contamination.
- Verify that the replacement NTMP01 matches the installed INFI 90 configuration.
- Install the termination unit in the correct cabinet position.
- Reconnect processor-side cables and associated connections according to system documentation.
- Check cable routing and mechanical strain on connectors.
- Verify all connections are fully seated before restoring system power.
- Check processor and INFI 90 system diagnostics after energization.
- Confirm processor communication and associated control functions before returning the system to normal operation.
Related Components
| Component | Relationship |
|---|---|
| ABB Bailey INFI 90 Processors | Processor hardware connected through the termination interface |
| INFI 90 Processor Cable Assemblies | Carry processor-related signals through the termination arrangement |
| INFI 90 Control Modules | Provide distributed control functions within the system |
| INFI 90 I/O Modules | Interface field process signals |
| INFI 90 Network Components | Support communication between control-system elements |
| INFI 90 Termination Units | Provide additional system and field connection interfaces |
| Control Cabinet Hardware | Supports mounting and system-level wiring |
Recommended Related Models
| Model | Product Type / Application |
|---|---|
| ABB Bailey NTMP01 | INFI 90 Multi-Function Processor Termination Unit |
| ABB Bailey NTMF01 | INFI 90 Multi-Function Controller Termination Unit |
| ABB Bailey INFI 90 Processors | Control-system processing hardware |
| ABB Bailey INFI 90 I/O Modules | Process signal interface hardware |
| ABB Bailey INFI 90 Termination Units | System connection and field termination hardware |
Key Advantages
- Dedicated processor termination interface for INFI 90 systems.
- Supports structured processor-side interconnection.
- Helps organize cabinet-level processor connections.
- Simplifies access to processor-related wiring during maintenance.
- Suitable for replacement and retrofit applications.
Technical FAQs
What is the function of the ABB Bailey NTMP01?
The NTMP01 is an INFI 90 Multi-Function Processor Termination Unit. It provides the physical termination and interconnection interface associated with INFI 90 processor hardware.
Is the NTMP01 itself an INFI 90 processor?
No. The NTMP01 is a termination unit. Processor functions such as application execution and system processing are performed by the associated INFI 90 processor hardware.
What should be checked before replacing an NTMP01?
Verify the complete NTMP01 part number, processor configuration, cable assemblies, connector arrangement, terminal assignments, and surrounding INFI 90 hardware. Existing connections should be documented before removal.
What should be checked if processor communication is lost after installation?
First inspect the processor cable connections, connectors, and termination points. Then check the associated processor and INFI 90 network diagnostics. If the physical connections are correct, the processor configuration and other network components should be investigated.
