- Yokogawa
- F3YC08-0C
- Relay Output Module
- Japan
- 28.9 × 100 × 83.2 mm
- 0.17 kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 5
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Product Overview
The Yokogawa F3YC08-0C is an 8-point Relay Output Module designed for the FA-M3 PLC Series. It is used to switch external electrical loads such as contactors, solenoids, indicator lamps, alarms, and small motors through mechanical relay contacts.
Unlike transistor output modules, the F3YC08-0C supports both AC and DC load switching, making it a flexible solution for mixed industrial control environments requiring electrical isolation and high load compatibility.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Yokogawa |
| Model | F3YC08-0C |
| Product Type | Relay Output Module |
| PLC Platform | FA-M3 Series |
| Number of Output Channels | 8 Relay Outputs |
| Output Type | Mechanical Relay Contact |
| Load Voltage | 5–24 V DC / 100–240 V AC |
| Maximum Load Current | 2 A per point |
| Isolation Method | Mechanical isolation (relay) |
| Response Time | ≤ 10 ms (ON/OFF) |
| Output Configuration | Independent outputs |
| External Connection | Terminal block |
| LED Indicators | Output status LEDs |
| Power Supply | 5 V DC (backplane supply) |
| Mounting Method | FA-M3 base unit |
| Dimensions | 28.9 × 100 × 83.2 mm |
| Weight | 0.17 kg |
Function and Working Principle
The F3YC08-0C receives output commands from the PLC CPU and activates internal relay contacts to switch external loads.
When the PLC sends an ON signal, the relay coil energizes and closes the contact, allowing current to flow to the connected device. When the signal is OFF, the relay de-energizes and opens the contact, stopping the load.
Because it uses mechanical relays, the module provides galvanic isolation between control circuitry and field devices, improving safety and compatibility with different voltage levels.
Operating Sequence
- PLC CPU sends output command
- Relay coil is energized
- Contact closes or opens
- External load is switched ON/OFF
- Status feedback displayed via LED
- Cycle repeats
PLC Output→Relay Driver→Mechanical Contact→LoadPLC\;Output\rightarrow Relay\;Driver\rightarrow Mechanical\;Contact\rightarrow Load
Key Features
- 8-channel relay output configuration
- Supports AC and DC load switching
- Mechanical isolation for high electrical safety
- 2 A output capacity per channel
- LED status indicators for each output
- High flexibility for mixed-voltage systems
- Simple wiring and maintenance
- FA-M3 system compatibility
System Role
The F3YC08-0C acts as the final switching interface between the PLC system and field devices.
Typical Control Architecture
PLC CPU → F3YC08-0C Relay Output Module → Contactors / Solenoids / Lamps / Alarms / Motors
It is typically used where electrical isolation and multi-voltage switching are required.
Industrial Applications
The F3YC08-0C is widely used in:
- Factory automation systems
- Machine control panels
- Conveyor systems
- HVAC control systems
- Pump and valve control
- Alarm and signaling systems
- Packaging machinery
- Process automation
- Power distribution control
- General industrial switching applications
Installation Guidelines
- Install into a compatible FA-M3 base unit
- Ensure power is disconnected before installation
- Use correct terminal wiring for AC/DC loads
- Do not exceed rated load current per channel
- Provide proper surge protection for inductive loads
- Ensure correct grounding for system stability
- Verify output operation before commissioning
Compatible Components
The F3YC08-0C is compatible with:
- FA-M3 CPU Modules
- FA-M3 Base Units
- Power Supply Modules (F3PU series)
- DC Input Modules
- AC Input Modules
- Communication Modules
- Analog I/O Modules
- Other FA-M3 output modules
Alternative Models
| Model | Description |
|---|---|
| F3YC08-0N | 8-point Relay Output Module (shared common) |
| F3YC16-0N | 16-point Relay Output Module |
| F3YD08-6A | Transistor Sink Output Module |
| F3YD08-6B | Transistor Source Output Module |
| F3YA08-2N | TRIAC Output Module (AC loads) |
Advantages
- Supports both AC and DC load switching
- Strong electrical isolation via relay contacts
- Flexible for mixed industrial environments
- Easy integration with FA-M3 PLC systems
- Reliable switching for low-to-medium power loads
- Clear LED diagnostics for each channel
- Simple maintenance and wiring
Frequently Asked Questions
What is the main function of F3YC08-0C?
It switches external devices ON/OFF using relay contacts controlled by the PLC.
What type of loads can it control?
It can control AC and DC loads, including solenoids, relays, lamps, and small motors.
What is the maximum output current?
Each channel supports up to 2 A per point.
Does it provide electrical isolation?
Yes, it uses mechanical relay isolation, separating PLC circuits from field loads.
Where is it commonly used?
It is used in industrial automation, machine control, process systems, HVAC systems, and general electrical switching applications.
Conclusion
The Yokogawa F3YC08-0C Relay Output Module is a flexible and reliable 8-point output solution for FA-M3 PLC systems. With dual AC/DC load capability, mechanical isolation, and robust switching performance, it is ideal for industrial environments requiring safe and versatile output control.
