Yokogawa AFV30D-S41252 Duplexed Field Control Unit Product Introduction The AFV30D-S41252 is a robust duplexed Field Control Unit (FCU) designed for seamless integration with Yokogawa’s CENTUM® VP distr……
Yokogawa AFV30D-S41252 Duplexed Field Control Unit
  • Yokogawa
  • AFV30D-S41252
  • Duplexed Field Control Unit
  • Japan
  • 207 × 265.9 x 482.6 mm
  • 8kg
  • Xiamen, China
  • New & In Stock
  • T/T, PayPal, Western Union
  • 1 Year
  • 1-3 Working Days
  • DHL, UPS, TNT, FedEx and EMS.
  • 24-Hour Service
  • COO
  • 21

Our advantage

Yokogawa AFV30D-S41252 Duplexed Field Control Unit

Global Logistics

We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.

Yokogawa AFV30D-S41252 Duplexed Field Control Unit

Brand new and original

Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.

Yokogawa AFV30D-S41252 Duplexed Field Control Unit

24-hour service

We provide 7*24 hours service to our customers. We will be there whenever you need us.

Yokogawa AFV30D-S41252 Duplexed Field Control Unit

Price advantage

All our products are priced very favorably because we have our own warehouse and supply.


Company Information
E-mail sales@xm-automation.com
Mobile +8613620394314
Whatsapp +8613620394314
WeChat 13620394314

Yokogawa AFV30D-S41252 Duplexed Field Control Unit

Product Introduction

The AFV30D-S41252 is a robust duplexed Field Control Unit (FCU) designed for seamless integration with Yokogawa’s CENTUM® VP distributed control system. Equipped with the LFS1550 control function, it executes complex sequence logic and provides deterministic field I/O management. Dual-redundant CPUs, power supplies, and network interfaces ensure continuous operation even in the event of a component failure. The unit’s steel chassis and vibration-dampening rack mounts guarantee stability and long service life in harsh industrial environments.

Key Applications

Continuous control of refining processes, including fractionation and reactor temperature regulation.

High-speed sequencing for turbine governors, boiler feedwater systems, and auxiliary plant equipment.

Automated pump station coordination, chemical dosing, and valve interlocks in water and wastewater treatment.

Motion control and safety interlocks in pulp and paper lines, including dryer drives and headbox systems.

Batch recipe execution, data logging, and alarm management in pharmaceutical and specialty chemical production.

Brand Overview

Yokogawa stands as a pioneer in industrial automation since 1915. With core strengths in process control, test and measurement, and information solutions, Yokogawa supports critical industries worldwide through rigorous quality standards, innovative R&D, and comprehensive lifecycle services.

Product Advantages

  • Fault-Tolerant Architecture: Redundant CPUs, power modules, and Vnet/IP interfaces with instantaneous switchover protect operations from single-point failures.

  • Expanded I/O Capacity: LFS1550 supports up to 32 field I/O nodes, enabling flexible scaling across large process areas.

  • Rack-Optimized Footprint: At just 4U high and 482.6 mm deep, the unit conserves valuable control room real estate without compromising functionality.

  • High-Speed Communications: Dual-redundant Vnet/IP ports deliver deterministic data exchange and support oversubscription topologies.

  • Enhanced Maintainability: Front-panel LEDs, two dry-contact alarm outputs, and SNMP trap capability enable rapid fault detection and preventive maintenance.

Detailed Technical Parameters

Specification Details
Model Number AFV30D-S41252
Control Function LFS1550 (Field Control Station)
Processor VR5432 @ 133 MHz
Main Memory 64 MB
Power Supply Dual-redundant 24 V DC
Communications Dual-redundant Vnet/IP, FIO interface
Status Contact Outputs 2 points (NC, C); 30 V DC @ 0.3 A
Operating Temperature 0 °C to 55 °C
Storage Temperature –20 °C to 70 °C
Relative Humidity 10 % to 90 % RH (non-condensing)
Dimensions (H × W × D) 207 × 265.9 × 482.6 mm
Weight 8 kg
Rack Mounting 19-inch rack, 4 U; includes 8 × M5 screws

Related Models (Same Series / Function)

Model Description
AFV30S-S41252 Single FCU with LFS1550, dual Vnet/IP & FIO, 19″ rack
AFV30D-S41272 Duplexed FCU variant with enhanced thermal management
AFV40D-A41262 Higher-capacity duplexed FCU with LFS1570 and extra I/O slots
AFV20D-S41252 Mid-range duplexed FCU with LFS1550 for moderate node counts
AFV10D-S41401 Entry-level duplexed FCU with LFS1500 for smaller installations

Popular Yokogawa FCU Models (Same Brand)

Model Key Features
A2FV50S Single FCU, Vnet/IP & N-IO/FIO, rack-mount
A2FV50D Duplexed FCU, Vnet/IP & N-IO/FIO, rack-mount
A2FV70S RIO-upgrade single FCU, rack-mount
A2FV70D RIO-upgrade duplexed FCU, rack-mount
AFV40S Single FCU with cabinet, Vnet/IP & FIO


Frequently Asked Questions (FAQ)

Q: How does the AFV30D-S41252 achieve continuous operation?
A: It uses redundant CPUs, dual power modules, and duplicated Vnet/IP ports with automatic switchover to prevent downtime.

Q: Which license is required to enable the control function?
A: The LFS1550 Control Function license must be ordered to activate sequence logic and I/O management.

Q: What is the maximum number of field I/O nodes supported?
A: Up to 32 I/O nodes can be attached, supporting as many as 512 discrete or analog points.

Q: Can firmware be updated without powering down the unit?
A: Yes, firmware images can be uploaded over the network and applied without interrupting operations.

Q: What maintenance indicators are provided?
A: Front-panel LEDs, two dry-contact alarm outputs, and SNMP traps over Vnet/IP notify operators of fault conditions.

Q: Is a 48 V DC power variant available?
A: Yes, a 48 V DC option (suffix code “B”) is offered for telecom and offshore applications.

Q: What environmental standards does this FCU meet?
A: It complies with IEC 60068 for temperature, humidity, and vibration resistance to withstand industrial conditions.

Q: How is the unit mounted in the rack?
A: It ships with eight M5 rack screws and insulating bushes for secure 19″ rack installation.

Q: What is the MTBF under normal operating conditions?
A: The mean time between failures exceeds 100 000 hours when operated within specified limits.

Q: Can different FCU types be mixed in one rack?
A: Yes, AFV30D and AFV30S units share the same form factor and network topology, allowing mixed configurations.
