The Yokogawa AFV10D-S41101 S2 is an advanced DC power supply designed to provide precise, stable, and clean output for a wide range of applications. It belongs to the AFV Series, known for high-accuracy voltage and current control, ideal for laboratories, research, and testing environments. With an output range of 0 to 10 V DC and 1 A of current, this model is built to handle the most demanding tasks that require reliable power sources.
The AFV10D-S41101 S2 stands out for its low ripple, high efficiency, and compact size, making it highly versatile for various industries. Whether you are working with battery simulations, component testing, or automated testing systems, this model offers exceptional performance with excellent accuracy, reducing the chances of errors and improving the overall reliability of the results.
| Parameter | Specification |
|---|---|
| Model | Yokogawa AFV10D-S41101 S2 |
| Output Voltage Range | 0 V to 10 V DC |
| Output Current | 0 A to 1 A |
| Voltage Accuracy | ±0.1% of setting |
| Current Accuracy | ±0.5% of setting |
| Ripple (Noise) | < 1 mVrms |
| Load Regulation | < 0.01% of output |
| Dimensions (L x W x H) | 220 mm x 150 mm x 85 mm |
| Weight | 2.5 kg |
| Power Supply | 100-240 V AC, 50/60 Hz |
| Operating Temperature | 0°C to 40°C |
| Interface | USB, LAN, GPIB |
| Display | LCD 2-line display |
| Protection | Overvoltage, Overcurrent |
| Efficiency | > 90% |
The AFV10D-S41101 S2 is suitable for a wide range of applications where precision DC power is needed:
Battery Simulation: Ideal for testing and simulating battery management systems (BMS), the AFV10D-S41101 S2 provides a stable and adjustable voltage to mimic charging and discharging cycles in electric vehicles (EV), solar systems, and mobile devices.
Component Testing: It is highly effective in component testing such as semiconductors, resistors, capacitors, and other electronic components, where precise voltage and current are essential for accurate analysis.
Power Supply Evaluation: The AFV10D-S41101 S2 is used for evaluating DC power supplies by verifying output performance and ensuring they meet required standards, especially in high-precision applications.
Automated Test Systems (ATS): Integrating the AFV10D-S41101 S2 into automated testing systems for continuous or high-throughput testing is straightforward, enabling remote control for automated sequencing and testing.
Research & Development: Engineers and researchers use the AFV10D-S41101 S2 to test new technologies and develop prototypes, offering flexibility in output settings to match specific testing conditions.
Precision Voltage and Current Control: With an accuracy of ±0.1% for voltage and ±0.5% for current, the AFV10D-S41101 S2 ensures highly accurate testing results, which is crucial for high-precision work.
Compact and Lightweight Design: The AFV10D-S41101 S2 is lightweight (2.5 kg) and compact (220 x 150 x 85 mm), making it easy to place in any workspace and convenient for mobile or field use.
Low Ripple: The device produces less than 1 mVrms ripple, offering clean DC output that minimizes noise, ideal for testing sensitive electronic components or systems that require low-noise power.
High Efficiency: The unit has an efficiency rate of greater than 90%, minimizing energy waste, reducing operating costs, and contributing to environmental sustainability.
Remote Control Capability: The AFV10D-S41101 S2 can be remotely controlled via USB, LAN, or GPIB connections, integrating seamlessly into automated test systems (ATS) for streamlined testing workflows.
Protection Features: Built-in overcurrent protection and overvoltage protection ensure safe operation and safeguard both the unit and the connected devices under test.
Versatile Usage: It is well-suited for various applications, from laboratory experiments and R&D projects to system testing, offering a wide range of voltage and current settings.
LCD Display for Easy Monitoring: The unit features an LCD 2-line display that shows voltage, current, and key operational data, making monitoring and adjustments easier during testing.
Global Compatibility: It supports 100-240 V AC input, allowing it to be used worldwide, making it a flexible choice for both local and international testing requirements.
Reliability: The robust design and high-quality components make the AFV10D-S41101 S2 a durable and reliable power supply, capable of withstanding continuous use over time.
Brand: Yokogawa
Series: AFV Series
The AFV Series is a line of precision DC power supplies developed by Yokogawa to meet the needs of industries requiring stable and reliable DC power for testing, simulation, and research purposes. These power supplies are designed to provide low ripple, high accuracy, and long-term reliability, making them essential tools for component testing, automated systems, and R&D applications.
| Model | Output Voltage Range | Current Output | Ripple (Noise) | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|
| AFV05D-S41101 | 0 V to 5 V DC | 0 A to 1 A | < 1 mVrms | 2.2 kg | 200 x 140 x 85 |
| AFV20D-S41101 | 0 V to 20 V DC | 0 A to 2 A | < 1.5 mVrms | 2.8 kg | 230 x 160 x 90 |
| AFV30D-S41101 | 0 V to 30 V DC | 0 A to 3 A | < 1.5 mVrms | 3.2 kg | 240 x 170 x 95 |
| AFV50D-S41101 | 0 V to 50 V DC | 0 A to 5 A | < 2 mVrms | 3.7 kg | 250 x 180 x 100 |
| AFV100D-S41101 | 0 V to 100 V DC | 0 A to 10 A | < 3 mVrms | 4.5 kg | 300 x 200 x 120 |
| Model | Voltage Range | Current Output | Ripple (Noise) | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|
| Yokogawa PDR200 | 0 V to 20 V DC | 0 A to 2 A | < 1 mVrms | 3.0 kg | 220 x 150 x 90 |
| Yokogawa GS2000 | 0 V to 200 V DC | 0 A to 20 A | < 2.5 mVrms | 6.0 kg | 250 x 180 x 110 |
| Yokogawa ZDS800 | 0 V to 80 V DC | 0 A to 8 A | < 1.5 mVrms | 4.5 kg | 240 x 170 x 100 |
| Yokogawa REX600 | 0 V to 60 V DC | 0 A to 6 A | < 2 mVrms | 4.0 kg | 230 x 160 x 95 |
Q1: What is the maximum output voltage of the Yokogawa AFV10D-S41101 S2?
A1: The maximum output voltage of the Yokogawa AFV10D-S41101 S2 is 10 V DC.
Q2: How accurate is the voltage setting?
A2: The voltage accuracy is ±0.1% of the setting.
Q3: Can I remotely control the AFV10D-S41101 S2?
A3: Yes, the unit supports remote control via USB, LAN, and GPIB.
Q4: What is the ripple (noise) level of this power supply?
A4: The ripple (noise) is less than 1 mVrms, which ensures clean and stable DC output.
Q5: What is the weight of the unit?
A5: The weight of the Yokogawa AFV10D-S41101 S2 is 2.5 kg.
Q6: What kind of protection does the unit have?
A6: The power supply has overvoltage and overcurrent protection to ensure safe operation.
Q7: What are the possible applications of the AFV10D-S41101 S2?
A7: It is ideal for battery simulations, component testing, power supply evaluation, automated test systems, and R&D projects.
Q8: Is this power supply suitable for use in automated test systems?
A8: Yes, it integrates easily into automated test systems (ATS) and offers remote control functionality for automated workflows.
Q9: Can the AFV10D-S41101 S2 be used for both AC and DC applications?
A9: The AFV10D-S41101 S2 is designed for DC applications only, providing stable and precise DC output.
Q10: What is the voltage regulation of the AFV10D-S41101 S2?
A10: The unit provides load regulation of less than 0.01% of the output.
