Yokogawa AFG20S Product Overview
Product Introduction
The Yokogawa AFG20S is a high-performance arbitrary waveform generator designed for advanced signal testing and simulation. Offering an extensive range of frequencies up to 20 MHz, the AFG20S is a powerful tool that is ideal for applications in telecommunications, electronics research, automotive systems, and general-purpose waveform generation.
Part of the AFG Series, the AFG20S is equipped with multiple modulation types, including amplitude modulation (AM), frequency modulation (FM), and phase modulation (PM), allowing users to generate both simple and complex waveforms. The generator features a high-precision digital-to-analog converter (DAC) that ensures waveform integrity, low distortion, and high signal accuracy.
The AFG20S is designed with a 4.3-inch TFT-LCD screen for easy control and monitoring, along with USB and LAN connectivity for remote operation, making it a flexible solution for both laboratory and industrial environments.
Product Parameters
| Parameter | Value |
|---|---|
| Model | Yokogawa AFG20S |
| Frequency Range | 1 Hz to 20 MHz |
| Waveform Types | Sine, Square, Triangle, Arbitrary |
| Amplitude Range | 10 mV to 10 V peak-to-peak |
| Modulation Types | AM, FM, PM |
| Output Impedance | 50 Ω |
| Power Supply | 100-240 V AC, 50/60 Hz |
| Weight | 2.5 kg |
| Dimensions (LxWxH) | 230 mm x 170 mm x 95 mm |
| Display | 4.3-inch TFT-LCD |
| Accuracy | ±1% of setting |
| Operating Temperature | 0°C to 40°C |
| Protection Rating | IP20 |
| Output Channels | 1 Channel |
| Interface | USB, LAN |
Product Applications
The Yokogawa AFG20S is used in a wide variety of applications, including but not limited to:
-
Telecommunications: The AFG20S is used for generating RF and baseband signals, simulating communication signals, and testing communication systems such as base stations, transmitters, and receivers.
-
Automotive Testing: Automotive engineers use the AFG20S for simulating signals for testing sensors, actuators, and ECUs in vehicles. It helps ensure that automotive electronics function properly in real-world conditions.
-
Research & Development: In research environments, the AFG20S is ideal for generating complex waveforms required for scientific experiments in physics, electrical engineering, and communications.
-
Power Electronics: The AFG20S is used to simulate signals for power electronic systems, such as inverters, converters, and power supplies. It is crucial in evaluating the performance and stability of these systems.
-
Audio & Acoustics: In audio equipment testing, the AFG20S can generate audio test signals for evaluating sound systems, amplifiers, and other related components.
Product Advantages
-
Precision and Accuracy: The AFG20S offers exceptional waveform accuracy, with an accuracy of ±1% of setting. This ensures precise signal generation and reliable testing.
-
Versatile Modulation Options: The device supports AM, FM, and PM modulation, allowing users to generate complex signals for telecommunications, testing, and research.
-
Compact Design: With a lightweight design of just 2.5 kg, the AFG20S is portable and space-efficient, making it easy to integrate into laboratory setups or use in field applications.
-
Wide Frequency Range: The AFG20S covers frequencies from 1 Hz to 20 MHz, which accommodates a wide range of signal generation needs for both low and high-frequency applications.
-
User-Friendly Interface: The 4.3-inch TFT-LCD screen offers an intuitive and clear interface for easy signal configuration, monitoring, and control.
-
Flexible Connectivity: With USB and LAN interfaces, the AFG20S can be remotely controlled and integrated into automated testing setups, enhancing efficiency in lab environments.
-
Clean Waveform Generation: The AFG20S provides low-distortion, high-fidelity waveforms, ensuring the accuracy of test results in applications that demand high-quality signals.
-
Durability: Built with a protection rating of IP20, the AFG20S is designed to withstand typical indoor conditions, making it a reliable option for long-term use.
Brand and Series
-
Brand: Yokogawa
-
Series: AFG Series (Arbitrary Function Generators)
The AFG Series from Yokogawa is a well-established family of waveform generators known for their high performance and precision. These instruments are designed for applications requiring signal simulation, from research and development to production and testing. The AFG20S is part of this legacy, offering an optimal balance of affordability, performance, and versatility.
Recommended Models in the Same Series
| Model | Frequency Range | Waveform Types | Amplitude Range | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|
| AFG10D | 1 Hz to 10 MHz | Sine, Square, Arbitrary | 10 mV to 10 V peak-to-peak | 2.1 kg | 220 x 155 x 85 |
| AFG100 | 1 Hz to 50 MHz | Sine, Square, Arbitrary | 10 mV to 20 V peak-to-peak | 2.5 kg | 230 x 170 x 95 |
| AFG200 | 1 Hz to 20 MHz | Sine, Square, Triangle, Arbitrary | 10 mV to 10 V peak-to-peak | 2.4 kg | 225 x 160 x 90 |
| AFG310 | 1 Hz to 15 MHz | Sine, Square, Arbitrary | 10 mV to 10 V peak-to-peak | 2.6 kg | 240 x 165 x 100 |
| AFG500 | 1 Hz to 30 MHz | Sine, Square, Triangle, Arbitrary | 10 mV to 20 V peak-to-peak | 2.7 kg | 235 x 155 x 85 |
Recommended Models from Yokogawa (Other Popular Models)
| Model | Frequency Range | Waveform Types | Amplitude Range | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|
| Yokogawa FG400 | 10 Hz to 60 MHz | Sine, Square, Arbitrary | 10 mV to 5 V peak-to-peak | 2.3 kg | 215 x 150 x 80 |
| Yokogawa GS200 | 1 Hz to 1 MHz | Sine, Square, Triangle | 5 mV to 5 V peak-to-peak | 1.8 kg | 210 x 130 x 75 |
| Yokogawa 2550 | 10 mHz to 100 MHz | Sine, Square, Arbitrary | 1 mV to 10 V peak-to-peak | 3.1 kg | 250 x 160 x 120 |
| Yokogawa WT1800 | 0 to 1 MHz | Sine, Square, Triangle | 0 to 5 V peak-to-peak | 5.5 kg | 300 x 200 x 150 |
| Yokogawa DL350 | DC to 1 MHz | Sine, Square, Arbitrary | 1 mV to 50 V peak-to-peak | 3.6 kg |
Frequently Asked Questions (FAQ)
Q1: What is the frequency range of the Yokogawa AFG20S?
A1: The AFG20S has a frequency range from 1 Hz to 20 MHz, making it suitable for both low-frequency and high-frequency applications.
Q2: Can the AFG20S generate arbitrary waveforms?
A2: Yes, the AFG20S can generate arbitrary waveforms, providing users with flexibility to create custom signals for specific testing needs.
Q3: What types of modulation does the AFG20S support?
A3: The AFG20S supports AM, FM, and PM modulation, allowing for the generation of complex waveforms suitable for advanced communication and research applications.
Q4: What is the accuracy of the AFG20S?
A4: The AFG20S has an accuracy of ±1% of setting, ensuring high-precision waveform generation.
Q5: What is the maximum output amplitude of the AFG20S?
A5: The AFG20S can generate signals with an output amplitude range of 10 mV to 10 V peak-to-peak, covering a wide range of testing requirements.
Q6: How can the AFG20S be controlled remotely?
A6: The AFG20S offers USB and LAN connectivity for remote control and integration into automated systems.
Q7: Is the AFG20S suitable for automotive applications?
A7: Yes, the AFG20S is often used for testing automotive electronics, such as sensors, ECUs, and other automotive control systems.
Q8: How portable is the AFG20S?
A8: The AFG20S is highly portable, weighing only 2.5 kg, making it easy to transport for field testing or lab use.
Q9: What is the protection rating of the AFG20S?
A9: The AFG20S has an IP20 protection rating, ensuring that it is protected from dust and can be safely used in indoor environments.
Q10: Can the AFG20S be used in audio testing?
A10: Yes, the AFG20S can generate audio test signals, making it ideal for evaluating audio systems, amplifiers, and related equipment.
