Product Overview
The Yokogawa ADV551-P50/D5D00 Digital Output Module is a 32-channel discrete output module used in Yokogawa CENTUM Distributed Control Systems (DCS). It is designed to output ON/OFF control signals from the control system to field devices such as relays, solenoids, valves, and indicator lamps.
The D5D00 option is a dual pressure clamp terminal block configuration, which provides enhanced wiring structure and improved connection stability for field installations.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Yokogawa |
| Model | ADV551-P50/D5D00 |
| Product Type | Digital Output Module |
| Function | Discrete signal (ON/OFF) output |
| System Compatibility | CENTUM VP / CENTUM CS 3000 |
| Output Channels | 32 channels |
| Output Type | Transistor (current sink) |
| Signal Type | ON/OFF (binary output) |
| Rated Output Voltage | 24 V DC |
| External Power Supply | 20.4 to 26.4 V DC |
| Output Current | Approx. 100 mA per channel |
| Response Time | ≤ 3 ms |
| Isolation | Channel-to-system isolation |
| Protection | Overcurrent and short-circuit protection |
| Power Supply | 5 V DC (via backplane) |
| Interface Option | D5D00 dual pressure clamp terminal block |
| Mounting Type | Rack-mounted / FIO system base |
| Dimensions (H × W × D) | 107.5 × 130 × 32.8 mm |
| Weight | 0.2 kg |
Function and Working Principle
The ADV551-P50/D5D00 operates as a digital output interface module, converting control system commands into electrical ON/OFF outputs.
Its working process includes:
- Receiving control signals from the DCS controller
- Converting digital logic into transistor switching outputs
- Driving field devices such as relays, solenoids, and indicator lamps
- Providing fast switching response for real-time control
- Ensuring electrical isolation between system and field side
- Supporting stable wiring through dual pressure clamp terminals
This ensures accurate and reliable execution of industrial control signals.
Role in Industrial Control Systems
Within Yokogawa CENTUM architecture, the ADV551-P50/D5D00 functions as a high-density output module responsible for:
- Executing automation control commands
- Driving field actuators and output devices
- Supporting interlock and alarm logic
- Enabling process control execution
- Improving wiring reliability through dual terminal structure
It is a key component in the output execution layer of distributed control systems.
Industrial Applications
The ADV551-P50/D5D00 is widely used in:
- Oil and gas production and refining
- Petrochemical and chemical processing
- Power generation systems
- Water and wastewater treatment
- Industrial automation systems
- Process control environments
It is suitable for applications requiring reliable high-density digital output switching and robust wiring integrity.
Installation and System Integration
For proper operation, the module should be:
- Installed in Yokogawa CENTUM / FIO system racks
- Connected using 24 V DC field wiring
- Integrated with dual pressure clamp terminal architecture (D5D00)
- Properly grounded to reduce electrical noise
- Configured via system engineering tools
- Used in distributed or redundant control systems if required
Correct installation ensures stable long-term performance and reliability.
Compatible System Components
The ADV551-P50/D5D00 typically works with:
- Yokogawa CENTUM controllers
- Field Control Stations (FCS)
- Human Interface Stations (HIS)
- Relays, solenoids, valves, and indicator devices
- Alarm and interlock systems
These components form a complete industrial automation system.
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| Yokogawa ADV551-P50/D5A00 | Digital Output Module | KS cable interface | Simplified wiring |
| Yokogawa ADV551-P50/D5S00 | Digital Output Module | Single clamp terminal | Standard wiring |
| Yokogawa ADV551-P13 S2 | Digital Output Module | High reliability revision | Process control |
| Yokogawa ADV551-DO32 | Digital Output Module | Basic configuration | General automation |
| Yokogawa ADV551-P63 | Digital Output Module | Enhanced version | Critical systems |
Key Advantages
- 32-channel high-density output capability
- Stable transistor switching performance
- Fast response time for real-time control
- Dual pressure clamp terminal structure (D5D00)
- Strong electrical isolation for system safety
- Reliable wiring stability in industrial environments
- Seamless integration with Yokogawa systems
Technical FAQs
Q1: What is the function of ADV551-P50/D5D00?
It outputs ON/OFF control signals from the system to field devices.
Q2: How many channels does it support?
It supports 32 digital output channels.
Q3: What is the D5D00 option?
It is a dual pressure clamp terminal block used for secure and stable wiring.
Q4: What type of output does it use?
It uses transistor-based current sink output.
Q5: Where is it commonly used?
It is widely used in industrial automation systems requiring reliable output control.
Conclusion
The Yokogawa ADV551-P50/D5D00 Digital Output Module is a robust and high-density output solution designed for industrial control systems. With stable switching performance, reliable dual-terminal wiring, and fast response, it ensures efficient and accurate execution of control signals in distributed automation environments.
