Product Overview: AAI835‑S00/K4A00
Product Parameters
| Parameter | Specification |
|---|---|
| Power Supply | 24 V DC; typical current draw ~320 mA; maximum ~360 mA |
| Input Signal | Single 4–20 mA two‑wire current‑loop input |
| Output Signal | SPDT relay (5 A at 250 V AC max) |
| Display | 5‑digit 7‑segment LED numeric readout |
| Accuracy | ±0.1 % of full scale; resolution 0.01 mA |
| Response Time | Approx. 200 ms to reach 90 % of a step change |
| Temperature Range | Operating: –10 °C to +55 °C; Storage: –25 °C to +70 °C |
| Protection Rating | IP front bezel rating: IP65 (dust‑tight, splashproof) |
| Calibration Method | Simple zero/span calibration via front-panel keys |
| Connection Interface | Rack-mounted modular K4 interface |
| Dimensions | 48 mm (W) × 96 mm (H) × 110 mm (D) |
| Weight (kg) | 0.40 kg |
Product Introduction
The AAI835‑S00/K4A00 is a compact, modular panel indicator designed to fit into rack-based distributed I/O systems via the K4 interface. Tailored for precise monitoring of a single 4–20 mA current‑loop signal, it offers a clear 5‑digit LED display and a relay output for alarm or control integration. Its slim profile, robust IP65 front, and easy calibration make it ideal for modern automation and control environments.
Applications
This module is well-suited for:
-
Monitoring individual process signals within modular control rack systems
-
Triggering alarms or control actions via relay when current thresholds are exceeded
-
Retrofits of old panel meters into modern rack layouts for easy expansion
-
Applications in water treatment, HVAC systems, manufacturing loops, or utilities
-
Situations where remote central control requires local display and relay-driven feedback
Advantages
-
Rack-ready integration — K4 interface enables quick plug-in of the module into standard backplanes.
-
High readability — A crisp 5‑digit LED ensures process values are easy to read from a distance.
-
Simple calibration — Front-panel zero/span keys allow fast adjustments without tools.
-
Robust front panel — IP65-rated bezel offers protection from dust and water ingress.
-
Compact and lightweight — Small dimensions and 0.40 kg weight make for efficient panel use.
Brand & Series
-
Brand: A renowned maker of industrial instrumentation, respected for reliable analog indicators and modular equipment.
-
Series: Falls under the AAI835 family, specifically the S‑type subgroup designed for 4–20 mA input with relay output, now adapted for the K4 modular rack standard (K4A00 suffix).
Related & Popular Models
A. Same Series / Related Models
| Model | Input Type | Output Feature | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| AAI835‑S00 S2 | 4–20 mA | SPDT relay | 48 × 96 × 110 | 0.45 |
| AAI835‑S00 M2 | 4–20 mA | Retransmit 4–20 mA | 48 × 96 × 110 | 0.50 |
| AAI835‑H00 S2 | 4–20 mA | SPDT relay (H-series) | 48 × 96 × 110 | 0.45 |
| AAI835‑S00 S3 | 0–10 V | SPST relay + analog output | 48 × 96 × 110 | 0.45 |
| AAI835‑S00 D0 | Dual 4–20 mA loops | Dual relay outputs | 96 × 96 × 110 | 0.75 |
B. Other Popular Models from the Same Brand
| Model | Notable Feature | Typical Use Case | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| AAA990‑C01 | LCD display with alarms | Operator interface | 96 × 48 × 100 | 0.55 |
| ABX770‑B22 | Touch-panel universal input | Process visual control | 144 × 144 × 60 | 0.90 |
| ACC510‑A05 | Compact scrolling LED | Flow meter display | 48 × 48 × 70 | 0.30 |
| ASS310‑D10 | Hand‑held thermocouple module | Portable readout & logging | 160 × 80 × 30 | 0.40 |
| AVP200‑E20 | Ethernet-enabled panel display | Advanced networked control | 192 × 96 × 50 | 1.20 |
Frequently Asked Questions (QA Format)
-
Q: What does the AAI835‑S00/K4A00 measure?
A: It measures a single 4–20 mA two‑wire current‑loop input. -
Q: How accurate is it?
A: It offers high accuracy at ±0.1 % of full scale, with 0.01 mA resolution. -
Q: What output does it provide?
A: It provides a SPDT relay output rated at 5 A and 250 V AC. -
Q: What display does it use?
A: It features a 5‑digit, 7‑segment LED display for numerical feedback. -
Q: How durable is its front panel?
A: The front CPU bezel is rated IP65—resistant to dust and splashing liquids. -
Q: How do you calibrate the unit?
A: Front-panel keys allow direct zero and span calibration without external tools. -
Q: How is it mounted?
A: It mounts via a K4 rack interface, ideal for modular control systems. -
Q: What are its dimensions?
A: Clearly compact at 48 mm wide, 96 mm tall, and 110 mm deep. -
Q: What is its weight?
A: Light at approximately 0.40 kg. -
Q: What does “K4A00” indicate in the model?
A: It denotes the rack-compatible K4 interface variant for convenient plug-in deployment.
