Product Overview: Yokogawa AAI543‑S50 S1
The AAI543‑S50 S1 is a precision analog output module designed for industrial DCS environments like CENTUM CS3000 and VP systems. It delivers reliable 4–20 mA output signals across 16 isolated channels, ensuring accurate control of field devices such as valves, actuators, and transducers. Engineered for robustness, this module supports redundant configurations, diagnostic functions, and maintains high performance in challenging industrial conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAI543‑S50 S1 |
| Function | 16-channel analog output (4–20 mA) |
| Output Range | 4–20 mA, user-configurable |
| Resolution | 16‑bit D/A |
| Accuracy | ±0.1 % of full‑scale output |
| Max Load Resistance | Up to 600 Ω |
| Isolation | Galvanic, channel-to-channel and channel-to-system |
| Power Supply | 24 V DC nominal |
| Power Consumption | ~5 W |
| Operating Temperature | –10 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | 10 % to 95 % RH, non-condensing |
| Mounting | DIN-rail or panel mount |
| Dimensions (W × H × D) | 107.5 × 32.8 × 130 mm |
| Weight | 0.4 kg |
Product Applications
-
Precise analog control of field devices (valves, actuators, transmitters)
-
DCS-based control systems in chemical, petrochemical, power generation, and water treatment industries
-
Redundant control system configurations requiring fast switchover
-
Panels where space efficiency and diagnostic capabilities matter
-
Environments demanding durable and accurate analog output modules
Product Advantages
-
High channel density: 16 analog output channels in a compact module
-
Exceptional accuracy: 16-bit resolution and ±0.1 % precision
-
Reliable electrical isolation: Enhances signal integrity and safety
-
Low power consumption: Around 5 W, efficient for dense installations
-
Wide environmental tolerance: Operates in –10° to +60 °C and high humidity conditions
-
Flexible mounting and hot-swapping: Supports DIN-rail or panel mounting, allows easy replacement
Related or Similar Models (Same Series)
| Model | Output Type | HART | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| AAI543‑S50 S1 | 4–20 mA, 16‑ch | No | 107.5 × 32.8 × 130 | 0.4 |
| AAI543‑H50 S1 | 4–20 mA, 16‑ch | Yes | 107.5 × 32.8 × 130 | 0.4 |
| AAI543‑H53 S1 | 4–20 mA/1–5 V, 16‑ch | Yes | 107.5 × 32.8 × 130 | ~0.32 |
| AAI543‑H50 A4S00 | 4–20 mA, 16‑ch | Yes | 107.5 × 32.8 × 130 | 0.4 |
| AAI543‑S53 S1 | 4–20 mA, 16‑ch | No | 107.5 × 32.8 × 130 | 0.4 |
Popular Yokogawa Models
| Model | Function | Channels | Signal Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| AAI543‑S50 S1 | Analog Output Module | 16 | 4–20 mA | 107.5 × 32.8 × 130 | 0.4 |
| AAI543‑H50 S1 | Analog Output w/ HART | 16 | 4–20 mA + HART | 107.5 × 32.8 × 130 | 0.4 |
| AAI141‑S00 | Analog Input Module | 8 | 4–20 mA | 107.5 × 32.8 × 130 | ~0.2 |
| AAV542 | Voltage Output Module | 16 | –10 to +10 V | 107.5 × 32.8 × 130 | ~0.2 |
| AAI143‑S50 | Analog Input Module | 16 | 4–20 mA | 107.5 × 32.8 × 130 | ~0.3 |
Frequently Asked Questions (QA)
Q1: What is the primary function of the AAI543‑S50 S1 module?
A1: It provides 16 isolated analog output channels (4–20 mA) for precise field device control.
Q2: Does it support digital communication such as HART?
A2: No, the S50 S1 model does not include HART support.
Q3: What is the maximum load resistance it can drive?
A3: It can drive up to 600 Ω per channel.
Q4: How accurate is the analog output?
A4: Output accuracy is ±0.1 % of full-scale.
Q5: Can it be mounted on a DIN rail?
A5: Yes, it supports DIN-rail and panel mounting configurations.
Q6: What is its environmental operating range?
A6: Operates from –10 °C to +60 °C and tolerates up to 95 % non-condensing humidity.
Q7: Is it hot‑swappable?
A7: Yes, the module is hot‑swappable, allowing maintenance without system shutdown.
Q8: What is the power consumption?
A8: Approximately 5 W during operation.
Q9: Does it offer electrical isolation?
A9: Yes, it provides galvanic isolation between channels and against system backplane.
Q10: What are its dimensions and weight?
A10: It measures 107.5 × 32.8 × 130 mm and weighs around 0.4 kg.
