🧾 Product Overview: Yokogawa AAI543-H10
The Yokogawa AAI543-H10 is an analog input module designed for use in distributed control systems (DCS), particularly within the CENTUM CS 3000 and VP series control systems. It is primarily used to receive analog signals such as 4–20 mA from field transmitters and convert them into digital data for processing by the control system.
With high input resolution, galvanic isolation, and HART protocol support, the AAI543-H10 module ensures accurate data acquisition and robust performance even in demanding industrial environments. It is a highly reliable module designed for industries such as oil and gas, chemical, power generation, and water treatment.
📐 Technical Parameters
| Parameter | Specification |
|---|---|
| Model | AAI543-H10 |
| Part Number | AAI543-H10 |
| Input Type | Analog Input |
| Signal Type | 4–20 mA DC (HART compatible) |
| Number of Channels | 16 channels |
| Communication Protocol | HART |
| Input Resolution | 16 bits |
| Isolation | Channel-to-channel and channel-to-ground |
| Power Supply | Supplied via base plate (from node) |
| Operating Temperature Range | –20°C to +70°C |
| Storage Temperature Range | –40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Mounting Type | Mounted on baseplate |
| Module Type | Low-Power (High-density I/O) |
| Dimensions (W × H × D) | 27.2 mm × 130 mm × 160 mm |
| Weight | 0.25 kg |
🏭 Product Applications
-
Process Control Systems in industries such as oil refining, gas processing, and chemical manufacturing
-
Utility Monitoring in power plants and water treatment facilities
-
Data Acquisition from analog sensors such as pressure, temperature, and flow transmitters
-
Instrumentation Integration in hazardous or remote environments
-
Industrial Automation requiring HART-enabled device communication
✅ Product Advantages
-
HART Compatibility: Enables digital communication over analog wiring
-
High Channel Density: 16 input channels save space and simplify wiring
-
Reliable Isolation: Ensures safety and signal integrity across channels
-
High Accuracy: 16-bit resolution provides precise measurements
-
Wide Temperature Range: Built to operate in rugged industrial conditions
-
Modular Design: Allows easy installation and replacement without system shutdown
🏷️ Brand and Series Information
-
Brand: Yokogawa
-
Series: CENTUM CS 3000 / VP System
-
Product Family: Analog Input I/O Modules
-
Target Use: Integration into process control and instrumentation systems
🔁 Recommended Related Models (Same or Related Series)
| Model | Type | Channels | Signal Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| AAI543-H10 | Analog Input | 16 | 4–20 mA + HART | 27.2 × 130 × 160 | 0.25 |
| AAI141-H00 | Analog Input | 8 | 1–5 V | 27.2 × 130 × 160 | 0.25 |
| AAI841-H00 | Analog Output | 8 | 4–20 mA | 27.2 × 130 × 160 | 0.25 |
| ADV151-P00 | Digital Input | 32 | 24 VDC | 27.2 × 130 × 160 | 0.24 |
| AAM50-S1 | Remote I/O Communication | N/A | N/A | 40 × 130 × 160 | 0.30 |
| AFV10D-S00 | Power Supply Module | N/A | N/A | 50 × 130 × 160 | 0.45 |
🌟 Popular Yokogawa Models
| Model | Function | System Application | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| AAI543-H10 | 16-Channel Analog Input | CS 3000 / VP Systems | 27.2 × 130 × 160 | 0.25 |
| AAR181-S50 | Remote Terminal Unit | SCADA / RTU | 40 × 130 × 160 | 0.32 |
| ATK4A-00 | Control Card | Turbine Control | 60 × 130 × 180 | 0.40 |
| AMN11 | Communication Interface | Vnet/IP, Fieldbus | 50 × 130 × 160 | 0.35 |
| ANB10D-420 | Baseplate Unit | For AAI / ADV Modules | 120 × 130 × 30 | 0.90 |
❓ Frequently Asked Questions (FAQ)
Q1: What type of signals does the AAI543-H10 module accept?
A1: It accepts 4–20 mA analog input signals and supports HART communication protocol.
Q2: How many channels are available in this module?
A2: The module supports 16 independent analog input channels.
Q3: Does it support signal isolation?
A3: Yes, the module provides channel-to-channel and channel-to-ground isolation for safety and noise reduction.
Q4: Is it compatible with digital transmitters?
A4: Yes, through HART protocol, it can communicate with smart transmitters over the same 4–20 mA line.
Q5: Can it be hot-swapped during operation?
A5: No, modules should be powered down before removal or installation to avoid system faults.
Q6: What is the input resolution of the AAI543-H10?
A6: The module provides 16-bit resolution for high-precision signal processing.
Q7: What systems can this module be used with?
A7: It is designed for integration with Yokogawa’s CENTUM CS 3000 and VP DCS platforms.
Q8: How is the module installed?
A8: It is mounted onto a compatible baseplate and connected via system backplane.
Q9: Is it suitable for hazardous environments?
A9: Yes, with appropriate housing and certifications, it can be used in hazardous zones.
Q10: How much does the AAI543-H10 weigh?
A10: The module weighs approximately 0.25 kg.
