Product Introduction – Yokogawa AAI543-H00/K4S00
The Yokogawa AAI543-H00/K4S00 is a high-precision analog output module designed for complex industrial automation and process control systems. Part of the AAI543 series, this module offers 16 independent, isolated 4–20 mA analog output channels, designed to interface between digital control systems (such as DCS or PLC) and field devices like valves, actuators, and converters.
The K4S00 suffix indicates a specific configuration of the terminal block: a removable terminal structure, enhancing installation flexibility, especially for applications requiring frequent maintenance or modular replacement. Combined with its electrical isolation and high update rate, this module is ideal for high-performance, high-reliability applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | AAI543-H00/K4S00 |
| Output Type | Analog 4–20 mA |
| Number of Channels | 16 (individually isolated) |
| Output Load Resistance | 0–750 Ω |
| Circuit Open Detection | < 0.65 mA |
| Accuracy | ±48 µA |
| Update Rate | 10 ms |
| Temperature Drift | ±16 µA / 10°C |
| Withstand Voltage | 1500 V AC (1 minute, output to system) |
| HART Support | Yes |
| Current Consumption (5 V DC) | 230 mA |
| Current Consumption (24 V DC) | 540 mA |
| Terminal Block Type | Removable screw terminal (K4S00) |
| Mounting | Base-mount |
| Dimensions (W x H x D) | 27 mm × 130 mm × 110 mm |
| Weight | 0.42 kg |
Applications
-
Power Generation Systems – For driving control valves and analog actuators in turbine systems.
-
Petrochemical Industry – Manages continuous analog control in hazardous or complex processes.
-
Pharmaceutical Manufacturing – Supports sterile process control through precise signal transmission.
-
Water & Wastewater Treatment – Used in SCADA and DCS to control pumps, valves, and dosing units.
-
Food & Beverage Automation – Ensures high-fidelity signal output in sanitary-controlled environments.
Key Advantages
-
✅ Modular Terminal Design (K4S00): The removable terminal structure allows for easy maintenance and module replacement without rewiring.
-
✅ Channel-to-Channel Isolation: Each analog output is electrically isolated to prevent crosstalk or interference.
-
✅ Surge Resistance and Durability: Designed for challenging environments with high transient voltages.
-
✅ Fast Data Refresh Rate: A 10 ms update time guarantees real-time control responsiveness.
-
✅ Compact and Lightweight: Slim profile and lightweight body reduce panel space consumption.
-
✅ Full HART Compatibility: Supports diagnostics and calibration via the HART protocol.
Brand and Series
-
Brand: Yokogawa
-
Series: AAI543 (Analog Output Module Series)
5 Related Models (Same or Compatible Series)
| Model | Description | Channels | HART | Terminal Type |
|---|---|---|---|---|
| AAI543-S00 | Standard analog output module | 16 | No | Fixed screw terminal |
| AAI543-H50 | Analog output with HART and enhanced voltage | 16 | Yes | Pressure clamp |
| AAI543-S50 | Analog output with basic HART functionality | 16 | Yes | Fixed screw terminal |
| AAI543-H53 | HART output with wide temperature range | 16 | Yes | Removable terminal |
| AAI543-H00/A4S10 | Analog output with surge-protected terminal block | 16 | Yes | Pressure clamp + absorber |
5 Popular Yokogawa Models (Different Functions)
| Model | Function | Channels | Special Feature |
|---|---|---|---|
| AAI143-H00 | Analog Input Module | 16 | High-accuracy isolated input |
| ADV151-P00 | Digital Output Module | 32 | Fast switching performance |
| ATD5A-00 | Thermocouple Input Module | 8 | Supports multiple sensor types |
| AAR181-S00 | Remote I/O Communication | – | Integrates external signals |
| AFV10D-S00 | Field Control Station Node | – | Core CPU module for DCS |
Top 10 FAQ (Q&A Format)
Q1: What type of signals does the AAI543-H00/K4S00 output?
A1: It outputs 4–20 mA analog current signals for controlling field devices like actuators and valves.
Q2: How many channels are provided in this model?
A2: It offers 16 independent, electrically isolated output channels.
Q3: What does the K4S00 designation mean?
A3: It indicates a removable screw terminal block configuration, allowing easier field wiring and maintenance.
Q4: Is this module compatible with the HART communication protocol?
A4: Yes, it fully supports HART communication for two-way diagnostics and field device configuration.
Q5: What is the update time of the module?
A5: The output refreshes every 10 milliseconds for real-time performance.
Q6: Can this module be used in hazardous areas?
A6: It is designed for industrial environments and can be used in certified enclosures in hazardous areas.
Q7: How much space does the module occupy?
A7: It measures 27 mm in width, 130 mm in height, and 110 mm in depth, fitting compactly into standard cabinets.
Q8: How accurate is the current output?
A8: It provides high precision with an accuracy of ±48 µA.
Q9: Does it offer protection against surges?
A9: Yes, while the K4S00 variant focuses on modular terminals, internal circuits are designed to handle electrical surges reliably.
Q10: What is the weight of this module?
A10: The module weighs approximately 0.42 kilograms.
