Yokogawa AAI135-H00 Analog Input Module
Product Overview:
The Yokogawa AAI135-H00 is an analog input module designed for use in industrial automation systems, specifically within the CENTUM-ST series. This module is capable of receiving 4 to 20 mA current loop input signals and features eight independent input channels. With its high accuracy, excellent isolation, and fast data update rates, the AAI135-H00 ensures that it meets the rigorous demands of modern process control systems.
The module is engineered to provide reliable and high-precision measurements, making it ideal for integration into process monitoring, control systems, and data acquisition applications.
Product Parameters:
| Parameter | Description |
|---|---|
| Model | AAI135-H00 |
| Series | CENTUM-ST Series |
| Input Channels | 8 independent input channels |
| Signal Type | 4 to 20 mA current loop input signal |
| Voltage Isolation | High voltage isolation between input and system, ensuring safety |
| Input Resistance | Varies based on current intensity (see manual for detailed specs) |
| Accuracy | ±16 µA |
| Data Update Time | 10 milliseconds |
| Transmitter Power | Provides power to 2-wire transmitters |
| Temperature Drift | Minimal drift due to temperature changes |
| Maximum Current Consumption | 360 mA at 5 V DC, 450 mA at 24 V DC |
| Weight | 0.3 kg |
| External Connections | Pressure clamp terminals, MIL connectors, or KS1 specialized cable |
| HART Communication | Supported (available in certain configurations) |
| Dimensions | 107.5 × 32.8 × 130 mm |
| Brand | Yokogawa |
| Product Type | Analog Input Module |
| Country of Origin | Japan |
Product Applications:
The AAI135-H00 module is versatile and widely used in various industrial automation applications, including but not limited to:
- Process Control Systems: Used to monitor and control key parameters in industrial processes.
- Data Acquisition and Monitoring: Collects real-time data for analysis and monitoring.
- Equipment Monitoring and Diagnostics: Detects equipment status and provides diagnostic information.
- Industrial Automation Systems: Integrates into automation systems to facilitate automatic control and optimization.
- Remote Monitoring and Control: Supports HART protocol for remote access and control.
Product Advantages:
- High Accuracy: Provides ±16 µA measurement accuracy, ensuring precise data capture.
- High Voltage Isolation: Features robust isolation between input and system to enhance safety.
- Fast Data Updates: Offers a 10-millisecond data update time, catering to high-speed data processing needs.
- Transmitter Power Supply: Supplies power to connected 2-wire transmitters, simplifying wiring.
- Minimal Temperature Drift: Ensures stable performance under varying temperature conditions.
- HART Protocol Support: Enables communication with other HART-compliant devices for advanced diagnostics.
Recommended Models in the Same Series or Related:
| Model | Description | Input Channels | HART Communication |
|---|---|---|---|
| AAI135-H01 | 8-channel analog input module with HART communication for diagnostics | 8 | Yes |
| AAI115-H00 | 4-channel analog input module for basic applications | 4 | No |
| AAI145 | 16-channel analog input module with redundancy for critical applications | 16 | Yes |
| AAI145-H00 | 16-channel analog input module with HART communication | 16 | Yes |
| AAI135 | Standard 8-channel analog input module for general applications | 8 | No |
Popular Models from Yokogawa:
| Model | Description | Input Channels | HART Communication |
|---|---|---|---|
| Yokogawa AAI143 | 4-channel analog input module with high-precision measurements | 4 | Yes |
| Yokogawa AAI115 | 4-channel analog input module for basic functionality | 4 | No |
| Yokogawa AAI145 | 16-channel analog input module with redundancy | 16 | Yes |
| Yokogawa AAI135 | 8-channel analog input module for general use | 8 | No |
| Yokogawa AAI143-H00 | 4-channel analog input module with HART for advanced diagnostics | 4 | Yes |
Frequently Asked Questions (FAQ):
-
Q: What is the input signal type for the AAI135-H00 module?
- A: The AAI135-H00 accepts 4 to 20 mA current loop signals.
-
Q: How many input channels does the AAI135-H00 module have?
- A: It has 8 independent input channels.
-
Q: Does the AAI135-H00 module support HART communication?
- A: Some configurations of the AAI135-H00 support HART communication for advanced diagnostics.
-
Q: What is the accuracy of the AAI135-H00 module?
- A: The module offers an accuracy of ±16 µA.
-
Q: What is the data update rate of the AAI135-H00?
- A: The data update rate is 10 milliseconds.
-
Q: What is the power consumption of the AAI135-H00?
- A: It consumes 360 mA at 5 V DC and 450 mA at 24 V DC.
-
Q: What is the size of the AAI135-H00 module?
- A: The dimensions are 107.5 × 32.8 × 130 mm.
-
Q: Is the AAI135-H00 module suitable for high-temperature environments?
- A: Yes, the module is designed to perform well in a wide range of temperatures with minimal drift.
-
Q: Can the AAI135-H00 module provide power to connected transmitters?
- A: Yes, it can provide power to 2-wire transmitters.
-
Q: Where is the AAI135-H00 module manufactured?
- A: The module is manufactured in Japan.
