Product Overview
The Woodward 8200-1302 is a compact digital turbine controller with integrated display. It provides control, monitoring, and protection for steam and small industrial turbines in a compact footprint, making it suitable for limited-space installations.
This controller is commonly used in industrial plants and small power generation systems where both control precision and on-device status monitoring are required.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Woodward |
| Model | 8200-1302 |
| Product Type | Compact Digital Controller with Display |
| System Compatibility | Steam turbines, small industrial turbines |
| Function | Turbine control, monitoring, and protection |
| Control Logic | Embedded PID and sequence logic |
| Display | Integrated LCD for real-time monitoring |
| Communication Interfaces | Serial (RS-232/RS-485), optional Ethernet |
| Inputs | Analog and discrete turbine signals |
| Outputs | Actuator control, alarms, protection trips |
| Indicators | On-device LCD and status LEDs |
| Power Supply | 24 VDC |
| Dimensions | 220 × 127 × 80 mm |
| Weight | 1.8 kg |
| Mounting | Panel or compact enclosure mounting |
Function and Working Principle
The 8200-1302 operates as a standalone compact turbine controller, providing:
- Start-up sequencing and shutdown management
- Speed and load regulation through PID control
- Real-time monitoring of key turbine parameters via LCD
- Protection functions including overspeed and emergency trips
- Communication with external systems for remote monitoring
The embedded display allows operators to monitor turbine performance and system status directly at the controller, reducing dependency on external SCADA interfaces.
Role in Industrial Control Systems
The 8200-1302 serves as:
- A primary control and protection unit for small steam or industrial turbines
- A local monitoring interface via integrated display
- A data interface for plant control systems via serial or Ethernet
- A compact and reliable solution for limited-space installations
Industrial Applications
- Small steam turbine plants
- Industrial process turbines
- Combined heat and power (CHP) systems
- Compact power generation units
- Pump or compressor driven turbine systems
- Local turbine monitoring with on-device display
Installation and System Integration
- Mount on a control panel or compact enclosure
- Connect turbine analog and discrete I/O signals
- Connect 24 VDC power supply
- Configure control parameters via built-in display or external software
- Test turbine control and protection functions during commissioning
Compatible System Components
- Analog and discrete I/O modules compatible with 8200 series
- Remote monitoring units or SCADA systems (optional)
- Actuator interfaces for turbine valves
- Safety interlocks and field sensors
Recommended Alternative Models
| Model | Product Type | Key Feature | Application |
|---|---|---|---|
| 8200-1302 | Compact Digital Controller | Integrated LCD display | Small steam or industrial turbines |
| 8200-1300 | Digital Steam Turbine Controller | Full-size controller | Medium to large turbines |
| 5503-335 | MicroNet 5200 CPU Module | Distributed system controller | Turbine & process control |
| 8200-1200 | Digital Turbine Controller | Smaller turbine alternative | Steam turbine systems |
Key Advantages
- Compact design for limited-space installations
- Integrated LCD display for real-time monitoring
- Digital PID-based control for speed and load regulation
- Built-in protection and emergency trip functions
- Supports serial and optional Ethernet communication
- Easy installation and configuration
- Suitable for continuous industrial operation
- Reduces need for external monitoring interfaces
Technical FAQs
Q1: What turbines is the 8200-1302 suited for?
Small steam turbines or industrial process turbines.
Q2: Does it provide local monitoring?
Yes, via integrated LCD display and status LEDs.
Q3: Can it communicate with SCADA or DCS?
Yes, through serial or optional Ethernet interfaces.
Q4: What protection functions does it provide?
Overspeed protection, emergency trip, and turbine safety interlocks.
Conclusion
The Woodward 8200-1302 Compact With Display Controller is a versatile, compact turbine controller that combines control, protection, and local monitoring in a single unit. Its compact size, integrated display, and reliable digital control make it ideal for small steam turbines and industrial process applications.
