Product Overview
The Woodward 5503-335 MicroNet 5200 CPU Module is a central processing unit module used in the Woodward MicroNet 5200 distributed control system architecture. It serves as the main controller of the system, executing real-time control logic, managing I/O modules, and coordinating communication between system components in industrial automation environments.
It is designed for high-reliability applications such as turbines, compressors, and power generation systems where continuous deterministic control is required.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Woodward |
| Model | 5503-335 |
| Product Type | MicroNet 5200 CPU Module |
| System Compatibility | MicroNet 5200 / MicroNet Plus |
| Function | Central processing unit (system controller) |
| Processor | Embedded industrial CPU (RISC architecture) |
| Memory | 64 MB Flash / 128 MB RAM |
| Communication Interfaces | Ethernet, CAN, RTN, serial interfaces |
| Control Architecture | Redundant / simplex system compatible |
| Operating Voltage | 24 VDC (backplane powered) |
| Operating Temperature | 0°C to 55°C |
| Installation Type | Plug-in chassis module |
| Dimensions | 160 × 160 × 120 mm |
| Weight | 1.82 kg |
Function and Working Principle
The 5503-335 CPU module acts as the core processing engine of the MicroNet 5200 system:
- Executes real-time control algorithms (PID, sequencing, protection logic)
- Processes inputs from analog and discrete I/O modules
- Coordinates communication between all system modules
- Manages turbine and compressor control loops
- Handles diagnostics, fault detection, and system monitoring
- Ensures deterministic cycle timing for industrial automation
It continuously runs a control loop:
Input acquisition → logic execution → output update
Role in Industrial Control Systems
Within MicroNet 5200 systems, the 5503-335 is responsible for:
- Serving as the main system controller
- Synchronizing all I/O and communication modules
- Executing safety and shutdown logic
- Supporting distributed control architecture
- Maintaining real-time deterministic performance
- Ensuring stable operation in continuous-duty environments
Industrial Applications
- Gas turbine control systems
- Steam turbine control systems
- Compressor control systems
- Power generation plants
- Oil and gas facilities
- Petrochemical processing plants
- Industrial automation systems
- Critical rotating machinery control
Installation and System Integration
- Install into MicroNet 5200 chassis slot
- Ensure proper backplane connection alignment
- Verify compatibility with I/O and power modules
- Configure system logic via engineering software
- Perform startup diagnostics and loop checks
- Monitor status indicators during commissioning
Compatible System Components
- Analog I/O modules (e.g., 5503-279, 5466-425D)
- Discrete I/O modules (e.g., 5501-469, 5466-258 series)
- Power modules (e.g., 5501-467)
- Communication modules (e.g., 5466-411 Ethernet module)
- Remote chassis transceivers (e.g., 5466-355)
Recommended Alternative Models
| Model | Product Type | Key Feature | Application |
|---|---|---|---|
| 5503-335 | MicroNet 5200 CPU Module | Main system controller | Turbine / industrial control |
| 5501-470 | CPU Module | Alternative MicroNet CPU | Distributed control systems |
| 5466-419 | CPU Processor Module | MicroNet CPU variant | Industrial automation |
| 5466-352 | NetCon CPU Module | Legacy controller CPU | Older systems |
Key Advantages
- High-performance real-time control processing
- Reliable deterministic system execution
- Supports complex turbine and process control logic
- Stable operation in harsh industrial environments
- Seamless integration with MicroNet 5200 architecture
- Supports distributed I/O and communication expansion
- Designed for continuous 24/7 operation
- High reliability for mission-critical systems
Technical FAQs
Q1: What is the main function of the 5503-335?
It is the main CPU that executes control logic and manages the MicroNet 5200 system.
Q2: Is it a standalone controller?
No. It operates as part of a distributed control system with I/O and communication modules.
Q3: What industries use it?
Power generation, oil & gas, turbines, compressors, and industrial automation.
Q4: Is it still in use today?
Yes, mainly in installed base industrial control systems.
Conclusion
The Woodward 5503-335 MicroNet 5200 CPU Module is a core processing unit for industrial automation systems, delivering reliable real-time control, deterministic execution, and seamless system coordination. It is widely used in turbine and process control applications where safety, stability, and continuous operation are essential.
