Schneider TSXAEY1614 Analog Input Module
Product Introduction
The Schneider TSXAEY1614 is a robust and high-performance analog input module designed specifically for the Modicon Premium series. Featuring 16 differential analog input channels, it supports both voltage and current signals, providing flexibility for diverse industrial applications. With 12-bit resolution, this module ensures precise signal conversion, making it ideal for accurate process monitoring and control.
Engineered to deliver reliable operation under harsh industrial environments, the TSXAEY1614 is compact, easy to install via DIN rail, and perfectly compatible with Schneider Electric’s automation systems. Its design emphasizes durability, accuracy, and seamless integration, supporting critical control functions across industries such as manufacturing, chemical processing, and energy management.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | TSXAEY1614 |
| Brand | Schneider Electric |
| Series | Modicon Premium |
| Input Channels | 16 differential analog inputs |
| Input Types | Voltage: 0-10 V, ±10 V; Current: 0-20 mA, ±20 mA |
| Resolution | 12-bit |
| Input Impedance | 10 kΩ |
| Power Supply | 24 V DC |
| Dimensions | 55 x 180 x 260 mm |
| Weight | 0.35 kg |
| Communication Protocol | Modbus/RTU |
| Operating Temperature | -10°C to +60°C |
| Mounting | DIN rail mount |
Product Applications
The TSXAEY1614 analog input module is widely applied in:
-
Industrial automation for precise sensor signal acquisition
-
Process control in chemical, oil & gas, and manufacturing plants
-
Energy management systems requiring accurate analog data
-
Environmental monitoring and data logging systems
-
Integration with Modicon Premium PLCs in complex control architectures
Product Advantages
-
Supports 16 differential analog input channels for comprehensive monitoring
-
Accepts both voltage and current signals, increasing application flexibility
-
High 12-bit resolution enables precise measurement and data accuracy
-
Compact dimensions and light weight simplify installation and reduce panel space
-
Reliable performance under a wide temperature range (-10°C to +60°C)
-
Designed for seamless compatibility with Schneider Electric’s Modicon Premium series
Brand Information
Schneider Electric is a leading global company specializing in energy management and industrial automation solutions. The Modicon Premium series is recognized for its reliability, advanced features, and excellent integration capabilities in industrial control systems.
Related Models (Modicon Premium Series)
| Model Number | Input Channels | Input Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| TSXAEY1600 | 16 | Voltage/Current | 55 x 180 x 260 | 0.34 |
| TSXAEY1602 | 8 | Voltage | 55 x 180 x 260 | 0.30 |
| TSXAEY1616 | 16 | Current | 55 x 180 x 260 | 0.36 |
| TSXAEY1620 | 32 | Voltage/Current | 55 x 180 x 260 | 0.38 |
| TSXAEY1650 | 16 | Thermocouple Inputs | 55 x 180 x 260 | 0.33 |
Popular Models from Schneider Electric
| Model Number | Description | Dimensions (mm) | Weight (kg) |
|---|---|---|---|
| TSXETZ1100 | CPU Module for Modicon Premium | 55 x 180 x 260 | 0.40 |
| TSXPSY1000 | Power Supply Module | 55 x 180 x 260 | 0.50 |
| TSXAEY1640 | Analog Input Module (Voltage) | 55 x 180 x 260 | 0.35 |
| TSXDEY2000 | Digital Input Module | 55 x 180 x 260 | 0.25 |
| TSXETY4100 | Ethernet Communication Module | 55 x 180 x 260 | 0.45 |
FAQ for Schneider TSXAEY1614
Q1: What types of analog inputs does the TSXAEY1614 support?
A1: It supports both voltage inputs (0-10 V, ±10 V) and current inputs (0-20 mA, ±20 mA).
Q2: How many input channels are available on the module?
A2: There are 16 differential analog input channels.
Q3: What is the resolution of the analog signals?
A3: The module offers 12-bit resolution for accurate data conversion.
Q4: What are the physical dimensions and weight of the TSXAEY1614?
A4: The module measures 55 x 180 x 260 mm and weighs 0.35 kg.
Q5: Which communication protocol does this module use?
A5: It uses the Modbus/RTU communication protocol.
Q6: Can this module be used with PLCs outside of the Modicon Premium series?
A6: It is specifically designed for Schneider Electric’s Modicon Premium series and may not be compatible with other PLC brands.
Q7: What is the operating temperature range for this module?
A7: It operates between -10°C and +60°C.
Q8: How is the module mounted?
A8: The TSXAEY1614 is designed for DIN rail mounting.
Q9: What is the input impedance of the module?
A9: The input impedance is 10 kΩ.
Q10: What power supply is required for the TSXAEY1614?
A10: The module requires a 24 V DC power supply.
