Product Overview
Reliable oil filtration is essential for maintaining the lubrication system, internal cleanliness, and operating stability of an industrial air compressor. The Ingersoll Rand 47704433001 / 24900433 Oil Filter is a replacement oil filtration component designed for compatible Ingersoll Rand compressor systems.
The oil filter removes particulate contamination and other debris from the compressor lubricant as oil circulates through the lubrication system. Effective filtration helps protect precision internal components from contamination while supporting stable oil flow and reliable compressor operation.
The 24900433 identification is associated with the oil filter, while 47704433001 is another part identification used for the same replacement component. The supplied product dimensions are 208 × 50 × 95 mm, with a listed weight of approximately 1.36 kg.
For compressor maintenance teams, the oil filter is a routine service component. Replacing it at the appropriate maintenance interval can help prevent excessive contamination from circulating through the compressor’s lubrication circuit.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Ingersoll Rand |
| Model / Part Number | 47704433001 / 24900433 |
| Product Type | Oil Filter |
| Filter Category | Compressor Oil Filter |
| Primary Function | Lubricant filtration |
| Application | Industrial air compressor systems |
| Filtration Medium | Compressor lubrication oil |
| Dimensions | 208 × 50 × 95 mm |
| Weight | Approx. 1.36 kg |
| Installation | Compressor oil filtration circuit |
| Installation Type | Replacement service component |
| Application Environment | Industrial |
| Maintenance Type | Periodic replacement |
| System Function | Removal of contaminants from circulating compressor oil |
| Equipment Type | Compatible Ingersoll Rand compressors |
| Service Purpose | Lubrication-system protection |
Function and Working Principle
The Ingersoll Rand 47704433001 / 24900433 operates as a filtration element within the compressor’s lubrication circuit.
During compressor operation, lubricating oil circulates through the system to perform functions such as lubrication, cooling, and sealing. Before the oil reaches sensitive internal components, it passes through the oil filter.
The basic filtration process can be represented as:
Compressor Oil → Oil Filter → Cleaned Lubricant → Compressor Lubrication Circuit
As the oil passes through the filter media, suspended particles and other contaminants are retained. This helps reduce the quantity of unwanted material circulating through the compressor.
Effective oil filtration can help protect:
- Bearings
- Rotating components
- Oil-injected compressor elements
- Lubrication passages
- Sealing surfaces
- Valves and associated components
- Other oil-dependent internal components
As the filter accumulates contamination, its flow resistance can increase. For this reason, the oil filter should be inspected and replaced according to the maintenance requirements of the specific compressor.
Role in Industrial Air Compressor Systems
The oil filter is an important component of an oil-lubricated compressor’s maintenance system.
Compressor oil is exposed to heat, mechanical operation, and continuous circulation. Over time, contamination can enter the lubrication circuit from several sources, including component wear, degradation products, environmental contamination, and particles generated during operation.
The 47704433001 / 24900433 helps intercept this contamination before it can continue circulating through the lubrication system.
Its role includes:
- Maintaining cleaner compressor lubricant
- Protecting internal lubricated components
- Reducing particulate circulation
- Supporting reliable oil flow
- Helping maintain lubrication-system cleanliness
- Supporting compressor service life
- Contributing to preventive maintenance
- Helping maintain stable compressor operation
An oil filter should therefore be considered a critical consumable component rather than simply an accessory.
Industrial Applications
The Ingersoll Rand 47704433001 / 24900433 can be used in compatible Ingersoll Rand oil-lubricated compressor applications, including industrial compressed-air installations.
Typical environments include:
- Manufacturing plants
- Automotive production
- Metalworking facilities
- Packaging plants
- Industrial workshops
- Process manufacturing
- Assembly facilities
- General factory automation
- Compressor rooms
- Production air systems
- Industrial utility systems
The filter is particularly important in compressor installations that operate continuously or for long periods because lubricant cleanliness becomes increasingly important as operating hours accumulate.
Installation and System Integration
The 47704433001 / 24900433 is installed within the compressor’s oil filtration circuit.
A typical replacement procedure includes:
- Shut down the compressor according to the applicable service procedure.
- Isolate the equipment and allow pressure and temperature to reach safe levels.
- Locate the compressor oil filter assembly.
- Remove the existing oil filter using the appropriate maintenance procedure.
- Inspect the filter housing and surrounding area for contamination or damage.
- Clean the sealing area before installing the replacement filter.
- Install the new 47704433001 / 24900433 filter correctly.
- Ensure the sealing surface is properly seated.
- Restore the compressor to its normal operating configuration.
- Start the compressor and inspect the oil filtration area for leakage.
- Verify normal oil pressure and operating conditions.
The exact replacement procedure depends on the specific compressor model. Maintenance personnel should always use the correct service procedure for the equipment being maintained.
It is also important to use the correct filter specification rather than selecting a replacement solely because it has similar physical dimensions.
Compatible System Components
The Ingersoll Rand 47704433001 / 24900433 oil filter normally works as part of a larger compressor lubrication system.
| Component | Function |
|---|---|
| Compressor Oil Separator | Separates lubricant from compressed air in oil-injected compressor systems |
| Oil Cooler | Removes heat from circulating compressor oil |
| Oil Filter Housing | Holds and directs oil through the filter |
| Compressor Oil | Provides lubrication, cooling, and sealing functions |
| Oil Circuit | Circulates lubricant through the compressor |
| Thermostatic Valve | Helps regulate oil temperature where applicable |
| Compressor Element | Generates compressed air and relies on proper lubrication |
| Oil Separator System | Supports lubricant recovery and circulation |
| Compressor Controller | Monitors and controls compressor operation |
The exact combination of components depends on the specific Ingersoll Rand compressor model and lubrication architecture.
Recommended Alternative Models
The following models and filter families may be considered when evaluating replacement options for compatible compressor systems. They should not automatically be treated as direct substitutes because filtration characteristics, dimensions, connection configuration, and compressor compatibility must be verified.
| Model | Type | Key Feature | Application |
|---|---|---|---|
| 47704433001 / 24900433 | Oil Filter | Compressor lubrication filtration | Compatible Ingersoll Rand systems |
| 39831888 | Oil Filter | Industrial compressor oil filtration | Selected compressor applications |
| 54601513 | Oil Filter | Compressor lubricant filtration | Compatible Ingersoll Rand equipment |
| 42841239 | Oil Filter | Replacement oil filtration component | Industrial compressor systems |
| Ingersoll Rand OEM Oil Filter Series | Oil Filter | Application-specific filtration | Compressor maintenance |
The 47704433001 / 24900433 should remain the preferred replacement when it is identified as the correct filter for the compressor being serviced. Alternative filter numbers should only be selected after confirming equipment compatibility.
Key Advantages
- Designed for compatible Ingersoll Rand compressor systems
- Provides filtration of circulating compressor oil
- Helps reduce particulate contamination in the lubrication circuit
- Supports cleaner compressor lubricant
- Helps protect oil-lubricated internal components
- Supports reliable compressor operation
- Suitable for preventive compressor maintenance
- Supplied as a dedicated replacement filtration component
- Listed dimensions of 208 × 50 × 95 mm
- Approximate listed weight of 1.36 kg
- Suitable for industrial compressed-air applications
- Helps maintain lubrication-system cleanliness
Technical FAQs
What is the Ingersoll Rand 47704433001?
The 47704433001 is an Ingersoll Rand part identification associated with an oil filter for compatible industrial compressor equipment.
What is Ingersoll Rand 24900433?
The 24900433 is the corresponding oil-filter identification supplied for this component.
What is the main function of the 47704433001 / 24900433?
Its primary function is to remove contaminants from circulating compressor oil, helping protect components within the lubrication system.
What are the dimensions of the oil filter?
The supplied dimensions are approximately 208 × 50 × 95 mm.
How much does the oil filter weigh?
The listed product weight is approximately 1.36 kg.
Where is the oil filter installed?
It is installed within the compressor’s lubrication and oil-circulation circuit, normally in a dedicated oil filter housing or assembly.
Why is oil filtration important in a compressor?
Clean lubricant helps reduce contamination-related wear and supports proper lubrication, cooling, and sealing of oil-dependent compressor components.
When should the oil filter be replaced?
Replacement should follow the maintenance interval specified for the particular compressor. The filter may also require earlier replacement if contamination, abnormal pressure drop, or other service conditions are detected.
Can any oil filter with the same dimensions be used?
No. Physical dimensions alone do not guarantee compatibility. The filtration characteristics, oil compatibility, connection configuration, flow requirements, pressure rating, and compressor model must also be considered.
What can happen if an oil filter becomes heavily contaminated?
A heavily loaded filter can increase flow resistance and interfere with normal oil circulation. Depending on the compressor design, this can affect lubrication performance and operating conditions.
Is the 47704433001 / 24900433 a consumable component?
Yes. An oil filter is normally treated as a routine maintenance component and is replaced periodically as part of compressor servicing.
Conclusion
The Ingersoll Rand 47704433001 / 24900433 Oil Filter is a dedicated compressor filtration component designed to maintain the cleanliness of circulating lubricant in compatible Ingersoll Rand air compressor systems.
With supplied dimensions of 208 × 50 × 95 mm and a listed weight of approximately 1.36 kg, the filter provides a practical replacement solution for compressor maintenance programs. Its primary function is to capture contaminants within the oil circuit before they can continue circulating through sensitive lubricated components.
Regular replacement of the oil filter can help maintain lubrication-system cleanliness, protect compressor components, and support reliable long-term operation. For maintenance and spare-parts selection, the compressor model, original filter identification, lubrication-system configuration, and required filtration characteristics should be verified before installation.
