Product Overview
The Ingersoll Rand 47553891001 85576437 Hose Assembly is a hydraulic hose component used in the compressor cooling system. It is identified as a -24 hydraulic hose with a 90-degree ISO 6162 flange connection at one end and a 1.5-inch ORFS connection at the other.
This assembly is listed in an Ingersoll Rand cooling assembly configuration intended for harsh or seawater operating environments. Its two different connection arrangements allow it to connect hydraulic piping components with different interface requirements.
The 34-inch hose length provides the specified connection distance within the assembly. The combination of a hydraulic flange connection and an ORFS fitting makes correct orientation and connection matching particularly important during replacement.
When selecting this component for maintenance, the complete part number and original connection configuration should be checked to avoid substituting a hose with different fittings or routing requirements.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Ingersoll Rand |
| Product Type | Hydraulic Hose Assembly |
| Model | 47553891001 |
| Part Number | 85576437 |
| Hose Type | Hydraulic Hose |
| Hose Size | -24 |
| Connection Configuration | 90° ISO 6162 × 1.5 ORFS |
| Hose Length | 34 in |
| Application | Cooling Assembly |
| Shipping Weight | 3 kg |
Product Features
- -24 hydraulic hose: Uses the specified hydraulic hose size designation.
- 90-degree ISO 6162 connection: Provides an angled flange connection for the corresponding hydraulic interface.
- 1.5-inch ORFS connection: Provides an ORFS connection at the opposite end.
- 34-inch hose length: Accommodates the specified connection distance.
- Different end connections: Combines flange and ORFS interfaces in one hose assembly.
- Cooling-system application: Listed as part of an Ingersoll Rand cooling assembly for harsh or seawater environments.
- Dedicated replacement identification: Uses part number 85576437 for maintenance and parts identification.
Working Principle
The 85576437 operates as a flexible hydraulic passage between two connected components in the cooling assembly.
Hydraulic fluid enters through one end of the hose, passes through its internal passage, and exits through the opposite connection. The flexible hose body accommodates the required connection distance, while the two different end fittings provide the interfaces needed by the assembly.
The connection arrangement is:
Hydraulic Component → 90° ISO 6162 Flange → 85576437 Hose → 1.5-Inch ORFS Connection → Connected Component
The ISO 6162 flange connection uses a bolted flange arrangement with an appropriate sealing interface. The ORFS connection uses an O-ring at the fitting face to maintain sealing between mating components.
Both connection points must be installed correctly to prevent fluid leakage. The hose should also be routed without twisting or excessive bending, particularly near the flange and fitting ends.
Role in the Ingersoll Rand Cooling Assembly
The 85576437 is identified as a component of an Ingersoll Rand cooling assembly intended for harsh or seawater service.
Its function is to provide a flexible hydraulic connection within this assembly. The 90-degree flange end and ORFS end accommodate the different connection interfaces specified by the equipment arrangement.
The associated assembly parts include:
| Part Number | Component | Function |
|---|---|---|
| 85576437 | Hydraulic Hose | Provides the flexible hydraulic connection |
| 95987970 | O-ring | Provides sealing at the specified connection |
| 96702444 | M12 Hex Head Screw | Secures the flange connection |
| 96955166 | Split-Half Flange Clamp | Provides mechanical retention of the flange connection |
These components work together to establish and secure the hose connection within the cooling assembly.
Industrial Applications
| Application | Typical Use |
|---|---|
| Industrial Air Compressors | Hydraulic hose connections within compressor cooling assemblies |
| Harsh-Environment Cooling Systems | Supporting hydraulic connections in demanding operating environments |
| Seawater Cooling Assemblies | Providing a flexible connection in specified seawater-service equipment |
| Industrial Cooling Equipment | Connecting components through hydraulic hose assemblies |
| Compressor Maintenance | Replacing worn or damaged cooling-system hoses |
| Equipment Overhaul | Restoring the original hose and flange connection arrangement |
Installation and Maintenance
- Verify the part number: Confirm that 85576437 matches the original hose assembly and the applicable equipment parts configuration.
- Check connection orientation: Identify the 90-degree ISO 6162 flange end and the 1.5-inch ORFS end before installation.
- Depressurize the system: Shut down the equipment, isolate the cooling circuit, and release residual pressure according to the approved maintenance procedure.
- Prepare for fluid drainage: Place a suitable collection container beneath the connection points to collect residual fluid.
- Inspect flange surfaces: Check the ISO 6162 mating surfaces for corrosion, scratches, deformation, or contamination.
- Inspect the ORFS connection: Examine the fitting face and sealing area for damage or contamination.
- Check the O-ring: Inspect the associated sealing ring and replace it when necessary using the specified replacement component.
- Position the hose correctly: Align both ends with their corresponding ports without twisting the hose body.
- Secure the flange connection: Install the appropriate split-half flange clamp and fastening hardware according to the equipment instructions.
- Tighten the fittings: Follow the applicable tightening specifications for the flange bolts and ORFS connection.
- Inspect for leakage: Restore the system according to the approved startup procedure and check both connection points for fluid leakage.
- Document maintenance: Record the replacement part number, installation date, sealing components replaced, and inspection results.
Never disconnect or inspect a pressurized hydraulic hose. High-pressure fluid leakage can cause serious injection injuries.
Compatible System Components
The following components are identified in the same Ingersoll Rand cooling assembly as the 85576437 hose.
| Model | Product Type | Function |
|---|---|---|
| 95987970 | O-ring | Seals the corresponding connection interface |
| 96702444 | M12 Hex Head Screw | Secures the flange connection |
| 96955166 | Split-Half Flange Clamp | Retains the flange connection |
| 85576437 | Hydraulic Hose | Provides the flexible hydraulic connection |
Key Advantages
- Combines ISO 6162 flange and ORFS connection interfaces.
- Uses a 90-degree flange connection for the specified installation.
- Provides a 34-inch hydraulic hose assembly.
- Supports the cooling assembly’s hydraulic connection arrangement.
- Has identifiable associated sealing and flange fastening components.
- Provides a dedicated part number for maintenance and replacement.
Technical FAQs
What connection types are used on the 85576437 hose assembly?
The assembly uses a 90-degree ISO 6162 flange connection at one end and a 1.5-inch ORFS connection at the other. Both interfaces must match the original equipment connections.
What is the function of the 90-degree ISO 6162 connection?
The angled flange connection accommodates the required piping direction and provides a bolted interface for securing the hose to the corresponding equipment port.
Which components are associated with the 85576437 assembly?
The associated parts include O-ring 95987970, M12 hex head screw 96702444, and split-half flange clamp 96955166. These components support sealing and mechanical retention of the hose connection.
Why should the original hose connection arrangement be maintained?
The hose combines two different connection interfaces. Replacing it with an assembly having different fitting types or orientations may prevent correct installation and compromise the hydraulic connection.
