Product Overview
The Foxboro P0916FH I/A Series 200 Type 4 P/PVC Termination Cable is a cable assembly associated with Foxboro I/A Series 200 process control systems. It supports the physical connection between system termination points and the corresponding control hardware, helping establish an organized signal path within an industrial control cabinet.
In a distributed control system, termination cabling is part of the connection infrastructure between field wiring and control electronics. Selecting the correct cable type is important when maintaining an existing installation, replacing a damaged assembly, or restoring connections during system servicing. The P0916FH is relevant to maintenance work involving Type 4 P/PVC termination arrangements, where the cable designation and intended system configuration must be considered together.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Title | Foxboro P0916FH I/A Series 200 Type 4 P/PVC Termination Cable |
| Manufacturer | Foxboro |
| Model | P0916FH |
| Product Series | I/A Series 200 |
| Product Type | P/PVC Termination Cable |
| Cable Type | Type 4 |
| Application | Industrial process control systems |
| System Platform | Foxboro I/A Series 200 |
| Primary Function | Termination and interconnection |
| Installation Environment | Industrial control cabinet |
| Cable Length | 1 meter |
| Shipping Weight | 3 kg |
Product Features
- I/A Series 200 application: Intended for use within the Foxboro I/A Series 200 control system environment.
- Type-specific identification: The Type 4 designation helps distinguish this cable from other termination cable variants.
- P/PVC termination configuration: The product designation identifies the specified termination cable type for the relevant system arrangement.
- Maintenance and replacement use: Suitable for consideration when servicing existing control system cabling.
- Organized cabinet wiring: Termination cabling helps maintain structured connections between system components.
- Defined cable length: The specified length supports planning for the intended connection route and cabinet layout.
Working Principle
The P0916FH functions as part of the connection path within a Foxboro I/A Series 200 control system. Termination cabling carries the required electrical connections between designated system interfaces, allowing the associated control hardware and termination arrangement to work together.
During operation, signals travel through the established wiring path between the relevant field or termination connections and the control system interface. The cable itself does not perform signal processing or control logic; those tasks belong to the connected system components.
When replacing an existing cable, the technician should identify the cable designation and the connection points used by the installed system. Correct routing and secure connections help prevent wiring faults that could interrupt signal transmission or complicate fault diagnosis.
Role in a Foxboro I/A Series 200 Control Architecture
| System Layer | Related Component | Role in the Architecture |
|---|---|---|
| Field Level | Sensors and field instruments | Supply process measurements or status signals |
| Termination Level | P/PVC termination arrangement | Provides the designated connection point for system wiring |
| Interconnection Level | P0916FH termination cable | Establishes the required cable connection between designated interfaces |
| Control Level | I/A Series 200 control hardware | Processes input signals and executes configured control functions |
| Supervisory Level | Operator workstation or HMI | Presents process information and supports operator interaction |
Industrial Applications
- Process measurement systems: Supports termination cabling arrangements associated with industrial measurement and monitoring.
- Chemical processing: Relevant to maintenance of control system wiring in process plants.
- Oil and gas facilities: Can be considered when servicing installed Foxboro I/A Series 200 control infrastructure.
- Power and utility installations: Supports maintenance activities involving compatible process control equipment.
- Manufacturing plants: Helps maintain the interconnection infrastructure used by distributed control systems.
- Control cabinet refurbishment: May be used when replacing an existing cable assembly during cabinet maintenance, subject to confirmation of the installed configuration.
Installation and Maintenance
- Confirm the model designation. Check that P0916FH matches the cable specified for the existing Type 4 P/PVC termination arrangement.
- Review the system documentation. Identify the intended connection points using the cabinet drawings and applicable Foxboro documentation.
- Isolate the relevant equipment. Follow site procedures for electrical isolation before disconnecting or replacing control cabling.
- Record the existing wiring. Label the cable and document its connection points before removal.
- Inspect the replacement cable. Check the cable jacket, connectors, and accessible termination areas for visible damage.
- Verify the routing path. Plan the cable route to avoid sharp edges, excessive bending, and interference with cabinet doors or moving parts.
- Disconnect the old assembly carefully. Release the existing connections using the appropriate procedure without pulling on the cable itself.
- Install the replacement. Connect the P0916FH to the designated interfaces according to the system wiring documentation.
- Secure the cable. Use suitable cable supports and maintain separation from sources of electrical interference where required by the installation.
- Check the connections. Confirm that connectors and termination points are properly seated and secured.
- Perform post-installation checks. Follow the applicable commissioning procedure to verify continuity and correct system response.
- Document the maintenance work. Record the replacement, inspection results, and any wiring changes in the equipment maintenance log.
Related Components
| Component | Function | Relationship to P0916FH |
|---|---|---|
| Foxboro I/A Series 200 Control Hardware | Executes configured control functions | Forms part of the control system served by the cabling infrastructure |
| Termination Assembly | Provides designated wiring connection points | Defines the connection arrangement used by the cable |
| Field Instrument Wiring | Carries process measurements and status signals | Connects field devices to the relevant system termination points |
| Control Cabinet Wiring Accessories | Support cable routing and organization | Help maintain an orderly installation |
| System Wiring Documentation | Identifies connection points and wiring assignments | Supports correct installation and troubleshooting |
Recommended Related Models
| Model | Product Description | Selection Consideration |
|---|---|---|
| Foxboro P0916DW | I/A Series 200 Type 2 P/PVC Termination Cable | Consider when the installed system specifies the Type 2 cable variant |
| Foxboro RH916DW | I/A Series 200 Type 2 P/PVC Termination Cable | Consider for installations that identify this model in their existing wiring documentation |
| Foxboro P0916FH | I/A Series 200 Type 4 P/PVC Termination Cable | The specified model for this product entry |
Key Advantages
- Identifiable cable variant for maintenance and replacement work.
- Supports structured connections within Foxboro I/A Series 200 installations.
- Helps technicians trace and maintain the termination wiring path.
- Suitable for planned service and control cabinet maintenance when the specified configuration matches.
Technical FAQs
1. What is the Foxboro P0916FH used for?
The P0916FH is an I/A Series 200 Type 4 P/PVC termination cable used as part of the interconnection infrastructure in a compatible Foxboro control system installation.
2. What does the Type 4 designation mean?
Type 4 identifies a particular cable variant within the product designation. It should be matched against the system documentation rather than treated as interchangeable with other termination cable types.
3. Can the P0916FH replace a Type 2 termination cable?
Not automatically. A Type 2 cable and a Type 4 cable have different designations. Before substitution, confirm the required cable model, termination arrangement, and connection requirements in the installed system documentation.
4. What should be checked before installing a replacement P0916FH?
Confirm the model designation, intended connection points, cable condition, routing requirements, and termination arrangement. After installation, carry out the checks specified by the applicable maintenance and commissioning procedures.
