- Foxboro
- FBM217 RH914TR
- Discrete Input Interface Module
- USA
- 114 × 45 × 104 mm
- 0.284 kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 4
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Product Overview
The Foxboro FBM217 RH914TR is an I/A Series discrete input interface module used to acquire binary field signals within Foxboro process control systems. It provides the interface between field switching devices, equipment status contacts, and the I/A Series control architecture, allowing discrete conditions to be used by monitoring and control functions.
Discrete input signals are commonly associated with equipment running status, valve position, limit conditions, alarms, permissives, and interlock feedback. The FBM217 RH914TR collects these field states and makes them available to the control system for sequence logic, operator indication, alarming, and process monitoring.
The module operates as part of the I/A Series field I/O structure. Field devices connect through the associated wiring and termination infrastructure, while the acquired input information is transferred through the system communication architecture toward the relevant control-processing functions. This makes the module suitable for process plants and automated equipment where numerous binary field conditions need to be integrated into the control system.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | FBM217 RH914TR |
| Product Type | Discrete Input Interface Module |
| Product Family | I/A Series |
| Series | Foxboro I/A Series |
| Module Type | Discrete Input Module |
| Signal Type | Discrete Field Signals |
| Primary Function | Discrete Signal Acquisition |
| Input Interface | Field Switching and Status Signals |
| Signal Processing | Discrete State Detection |
| System Integration | Foxboro I/A Series Control System |
| Field Interface | Process and Machine Instrumentation |
| Application | Process Monitoring and Control |
| Installation | I/O Subsystem / Field Interface Assembly |
| Dimensions | 114 × 45 × 104 mm |
| Weight | 0.284 kg |
Product Features
- I/A Series discrete input interface for industrial process-control applications.
- Acquires binary field conditions for monitoring and control logic.
- Suitable for equipment status, alarm indications, permissives, and interlock feedback.
- Provides a field-level interface between discrete devices and the Foxboro control system.
- Integrates external switching and status signals into the I/A Series I/O architecture.
- Suitable for process equipment and machine-status monitoring.
- Works with associated field wiring and termination infrastructure.
- Supports structured I/O installation within Foxboro process-control systems.
- Suitable for compatible system expansion and replacement applications.
- Provides a practical interface for collecting discrete field information.
Working Principle
1. Field condition generation
A field device changes state according to the condition being monitored. A limit switch, equipment contact, valve position switch, alarm contact, or other discrete device can provide the binary condition required by the control system.
2. Signal transmission
The field condition travels through the associated field wiring and termination assembly toward the FBM217 RH914TR. Correct wiring and termination are necessary for the module to receive the intended input state.
3. Discrete state acquisition
The module receives and interprets the field signal as a discrete input condition. The resulting state can represent a defined process or equipment condition within the I/A Series system.
4. I/O communication
The acquired state is transferred through the I/A Series communication architecture toward the appropriate control-processing functions. The control application can then use the input for logic, sequencing, alarming, or operator indication.
5. Control-system response
The control strategy determines what action is associated with the input state. A change in the field signal may update equipment status, initiate an alarm, satisfy a permissive, or affect an interlock or sequence.
Role in an I/A Series Process Control Architecture
The FBM217 RH914TR operates at the discrete field I/O layer of an I/A Series control system. It provides the connection between binary field conditions and the higher-level control functions that use those conditions for monitoring and automation.
| Architecture Layer | Main Function | Relationship to FBM217 RH914TR |
|---|---|---|
| Field Devices | Generate process or equipment status | Supplies discrete state information |
| Field Wiring | Carries field signals | Connects devices to the I/O interface |
| Termination Assembly | Organizes field connections | Provides the field connection interface |
| FBM217 Module | Acquires discrete input states | Provides the discrete input interface |
| I/A Series Communication | Transfers I/O information | Carries input states toward the control system |
| Control Processor | Executes control and sequence logic | Uses discrete states for automation functions |
| Operator Interface | Displays process and equipment status | Presents input conditions to operators |
Industrial Applications
| Application | Typical Use |
|---|---|
| Equipment Status Monitoring | Detecting running, stopped, available, or fault conditions |
| Valve Position Monitoring | Receiving open or closed position feedback |
| Motor and Pump Systems | Monitoring operating and fault contacts |
| Process Interlocking | Providing permissive and interlock conditions |
| Alarm Monitoring | Acquiring discrete alarm and trip indications |
| Automated Production Equipment | Monitoring machine states and sequence conditions |
| Process Plants | Collecting binary field conditions for control and operator monitoring |
| Material Handling | Monitoring limit switches and equipment position states |
Installation and Maintenance
- Verify the complete model number — Confirm FBM217 RH914TR before installation or replacement to avoid using an incorrect module variant.
- Check I/A Series compatibility — Verify compatibility with the existing Foxboro I/A Series I/O architecture and associated hardware.
- Confirm the intended input application — Make sure the connected field devices provide the appropriate discrete signals for the configured system.
- Inspect the termination interface — Check the associated termination assembly and verify that field connections are correctly installed.
- Inspect field wiring — Look for loose terminals, damaged conductors, corrosion, incorrect connections, or other wiring problems.
- Verify field-device operation — Confirm that switches, contacts, limit devices, or other discrete sources actually change state when the monitored condition changes.
- Check module installation — Ensure the module is correctly seated and that its associated connections are secure.
- Review the I/O configuration — Confirm that the control-system configuration corresponds to the intended discrete input arrangement.
- Test individual input states — Change the relevant field condition under controlled conditions and confirm that the corresponding input state appears correctly in the control system.
- Verify sequence and alarm logic — Check that the acquired input produces the expected response in associated control logic, alarms, permissives, or sequences.
- Review diagnostic information — Investigate unexpected input behavior, communication problems, or other I/O indications using available system diagnostics.
- Follow controlled replacement procedures — When replacing the module in an operating process environment, follow the site’s approved isolation, configuration, testing, and commissioning procedures.
Related Components
| Component | Function |
|---|---|
| Foxboro I/A Series Control Processor | Processes discrete input information and executes control logic |
| I/A Series Termination Assembly | Provides the field wiring interface for discrete devices |
| Field Switches and Contacts | Generate binary process or equipment conditions |
| Limit Switches | Provide position and travel status |
| Motor and Pump Status Contacts | Supply operating and fault indications |
| Valve Position Switches | Provide discrete valve position feedback |
| I/A Series Communication Infrastructure | Transfers acquired I/O information |
| Engineering / Maintenance Station | Supports configuration, diagnostics, and troubleshooting |
Recommended Related Models
| Model | Product Type | Typical Application |
|---|---|---|
| Foxboro FBM217 P0914TR | I/A Series Discrete Input Interface Module | Discrete field signal acquisition |
| Foxboro FBM216b RH927AJ | I/A Series Redundant HART Communication Input Module | HART field instrumentation |
| Foxboro FBM216 P0922VV | I/A Series Input Module | Process signal acquisition |
| Foxboro FBM214b RH927AH | I/A Series Input Module | Process instrumentation interface |
| Foxboro FBM211 RH914TN | I/A Series Input Module | Process input applications |
| Foxboro FBM207c RH917GY | I/A Series Input Module | I/A Series field I/O |
| Foxboro FBM203 RH914SV | I/A Series Input Module | Process measurement interface |
Key Advantages
- Dedicated discrete input interface for Foxboro I/A Series systems.
- Suitable for binary process and equipment status signals.
- Supports monitoring, sequencing, alarms, permissives, and interlocks.
- Integrates field switching devices with the I/A Series control architecture.
- Suitable for process plants and automated industrial equipment.
- Useful for compatible I/O expansion and replacement applications.
Technical FAQs
What is the primary function of the FBM217 RH914TR?
The FBM217 RH914TR provides a discrete input interface between field devices and the Foxboro I/A Series control system. It acquires binary field conditions and makes the resulting states available to control and monitoring functions.
What field devices are commonly connected to a discrete input module?
Typical devices include limit switches, valve position switches, equipment status contacts, motor or pump auxiliary contacts, alarm contacts, and other devices that provide defined binary states.
How can an incorrect discrete input state be diagnosed?
Start with the field device and confirm that its physical state changes as expected. Then check field wiring, termination connections, module installation, and I/O configuration. If the field condition is correct but the displayed control-system state is not, the signal path should be checked progressively toward the control processor.
Can the FBM217 RH914TR be used for analog process measurements?
The FBM217 RH914TR is intended for discrete input applications rather than continuously varying analog measurements. Analog process variables such as pressure, temperature, or flow normally require an appropriate analog input interface instead.
