1. Product Overview: Bently Nevada 3500/92 136188-01
Product Description
The Bently Nevada 3500/92 136188-01 is a Communication Gateway Module designed for seamless integration within the 3500 Series machinery protection systems. This device serves as a bridge between the monitoring rack and external control systems like DCS (Distributed Control System), SCADA (Supervisory Control and Data Acquisition), or PLC (Programmable Logic Controller).
It enables real-time data exchange and monitoring by supporting a range of communication protocols including Modbus TCP/IP, Modbus RTU, and proprietary protocols specific to the 3500 Series. The module offers multiple communication interfaces including Ethernet and serial connections (RS-232/RS-422/RS-485), allowing for flexible and reliable data transmission.
The 136188-01 variant is tailored for enhanced communication capabilities, allowing precise monitoring of machine health parameters such as vibration, shaft position, temperature, and alarms, essential for predictive maintenance and operational safety.
Brand and Series Information
| Category | Details |
|---|---|
| Brand | Bently Nevada |
| Series | 3500 Series |
| Product Type | Communication Gateway Module |
| Model Number | 3500/92 136188-01 |
Technical Specifications
| Parameter | Value |
|---|---|
| Model | 3500/92 136188-01 |
| Function | Communication Gateway Module |
| Power Supply | 24 VDC (Nominal) |
| Communication Interfaces | Ethernet TCP/IP, RS-232, RS-422, RS-485 |
| Supported Protocols | Modbus RTU, Modbus TCP/IP, Proprietary 3500 protocols |
| Configuration Tools | Network-based configuration software |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% (non-condensing) |
| Dimensions (L × W × H) | 150 mm × 100 mm × 25 mm |
| Weight | 0.22 kg |
| Mounting | 3500 Rack Mount |
| Hot-Swappable | No, requires powered-down state for handling |
Key Advantages
-
Robust Multi-Protocol Support: Seamlessly communicates via Modbus TCP/IP, Modbus RTU, and proprietary 3500 protocols for broad compatibility.
-
Flexible Communication Interfaces: Provides multiple interfaces including Ethernet and serial ports to suit various control system architectures.
-
Compact and Lightweight: Small form factor and light weight simplify installation within control cabinets.
-
Wide Environmental Tolerance: Designed to operate reliably under extreme industrial environmental conditions.
-
Real-Time Data Access: Enables timely and reliable transmission of vibration, temperature, and alarm data crucial for machinery health monitoring.
-
Customizable Data Mapping: Allows users to define which parameters are communicated, optimizing network traffic.
Applications
The 3500/92 136188-01 module is widely used in industries requiring reliable machinery condition monitoring and integration with control systems. Typical applications include:
-
Power Plants: Monitoring turbines, generators, and auxiliary equipment.
-
Oil & Gas Industry: Tracking compressors, pumps, and rotating equipment onshore and offshore.
-
Petrochemical Plants: Protecting critical processing machinery from failure.
-
Mining & Metals: Ensuring reliable operation of mills, crushers, and conveyors.
-
Water Treatment Facilities: Monitoring pumps and motors for preventative maintenance.
-
General Manufacturing: Protecting heavy machinery and automated production lines.
2. Related Models – Same Series or Similar Modules
| Model | Function/Type | Key Specs (Size/Voltage/Weight) | Description/Use Case |
|---|---|---|---|
| 3500/91 | Communication Gateway Module | 150 mm × 100 mm × 25 mm / 24 VDC / 0.20 kg | Alternative gateway with similar interface options. |
| 3500/22-01-01-00 (TDI) | Transient Data Interface Module | 241.3 × 24.4 × 241.8 mm / 24 VDC / 0.9 kg | Captures high-speed transient data for detailed event analysis. |
| 3500/33 16-Channel Relay | Relay Output Module | Standard rack size / 24 VDC / ~0.7 kg | Provides relay outputs for alarms and shutdown signals. |
| 3500/15 125840-02 | Low Voltage Power Module | 85–265 VAC / Rack size / ~0.4 kg | Powers entire 3500 rack; base module for system operation. |
| 3500/50 133442-01 | Overspeed Protection Module | 24 V input / Standard size / ~1.0 kg | Critical safety module to monitor overspeed conditions. |
3. Popular Models from the Same Brand (Bently Nevada)
| Model | Type/Function | Key Specs (Size/Voltage/Weight) | Description/Application |
|---|---|---|---|
| 3500/93 135785-01 | System Display Module | 150 × 120 × 30 mm / 12 VDC / 0.2 kg | Provides visual monitoring and alarms for operators. |
| 3500/22M 288055-01 | Transient Data Interface Module | 241.3 × 24.4 × 241.8 mm / 24 VDC / 0.9 kg | Enhanced TDI for transient event capture and analysis. |
| 3500/40M (e.g., 176449-01) | Proximitor/Position Monitoring Module | Rack size / 24 VDC / ~0.8–1.0 kg | Measures shaft displacement and vibration in rotating equipment. |
| 3500/20 Series | I/O Interface Modules | Rack size / 24 VDC / ~0.7 kg | Interfaces sensors and control outputs. |
| 3300 XL Series | Proximity Probes & Sensors | Compact / Varies / Lightweight | Used for direct shaft monitoring with high precision. |
4. FAQ – Top 10 Questions About 3500/92 136188-01
Q1: What is the primary function of the 3500/92 136188-01?
A1: It acts as a communication gateway, transmitting data from the 3500 rack to external systems using various protocols.
Q2: Which communication interfaces are supported?
A2: Ethernet TCP/IP, RS-232, RS-422, and RS-485 serial ports are supported.
Q3: What protocols does it use?
A3: It supports Modbus RTU, Modbus TCP/IP, and proprietary Bently Nevada protocols.
Q4: What is the power requirement?
A4: The module requires 24 VDC power supply.
Q5: What are the dimensions and weight?
A5: Dimensions are 150 mm × 100 mm × 25 mm; weight is approximately 0.22 kg.
Q6: Is it hot-swappable?
A6: No, it must be powered down before installation or removal.
Q7: What environments can it operate in?
A7: It can operate from -40°C to +85°C and tolerate humidity levels of 5% to 95% (non-condensing).
Q8: How is the module configured?
A8: Through software that accesses the device via network or serial connection to set parameters and Modbus mappings.
Q9: Can it be integrated with SCADA or DCS systems?
A9: Yes, it is designed specifically for integration with SCADA, DCS, and PLC systems.
Q10: What kind of data does it transmit?
A10: It transmits machinery health data such as vibration, temperature, alarms, and system status.
