Product Overview: 3500/42M 140482‑01
The 3500/42M 140482‑01 module is a precision-engineered monitoring unit designed for continuous protection of rotating machinery. It fits into a modular rack monitoring system, accepting inputs from both proximity probes and seismic transducers. Real-time signal processing allows accurate vibration and displacement measurements, which are output to control systems. Built for demanding industrial environments, it delivers consistent reliability and fault detection readiness.
Product Specifications
| Parameter | Details |
|---|---|
| Model | 3500/42M 140482‑01 |
| Input Channels | 4 independent inputs |
| Supported Sensors | Proximity probes, seismic vibration sensors |
| Output Signals | 4–20 mA outputs per channel; buffered analog voltage outputs |
| Signal Processing Modes | True peak, RMS, gap, direct values, harmonic detection (1×, 2×, Not 1×) |
| Update Frequency | ~100 ms per channel |
| Communication Interface | Proprietary rack bus compatible with display and relay modules |
| Physical Mounting | Single- or dual-slot compatible within standard rack setup |
| Power Consumption | Below 5 W |
| Operating Temperature | –30 °C to +65 °C |
| Storage Temperature | –40 °C to +85 °C |
| Hazardous Area Certification | Rated for Zone 2 locations morphologically |
| Dimensions (HxWxD) | 241 mm × 24 mm × 241 mm |
| Weight | 0.45 kg |
Product Applications
This module is deployed to maintain operational integrity across various industrial platforms. Key application areas include:
-
Monitoring turbine rotor vibration and shaft alignment in gas and steam turbines
-
Providing early warning of imbalance or bearing wear in compressors
-
Protecting generators and motors in power generation and industrial equipment
-
Monitoring critical pumps, blowers, and fans to prevent mechanical degradation
-
Facilitating reliable condition monitoring in energy, petrochemical, marine, and mining sectors
With its real-time analytics and analog outputs, this unit is ideal for integrating into condition-based maintenance strategies where uptime is vital.
Product Advantages
-
High-Density Monitoring: Four independent channels in a streamlined module maximize rack efficiency
-
Comprehensive Signal Analysis: Built-in processing for peak, RMS, gap, and harmonic data supports early fault detection
-
Seamless Rack Integration: Compatible with display, relay, and interface modules via standard bus architecture
-
Rugged and Reliable: Wide temperature tolerance and hazardous area rating ensure consistent performance under harsh conditions
-
Low Power, Low Maintenance: Minimal power draw and field service requirements translate to reduced operational overhead
Brand & Series
-
Brand: (Confidential Industrial Monitoring Solution)
-
Series: 3500 Modular Machinery Protection Platform
The 3500 series is renowned for modular, rack-based protection of rotating assets, offering specialized modules for vibration, displacement, phase, speed, and data relay functions. This framework allows tailored configurations for machinery protection workflows.
5 Same-Series or Related Models
| Model | Description | Input Channels | Key Feature | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 3500/42M 140482‑02 | Alternate variant in same family | 4 | Alternate tuning or calibration option | 241 × 24 × 241 | 0.45 |
| 3500/40M 176449‑03 | Basic proximity measurement module | 4 | Straight distance measurement | 241 × 24 × 241 | 0.44 |
| 3500/44M 140734‑03 | Triple-redundant proximitor/seismic module | 3 (TMR) | High-reliability architecture | 241 × 24 × 241 | 0.46 |
| 3500/50M 140734‑02 | Tachometer / phase monitoring module | 2 | Speed and phase signal generation | 241 × 24 × 241 | 0.43 |
| 3500/25M 149369‑02 | Keyphasor phase reference module | 2 | Precise rotor phase reference | 241 × 24 × 241 | 0.42 |
5 Popular Models from the Same Brand
| Model | Description | Functionality | Channels | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 3500/22M 138607‑02 | Data communication module | Rack bus data relay | – | 241 × 24 × 241 | 0.40 |
| 3500/94M 147663‑02 | Operator interface display unit | Visual monitoring interface | – | 241 × 48 × 241 | 0.55 |
| 3300 XL Proximitor (8 mm) | Industrial displacement sensor | Vibration/displacement sensing | – | 71 × 25 × 25 | 0.09 |
| 3500/15M Power Module | Rack power supply unit | Power distribution within rack | – | 241 × 48 × 241 | 0.50 |
| 1900/65A Compact Monitor | Compact condition monitor | Simple vibration monitoring | 2 | 120 × 30 × 110 | 0.35 |
Frequently Asked Questions (QA)
Q1: What sensor types does this module accept?
A1: It accepts proximity probes and seismic vibration transducers for comprehensive measurement.
Q2: How many channels can be monitored simultaneously?
A2: Four independent channels are monitored concurrently for extensive coverage.
Q3: What kinds of signal outputs are available?
A3: Each channel provides both 4–20 mA and buffered voltage outputs for system integration.
Q4: Which signal diagnostics are built in?
A4: The module offers true peak, RMS, gap, and harmonic signal detection (1×, 2×, Not 1×).
Q5: Is it safe for use in hazardous environments?
A5: Yes. It’s rated for Zone 2 service, suitable for areas that occasionally contain flammable gases.
Q6: How much power does the module draw?
A6: It operates using less than 5 W, making it energy-efficient.
Q7: What temperature range can it endure?
A7: It remains functional from –30 °C up to +65 °C, covering extreme industrial conditions.
Q8: What maintenance does it need?
A8: Maintenance is minimal, limited to periodic checks and firmware updates.
Q9: Can this module be installed while powered?
A9: No. Power must be switched off before inserting or removing the module to avoid damage.
Q10: Which module family does this belong to?
A10: It is part of the 3500 modular platform for machinery protection.
