1. Product Overview
Model: 3500/40M 135489-04
Type: Proximitor I/O Module with Internal Barriers and Internal Terminations
Brand: Bently Nevada
Series: 3500 Machinery Protection System
2. Product Introduction
The 3500/40M 135489-04 is an advanced Proximitor I/O Module designed for the Bently Nevada 3500 Machinery Protection System. This module is equipped with internal barriers and internal terminations, providing explosion protection for transducer systems connected to the 3500 system. It ensures that all types of transducer systems can be installed within a hazardous area without degrading system performance.
This module is ideal for applications requiring high-speed signal processing and is constructed from high-quality stainless steel, making it suitable for use in a wide range of temperature conditions, from sub-zero environments to hot industrial settings. Its versatile communication interface supports RS-485 protocols, facilitating seamless connectivity with various control systems.
3. Product Applications
The 3500/40M 135489-04 module is widely used in industries where machinery protection and condition monitoring are critical. Its applications include:
-
Power Generation: Monitoring turbines, generators, and pumps to detect early signs of mechanical failure.
-
Oil & Gas: Ensuring the reliability of compressors, drilling equipment, and other critical machinery.
-
Petrochemical Plants: Protecting pumps, compressors, and other rotating equipment from potential damage.
-
Water Treatment Facilities: Monitoring pumps and motors to prevent unexpected failures.
-
Manufacturing Industries: Safeguarding large rotating equipment from potential damage.
4. Product Advantages
-
Explosion Protection: Equipped with internal barriers and terminations, allowing installation in hazardous areas without compromising safety.
-
High-Speed Signal Processing: Capable of handling complex control tasks efficiently with an impressive output frequency of 40 kHz.
-
Robust Design: Constructed from high-quality stainless steel, suitable for a wide range of temperature conditions.
-
Versatile Communication Interface: Supports RS-485 protocols for seamless connectivity with various control systems.
-
Compliance with Safety Standards: Certified to meet international safety and quality standards, including UL, CE, and ISO 9001.
5. Detailed Specifications
| Parameter | Specification |
|---|---|
| Model | 3500/40M 135489-04 |
| Input Channels | 1 to 4 proximity transducer signals |
| Output Frequency | 40 kHz |
| Power Consumption | 7.7 W nominal |
| Operating Temperature | -30°C to +65°C (with internal termination) |
| Storage Temperature | -40°C to +85°C |
| Humidity | 95% non-condensing |
| Dimensions (HxWxD) | 241.3 mm x 24.4 mm x 163.1 mm |
| Weight | 0.46 kg |
| Material | High-quality stainless steel |
| Communication Interface | RS-485 |
| Certifications | UL, CE, ISO 9001 |
6. Related and Popular Models
Related Models (Same Series or Function)
| Model | Input Channels | Sensor Compatibility | Outputs | Notes |
|---|---|---|---|---|
| 3500/40M 135489-04 | 1 to 4 | Proximity transducers | RS-485 | Standard 4-channel input module |
| 3500/40M 135489-01 | 1 to 4 | Proximity transducers | RS-485 | Similar vibration monitoring |
| 3500/40M 135489-02 | 1 to 4 | Proximity transducers | RS-485 | Includes Modbus RTU communication |
| 3500/40M 135489-03 | 1 to 4 | Proximity transducers | RS-485 | Designed for hydro machinery |
| 3500/40M 135489-05 | 1 to 4 | Proximity transducers | RS-485 | High-temperature environments |
Popular Models (Same Brand)
| Model | Input Channels | Sensor Type | Output Type | Application Focus |
|---|---|---|---|---|
| 3500/32M | 4 | Temperature sensors | Analog | Temperature monitoring |
| 3500/33 | 4 | Temperature sensors | Analog | Dedicated temperature module |
| 3500/60 | 8 | Temperature sensors | Analog | Extended temperature monitoring |
| 3500/61 | 8 | Temperature sensors | Analog | High-temperature environments |
| 3500/77M | 8 | Temperature sensors | Analog | High-temp zone monitoring |
7. Frequently Asked Questions (QA)
Q1: What sensors can I connect to the 3500/40M 135489-04?
A1: It supports Bently Nevada 3300 XL proximity probes and 330500 velocity sensors.
Q2: How many input channels are available?
A2: The module provides 1 to 4 differential input channels for simultaneous sensor monitoring.
Q3: What types of measurements does this module provide?
A3: It measures vibration velocity, shaft displacement, eccentricity, and differential expansion.
Q4: What outputs are supported for integration?
A4: Outputs include RS-485 Modbus RTU digital communication.
Q5: Can I replace this module without shutting down the system?
A5: Yes, the 3500/40M is hot-swappable, allowing maintenance without interrupting system operation.
Q6: What is the operating temperature range?
A6: The module functions reliably between -30°C and +65°C with internal termination.
Q7: What are the physical dimensions and weight of this module?
A7: Dimensions are 241.3 mm high, 24.4 mm wide, 163.1 mm deep, with a weight of approximately 0.46 kg.
Q8: Is the module compliant with industry standards?
A8: Yes, it meets UL, CE, and ISO 9001 standards.
Q9: How do I install the 3500/40M 135489-04?
A9: It is rack-mounted within the Bently Nevada 3500 series enclosure.
Q10: What maintenance is required for the 3500/40M module?
A10: Regular visual inspections and functional tests are recommended, but the module is designed for low maintenance and high reliability.
