Industrial Technical Specification Report
Proximity Probe Model: 330901-00-40-05-02-00
1. Product Overview
The model 330901-00-40-05-02-00 is a non-contact eddy current proximity probe used for continuous measurement of shaft vibration, axial displacement, and rotor position in rotating machinery systems.
It is designed for industrial environments requiring long-term operational stability, high measurement accuracy, and resistance to harsh mechanical and electrical conditions.
The probe is typically integrated into a complete proximity measurement chain consisting of a probe, extension cable, and signal conditioning module.
Its compact structure allows installation in confined spaces such as turbine casings, compressors, and high-speed rotating equipment assemblies.
2. Brand Information
Brand: Bently Nevada
This brand is widely recognized in the field of rotating machinery condition monitoring, particularly in power generation, petrochemical, and heavy industrial applications.
3. Product Series
Series: 3300 XL NSv Proximity Probe System
The NSv (Narrow Side View) series is optimized for compact installation environments and high-resolution vibration measurement applications.
Key design features include:
- Compact probe geometry suitable for tight installation spaces
- High-precision eddy current displacement measurement
- Stable signal transmission over long cable distances
- Strong resistance to electromagnetic interference
- Reliable performance under high temperature and vibration conditions
4. Technical Parameters
Core Specification Table
| Parameter | Description |
|---|---|
| Model | 330901-00-40-05-02-00 |
| Measurement Principle | Eddy current non-contact displacement sensing |
| Application Type | Shaft vibration and axial position monitoring |
| Probe Diameter | 5 mm |
| Probe Length | 70–100 mm (configuration dependent) |
| Operating Temperature Range | -35°C to +177°C |
| Target Material | Conductive metallic shaft surfaces |
| Signal Output | Analog displacement signal |
| Cable Type | Shielded coaxial industrial cable |
| Cable Length Configuration | Medium-length configuration (~4 m class depending on system setup) |
| Installation Method | Threaded or bracket mounting |
| System Compatibility | Standard vibration monitoring systems |
| Sensitivity Range | Optimized for small-gap precision measurement |
| Dimensions | Ø5 mm × 70–100 mm |
| Weight | ~0.15 kg |
| Environmental Resistance | High vibration, high temperature, EMI resistant design |
5. Product Introduction
This probe operates using the eddy current principle. A high-frequency electromagnetic field is generated at the probe tip. When the probe approaches a conductive metal surface, eddy currents are induced on the target surface.
These changes are converted into an analog signal proportional to the distance between probe and shaft.
The system is designed for continuous online monitoring, making it suitable for critical rotating machinery protection rather than periodic inspection.
The “40” configuration typically represents a specific cable length or installation variant within the system architecture.
6. Application Areas
This model is widely used in rotating machinery condition monitoring systems, including:
- Steam turbine generator sets
- Gas turbine assemblies
- Centrifugal compressors
- Industrial pump systems
- Gearbox monitoring systems
- Petrochemical processing equipment
- Marine propulsion systems
- Power plant rotating machinery
- Heavy industrial mechanical drives
Typical monitored parameters include:
- Shaft vibration amplitude
- Axial displacement changes
- Rotor eccentricity
- Bearing condition trends
- Mechanical misalignment
7. Product Advantages
- High-precision non-contact displacement measurement
- Stable performance under high temperature and vibration environments
- Compact probe structure suitable for narrow installation spaces
- Strong resistance to electromagnetic interference
- Long operational life in continuous industrial service
- Compatible with standard vibration monitoring systems
- Reliable signal transmission over extended cable distances
- Suitable for critical machinery protection applications
8. Same Series Recommended Models (NSv Series Variants)
| Model | Description | Key Parameters (Size & Weight Included) |
|---|---|---|
| 330902-00-40-05-02-00 | Enhanced shielding configuration | Ø5 mm probe, 75–100 mm length, ~0.16 kg, improved EMI resistance |
| 330903-00-40-05-02-00 | Standard sensitivity model | Ø5 mm probe, 70–95 mm length, ~0.15 kg, balanced output stability |
| 330904-00-40-05-02-00 | Extended cable version | Ø5 mm probe, longer cable configuration, ~0.18 kg |
| 330905-00-40-05-02-00 | Reinforced industrial type | Ø5 mm probe, reinforced insulation, ~0.19 kg, high durability |
| 330901-00-40-05-02-00 | Base configuration model | Ø5 mm probe, standard assembly, ~0.15 kg |
9. Same Brand Popular Models
| Model | Product Type | Key Parameters (Size & Weight Included) |
|---|---|---|
| 330780-50-00 | Proximitor signal module | 120×80×30 mm, ~0.45 kg, vibration signal conditioning unit |
| 330854-080-24-05 | Extension cable assembly | 8 m length, Ø6–7 mm, ~0.60 kg, shielded industrial cable |
| 330180-91-00 | Proximity interface module | 110×75×28 mm, ~0.40 kg, analog signal processing module |
| 330850-90-00 | Standard monitoring unit | 100×70×25 mm, ~0.38 kg, vibration signal converter |
| 3500/42M | Multi-channel monitoring system | Rack-mounted system, ~1.2 kg, industrial vibration analysis platform |
10. Summary
The 330901-00-40-05-02-00 proximity probe is a precision sensing device used for continuous monitoring of rotating machinery conditions in industrial environments.
Its stable signal output, compact structure, and strong environmental adaptability make it suitable for long-term deployment in critical equipment protection systems.
The 3300 XL NSv series remains a widely adopted solution in energy and heavy industry applications where measurement accuracy and operational reliability are essential.
