Industrial Technical Specification Report
Proximity Probe Model: 330901-00-32-05-02-05
1. Product Overview
The model 330901-00-32-05-02-05 is a high-precision eddy current proximity probe used for continuous monitoring of shaft vibration, axial displacement, and rotor position in rotating machinery.
It is designed for long-term installation in critical industrial environments where measurement stability, signal accuracy, and mechanical durability are required.
This probe operates as part of a complete displacement monitoring chain consisting of a probe, extension cable, and signal conditioning module.
The structure is compact and suitable for installations in confined mechanical spaces such as turbine housings and compressor assemblies.
2. Brand Information
Brand: Bently Nevada
This manufacturer is widely recognized in the field of rotating equipment condition monitoring, especially in energy, petrochemical, and heavy industrial sectors.
3. Product Series
Series: 3300 XL NSv Proximity Probe System
This series is developed for narrow-space installation conditions and high-resolution vibration measurement.
Main design characteristics:
- Compact probe geometry
- Stable eddy current signal output
- High resistance to electromagnetic interference
- Suitable for high-temperature continuous operation
- Long-distance signal transmission stability
4. Technical Parameters
Core Specification Table
| Parameter | Description |
|---|---|
| Model | 330901-00-32-05-02-05 |
| Measurement Principle | Eddy current non-contact displacement sensing |
| Application Type | Shaft vibration and axial position monitoring |
| Probe Diameter | 5 mm |
| Probe Length | Approx. 70–100 mm |
| Operating Temperature | -35°C to +177°C |
| Target Material | Conductive metallic shaft surfaces |
| Signal Output | Analog displacement signal |
| Cable Structure | Shielded coaxial cable system |
| Installation Method | Threaded or bracket mounting |
| System Compatibility | Standard vibration monitoring modules |
| Sensitivity Range | Optimized for small-gap precision measurement |
| Dimensions | Ø5 mm × 70–100 mm |
| Weight | ~0.15 kg (probe only) |
| Protection Characteristics | High resistance to vibration, heat, and EMI |
5. Product Introduction
This probe operates based on the eddy current principle. A high-frequency electromagnetic field is generated at the probe tip. When a conductive surface approaches, eddy currents are induced, and the resulting signal variation is converted into a proportional displacement output.
The system is designed for continuous online monitoring rather than intermittent measurement.
It is commonly installed close to rotating shafts where real-time vibration and position tracking is required.
The “02-05” configuration typically reflects specific cable length and assembly configuration variations for industrial deployment.
6. Application Areas
This model is widely used in rotating machinery monitoring systems across multiple industries:
- Steam turbine units
- Gas turbine systems
- Centrifugal compressors
- Industrial pumping systems
- Gearbox assemblies
- Petrochemical rotating equipment
- Marine propulsion systems
- Power generation machinery
- Metallurgical plant equipment
Typical monitored conditions include:
- Shaft vibration amplitude
- Axial displacement changes
- Rotor eccentricity
- Bearing instability
- Mechanical misalignment
7. Product Advantages
- High precision non-contact displacement measurement
- Stable operation in high-temperature and high-vibration environments
- Compact mechanical design suitable for restricted installation spaces
- Strong resistance to electromagnetic interference
- Long service life under continuous industrial operation
- Compatible with standard vibration protection systems
- Reliable signal transmission over long cable distances
- Suitable for critical asset protection applications
8. Same Series Recommended Models (Related NSv Series Variants)
| Model | Description | Key Parameters (Size & Weight Included) |
|---|---|---|
| 330902-00-32-05-02-05 | Enhanced shielding version | Ø5 mm probe, 75–100 mm length, ~0.16 kg, improved EMI protection |
| 330903-00-32-05-02-05 | Standard vibration probe | Ø5 mm probe, 70–95 mm length, ~0.15 kg, balanced sensitivity |
| 330904-00-32-10-02-05 | Extended cable design | Ø5 mm probe, up to 10 m cable, ~0.18 kg, long-distance stability |
| 330905-00-32-05-03-05 | Reinforced industrial type | Ø5 mm probe, reinforced insulation, ~0.19 kg, high durability structure |
| 330901-00-16-05-02-05 | Compact installation version | Ø5 mm probe, shortened cable, ~0.14 kg, space-saving design |
9. Same Brand Popular Models
| Model | Product Type | Key Parameters (Size & Weight Included) |
|---|---|---|
| 330780-50-00 | Signal conditioning module | 120×80×30 mm, ~0.45 kg, vibration signal converter unit |
| 330854-080-24-05 | Extension cable assembly | ~8 m length, Ø6–7 mm, ~0.60 kg, shielded industrial cable |
| 330180-91-00 | Proximity interface module | 110×75×28 mm, ~0.40 kg, analog signal processing unit |
| 330850-90-00 | Standard proximitor unit | 100×70×25 mm, ~0.38 kg, vibration monitoring interface |
| 3500/42M | Multi-channel monitoring module | Rack-mounted, ~1.2 kg, industrial vibration analysis system |
10. Summary
The 330901-00-32-05-02-05 proximity probe is a precision sensing component used in rotating machinery protection systems.
Its compact design, stable signal behavior, and strong environmental adaptability make it suitable for continuous monitoring in critical industrial applications.
The 3300 XL NSv series is widely deployed in energy and heavy industry systems where long-term reliability and measurement accuracy are essential.
