Technical Product Report

Model: 330881-16-06-165-07-02

1. Brand Overview

The 330881-16-06-165-07-02 belongs to an industrial-grade machinery protection and condition monitoring product family widely used for vibration measurement and rotating equipment diagnostics.

This product line is applied in critical industries where equipment stability and continuous operation are essential, including:

• Power generation plants
• Oil and gas production facilities
• Petrochemical processing units
• Offshore drilling systems
• Steel and metallurgy plants
• Mining and mineral processing operations
• Marine propulsion systems
• Heavy industrial automation environments

The product ecosystem is designed for high precision, long-term reliability, and stable operation in harsh industrial environments with strong vibration, temperature variation, and electrical noise.

2. Product Series

The 330881-16-06-165-07-02 belongs to the 3300 XL 8 mm Proximity Transducer System, specifically within the 330881 Proximity Probe Assembly Series.

This system is part of a complete machinery monitoring architecture used for:

• Shaft vibration monitoring
• Radial displacement measurement
• Axial position detection
• Rotor eccentricity tracking
• Thrust position monitoring

A full system consists of:

• 330881 proximity probe (sensor element)
• 330880 extension cable (signal transmission)
• Proximitor monitor module (signal processing)

The probe is the primary sensing component responsible for converting mechanical motion into electrical signals.

3. Product Introduction

The 330881-16-06-165-07-02 is an 8 mm proximity probe designed for precise vibration and displacement monitoring in rotating machinery.

It operates based on eddy current sensing technology, where the probe generates a high-frequency electromagnetic field. Changes in the distance between the probe tip and the conductive target surface (usually a rotating shaft) are converted into proportional electrical signals.

This model is engineered for continuous monitoring applications in industrial environments where machinery operates under high load and continuous vibration.

The probe is designed for permanent installation, offering long-term stability and consistent measurement accuracy even in harsh conditions such as oil exposure, humidity, dust, and high temperatures.

4. Technical Specifications

5. Product Function Description

This proximity probe is a key sensing element in rotating machinery monitoring systems.

It continuously measures the gap between the probe tip and the rotating shaft surface. Any variation in this gap caused by vibration, shaft movement, or mechanical instability is converted into an electrical signal.

The monitoring system processes this signal to evaluate machine health conditions such as imbalance, misalignment, bearing wear, and rotor instability.

The probe is calibrated as part of a complete measurement system, ensuring consistent accuracy and repeatability.

6. Application Areas

The 330881-16-06-165-07-02 is widely used in industrial machinery condition monitoring and protection systems.

Typical applications include:

• Steam turbine shaft vibration monitoring
• Gas turbine rotor displacement measurement
• Centrifugal compressor condition monitoring
• Axial compressor protection systems
• Industrial pump vibration detection
• Large electric motor condition monitoring
• Generator rotor displacement systems
• Cooling fan and blower monitoring
• Hydro turbine vibration analysis
• Marine propulsion shaft systems
• Petrochemical rotating machinery
• Refinery process equipment monitoring
• LNG compressor units
• Mining machinery condition monitoring
• Steel mill rolling systems
• Cement plant rotating equipment
• Paper manufacturing machinery
• Offshore platform machinery systems
• Pipeline compressor stations
• Predictive maintenance systems

These applications require high reliability, continuous operation, and accurate real-time measurement.

7. Product Advantages

High Measurement Accuracy

Provides stable and precise detection of shaft vibration and displacement.

Compact Design

Short cable length design improves installation flexibility in compact machinery layouts.

Strong Environmental Resistance

Performs reliably under oil, moisture, dust, and chemical exposure conditions.

Stable Signal Output

Maintains consistent measurement performance over long operational periods.

High EMI Immunity

Multi-layer shielding ensures reliable operation in electrically noisy environments.

Easy Integration

Compatible with standard 3300 XL system architecture.

Low Maintenance Requirement

Designed for long-term use with minimal service intervention.

8. Recommended Models (Same Series / Related Products)

9. Recommended Popular Models (Same Brand Ecosystem)

10. Summary

The 330881-16-06-165-07-02 is a compact 8 mm proximity probe designed for high-precision monitoring of rotating machinery. It serves as a key sensing element in vibration and displacement measurement systems, converting mechanical shaft movement into electrical signals for analysis and protection.

With its stainless steel construction, compact integrated cable design, strong environmental resistance, and stable measurement performance, it is widely used in turbines, compressors, pumps, motors, and other critical industrial equipment.

The product plays a crucial role in predictive maintenance systems by enabling early fault detection, improving equipment reliability, reducing downtime, and ensuring safe and continuous industrial operation.
