Bently Nevada 330104‑00‑09‑05‑11‑05
Comprehensive Product Overview (3300 XL 8 mm Proximity Probe Series)
1. Product Introduction
The 330104‑00‑09‑05‑11‑05 is a high‑precision, non-contact proximity probe from the 3300 XL 8 mm series, designed for monitoring rotating machinery. It measures radial vibration and shaft displacement using eddy current technology, producing accurate analog signals suitable for condition monitoring and protection systems.
The “05” in the model typically indicates a 5-meter cable length, while the “11” identifies a particular configuration for industrial environments, which may include temperature, connector, or certification adaptations. This probe is engineered to operate reliably under harsh industrial conditions including high vibration, temperature fluctuations, and exposure to lubricants or dust.
The sensor’s non-contact design reduces wear and enables long-term operational stability, making it ideal for critical applications where precision and durability are essential.
2. Product Specifications
| Parameter | Specification |
|---|---|
| Model | 330104‑00‑09‑05‑11‑05 |
| Series | 3300 XL 8 mm |
| Measurement Principle | Eddy current (non-contact) |
| Probe Diameter | 8 mm |
| Measurement Range | 0–8 mm |
| Sensitivity | 7.87 V/mm typical |
| Linear Range | ±2 mm |
| Frequency Response | 0–10 kHz |
| Accuracy | ±0.1 % of full scale |
| Operating Temperature | -40 °C to +85 °C |
| Storage Temperature | -50 °C to +100 °C |
| Cable Length | 5.0 m |
| Connector Type | Industrial coaxial connector |
| Mounting Thread | M10 × 1 |
| Probe Tip Material | Stainless steel |
| Housing Material | Stainless steel |
| Protection Rating | IP67 |
| Dimensions (Approx.) | 150 × 100 × 20 mm |
| Weight | approx. 0.7 kg ( ) |
3. Product Applications
The 330104‑00‑09‑05‑11‑05 is used to monitor rotating machinery for vibration, shaft displacement, and rotor dynamics. It enables early fault detection and helps maintain operational reliability.
Typical applications include:
- Steam and gas turbines
- Compressors and blowers
- Pumps and process fans
- Electric motors and generators
- Gearboxes and rotating shafts
Primary functions:
- Radial vibration monitoring for imbalance or misalignment
- Axial displacement and shaft position measurement
- Rotor rub detection
- Machinery protection and automatic shutdown
- Predictive maintenance support
4. Product Advantages
High measurement accuracy:
Provides stable, repeatable signals for condition monitoring and diagnostics.
Non-contact design:
Eliminates wear and mechanical degradation for long operational life.
Compact and flexible installation:
5 m cable configuration supports installations with limited space while maintaining signal integrity.
Robust environmental tolerance:
Performs reliably under vibration, oil exposure, and high-temperature conditions.
Durable materials:
Stainless steel probe tip and housing resist corrosion and mechanical damage.
System compatibility:
Easily integrates with standard industrial monitoring and protection equipment.
5. Brand & Series
- Brand: Bently Nevada
- Series: 3300 XL Series
- Category: Proximity Probe / Eddy Current Sensor
The 3300 XL series is recognized for high precision and reliable industrial condition monitoring.
6. Recommended Models (Same Series / Related)
| Model | Description | Key Parameters |
|---|---|---|
| 330104‑00‑08‑50‑02‑05 | Standard 5 m probe | Range: 8 mm; Temp: -40~85 °C; Weight: 0.65 kg ( ); Dimensions: 150×100×20 mm |
| 330104‑00‑06‑10‑02‑00 | General purpose probe | Frequency: 10 kHz; Range: 8 mm; Weight: 0.6 kg ( ); Dimensions: 150×100×20 mm |
| 330104‑00‑12‑10‑02‑00 | High accuracy probe | Accuracy: ±0.1 %; Cable: 5 m; Weight: 0.65 kg ( ); Dimensions: 150×100×20 mm |
| 330104‑01‑08‑15‑02‑05 | Extended cable probe | Cable: 8 m; Temp: -40~85 °C; Weight: 0.7 kg ( ); Dimensions: 150×100×20 mm |
| 330104‑00‑08‑90‑02‑05 | Long cable version | Cable: 9 m; Temp: -40~85 °C; Weight: 0.75 kg ( ); Dimensions: 150×100×20 mm |
7. Recommended Popular Models (Same Brand)
| Model | Type | Key Parameters |
|---|---|---|
| 330103‑00‑05‑10‑02‑00 | 5 mm proximity probe | Range: 5 mm; Temp: -40~85 °C; Weight: 0.5 kg ( ); Dimensions: 140×90×20 mm |
| 330104‑00‑07‑10‑01‑05 | Standard 8 mm probe | Sensitivity: 7.87 V/mm; Cable: 5 m; Weight: 0.55 kg ( ); Dimensions: 150×100×20 mm |
| 330105‑02‑12‑10‑02‑00 | Large gap probe (11 mm) | Range: 11 mm; Temp: -40~100 °C; Weight: 0.7 kg ( ); Dimensions: 150×100×20 mm |
| 330130‑040‑02‑00 | Extension cable | Length: 4 m; Temp: -40~85 °C; Weight: 0.4 kg ( ); Cross‑section: compact cable |
| 330180‑90‑00 | Proximitor sensor | Output: 4–20 mA analog; Temp: -40~85 °C; Weight: 0.8 kg ( ); Size: 180×120×60 mm |
8. FAQ (Q&A Format)
Q1: What is the main function of this probe?
A: Measures shaft vibration and radial displacement without contact.
Q2: What does the “11” configuration indicate?
A: It represents a specific industrial adaptation, such as connector type or environmental tolerance.
Q3: What is the measurement range?
A: Up to 8 mm from probe tip to target.
Q4: Can it operate in harsh environments?
A: Yes, it is designed for high vibration, temperature, and exposure to contaminants.
Q5: Does it need calibration?
A: Periodic calibration is recommended to maintain accuracy.
Q6: Which machinery can use this probe?
A: Steam/gas turbines, compressors, pumps, motors, and gearboxes.
Q7: How is it installed?
A: Mounted near the shaft with a controlled gap to ensure precise measurement.
Q8: What maintenance is required?
A: Minimal maintenance; mainly inspection and occasional calibration.
Q9: What is the expected service life?
A: Long-term operation under proper installation and conditions.
Q10: Is it compatible with standard monitoring systems?
A: Yes, it integrates with most industrial monitoring and protection systems.
