Bently Nevada 330104-00-06-10-01-00 Detailed Product Guide (3300 XL 10 mm Series)
1. Basic Product Information
- Model: 330104-00-06-10-01-00
- Brand: Bently Nevada
- Series: 3300 XL 10 mm Proximity Probe Series
- Product Type: Eddy Current Proximity Probe
The 330104-00-06-10-01-00 is a high-precision 10 mm eddy current proximity probe designed for industrial machinery monitoring. It is part of the 3300 XL 10 mm series, which offers a larger probe diameter than the 8 mm series, providing increased robustness and mechanical stability for larger rotating equipment. This model is commonly used in applications where greater probe strength and durability are needed while maintaining accurate shaft displacement and vibration measurement.
2. Technical Specifications
Parameter Table
| Parameter | Specification |
|---|---|
| Probe Diameter | 10 mm |
| Measurement Range | 0 – 10 mm |
| Case Length | 60 mm |
| Cable Length | 0.5 m |
| Connector Type | Miniature coaxial connector |
| Cable Type | Standard industrial cable |
| Probe Tip Material | PPS high-temperature polymer |
| Housing Material | Stainless steel |
| Operating Voltage | 12 – 24 V DC |
| Output Signal | Eddy current analog signal |
| Frequency Response | High-frequency dynamic response |
| Response Time | < 1 ms |
| Operating Temperature | -40°C to +85°C |
| Protection Rating | IP67 |
| Mounting Thread | M10 × 1 |
| Dimensions | Ø10 mm × 60 mm |
| Weight (kg) | 0.190 kg |
3. Product Description
The 330104-00-06-10-01-00 is engineered for precise, non-contact measurement of shaft displacement and vibration. Using eddy current sensing technology, the probe generates a high-frequency electromagnetic field at its tip. When a conductive surface such as a rotor shaft enters this field, eddy currents are induced. These changes in impedance are converted into electrical signals proportional to displacement, allowing accurate real-time monitoring.
This probe’s 10 mm diameter provides enhanced mechanical robustness compared with smaller 8 mm probes, making it suitable for larger shafts or higher-stress installations. The stainless steel housing protects the probe from vibration, impact, and environmental stress. Its compact 60 mm body allows installation in confined spaces while maintaining the integrity of the measurement signal.
4. Applications
The 330104-00-06-10-01-00 is widely used in industrial environments requiring accurate monitoring of critical rotating machinery:
- Steam and gas turbines
- Large compressors and blowers
- Pumping systems in power generation and chemical plants
- Electric motors and generators
- Gearboxes and transmission systems
- Industrial fans and blowers
- Machinery requiring high reliability monitoring
Typical Monitoring Functions
- Radial vibration measurement
- Axial displacement measurement
- Shaft position tracking
- Speed and phase reference detection
- Fault detection (misalignment, imbalance, rubs)
5. Product Advantages
Mechanical Robustness: 10 mm probe diameter ensures increased strength and longevity.
High Precision: Accurate real-time displacement and vibration data for critical machinery monitoring.
Non-contact Measurement: Eliminates mechanical wear, reducing maintenance requirements.
Compact & Flexible Installation: 60 mm case length allows use in tight spaces.
Durable Construction: Stainless steel housing resists corrosion, vibration, and mechanical impact.
Fast Response: Sub-millisecond response for early fault detection.
System Compatibility: Fully compatible with 3300 XL monitoring systems.
6. Recommended Models (Same Series / Related)
Table – 3300 XL 10 mm Series Related Models
| Model | Key Parameters |
|---|---|
| 330104-00-06-10-01-05 | Reinforced cable, 10 mm diameter, same measurement range |
| 330104-00-06-10-02-00 | Extended case length for specialized installations |
| 330104-00-10-10-01-00 | Longer measurement range up to 12 mm, robust design |
| 330104-00-06-10-02-05 | Reinforced cable with extended body for high-vibration applications |
| 330104-00-08-10-01-00 | Alternative 10 mm probe with minor dimensional variations for certain machinery |
7. Popular Models from the Same Brand
Table – Hot-Selling Models
| Model | Key Parameters |
|---|---|
| 330180-50-00 | Proximitor signal conditioner, multi-probe support |
| 330850-90-05 | High-sensitivity proximity sensor, 25 mm range |
| 330101-00-28-10-02-05 | Extended 10 mm probe with long cable |
| 330105-02-12-05-02-05 | Flexible installation proximity probe variant |
| 330171-00-14-10-02-00 | Industrial vibration sensor module, robust design |
8. FAQ (Q&A Format)
Q1: What is the primary function of this probe?
A: To measure shaft displacement and vibration without mechanical contact.
Q2: What is the advantage of the 10 mm probe diameter?
A: Provides increased mechanical strength and stability for larger or higher-stress machinery.
Q3: What is the measurement range?
A: 0–10 mm.
Q4: What environments can it operate in?
A: Industrial environments with dust, oil, vibration, or temperature extremes (IP67).
Q5: What is the response time?
A: Less than 1 millisecond for real-time monitoring.
Q6: Does it require physical contact with the shaft?
A: No, it operates using eddy current technology.
Q7: What is the housing material?
A: Stainless steel for durability and corrosion resistance.
Q8: What types of machinery is it suitable for?
A: Turbines, compressors, pumps, motors, gearboxes, and industrial fans.
Q9: What is the mounting type?
A: M10 × 1 threaded connection.
Q10: Why choose this 10 mm probe over smaller 8 mm probes?
A: For enhanced mechanical robustness, ideal for larger shafts or high-vibration environments.
