Bently Nevada 330103-08-13-10-02-00
Comprehensive Product Overview & Technical Guide (Offline Version)
1. Product Overview
The 330103-08-13-10-02-00 is a high-precision eddy current proximity probe designed for non-contact measurement of vibration, displacement, and shaft position in rotating machinery.
It belongs to the 3300 XL 8 mm series, a widely used family of probes for industrial machinery condition monitoring and protection systems.
The 08-13-10-02 configuration denotes an 8 mm diameter probe, 130 mm case length, and 1.0 m system cable, suitable for medium-depth installations where slightly longer cable routing is required.
This probe is designed for continuous, accurate monitoring, providing reliable data for machine protection, diagnostics, and operational efficiency.
2. Brand
- Brand: Bently Nevada
The brand is recognized globally for industrial machinery monitoring and protection solutions, with proven reliability in harsh environments.
3. Series
- Series: 3300 XL Series (8 mm)
Key features of the series include:
- Modular system design: interchangeable probes, cables, and sensor modules
- High sensitivity and low-noise output
- Durable and resistant to industrial contaminants
- Compatible with standard vibration monitoring systems
4. Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 330103-08-13-10-02-00 |
| Probe Type | Eddy Current Proximity Probe |
| Probe Diameter | 8 mm |
| Unthreaded Length | 80 mm |
| Case Length | 130 mm |
| System Length | 1.0 m |
| Sensitivity | 7.87 V/mm (typical) |
| Output Type | Analog voltage |
| Frequency Response | 0 – 10 kHz |
| Operating Voltage | -24 V DC (system powered) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -50°C to +100°C |
| Probe Material | Stainless steel |
| Tip Material | PPS (high-performance polymer) |
| Cable Type | Coaxial cable |
| Connector Type | ClickLoc |
| Protection Level | IP67 |
| Dimensions (mm) | approx. 130 × 20 × 30 |
| Weight (kg) | approx. 0.33 kg |
5. Product Description
The 330103-08-13-10-02-00 probe provides continuous, non-contact monitoring of shaft vibration and displacement.
It uses eddy current technology: the probe generates an electromagnetic field at the tip, and variations caused by nearby conductive targets (shafts) are converted into voltage signals.
The 1.0 m system cable allows installation flexibility, making it suitable for medium-depth mounting and moderate cable routing in machinery cabinets.
The probe is designed to withstand harsh industrial environments including oil, dust, and high vibration, ensuring reliable long-term operation.
6. Applications
This probe is commonly used in:
- Steam turbines
- Gas turbines
- Compressors
- Industrial pumps
- Electric motors
- Gearboxes
Functions include:
- Radial shaft vibration measurement
- Axial displacement detection
- Shaft position monitoring
- Speed reference (Keyphasor output)
7. Product Advantages
High Accuracy
Delivers precise and repeatable measurements under industrial conditions.
Non-contact Measurement
Eliminates wear and extends component lifespan.
Moderate Case Length
Supports medium-depth mounting without complex installation.
Flexible System Cable
1.0 m cable length provides moderate routing flexibility.
Durable Industrial Design
Reliable in environments with oil, dust, or vibration.
8. Recommended Models (Same Series / Related)**
| Model | Probe Diameter | Cable Length | Case Length | Temp Range | Weight (kg) |
|---|---|---|---|---|---|
| 330103-08-13-05-02-00 | 8 mm | 0.5 m | 130 mm | -40~85°C | 0.32 |
| 330103-07-16-05-02-00 | 8 mm | 0.5 m | 160 mm | -40~85°C | 0.34 |
| 330103-07-14-05-01-00 | 8 mm | 0.5 m | 140 mm | -40~85°C | 0.32 |
| 330103-08-18-10-02-00 | 8 mm | 1 m | 180 mm | -40~85°C | 0.36 |
| 330103-07-12-10-02-00 | 8 mm | 1 m | 120 mm | -40~85°C | 0.28 |
9. Recommended Popular Models (Same Brand)**
| Model | Product Type | Series | Voltage | Output | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 3300 XL Proximitor Sensor | Proximitor | 3300 XL | 24 V DC | Analog | 120 × 50 × 30 | 0.50 |
| 330180-91-00 | Proximitor | 3300 XL | 24 V DC | Analog | 120 × 50 × 30 | 0.48 |
| 330101-00-28-10-02-05 | Probe | 3300 XL | -24 V DC | Analog | 150 × 20 × 30 | 0.28 |
| 330100-50-05 | Proximitor | 3300 Series | 24 V DC | Analog | 120 × 50 × 30 | 0.45 |
| 3300/65 Monitor | Monitor Module | 3300 | 24 V DC | Analog | 160 × 80 × 40 | 0.70 |
10. FAQ (10 Q&A)
Q1: What does this probe measure?
A: Shaft vibration and displacement without physical contact.
Q2: What does the “08-13-10-02” signify?
A: 8 mm probe diameter, 130 mm case length, 1.0 m system cable, configuration type 2.
Q3: Can it operate in oil or dust environments?
A: Yes, designed for harsh industrial conditions.
Q4: What is the typical installation gap?
A: Approximately 1–2 mm between probe tip and shaft surface.
Q5: Is calibration required?
A: Yes, correct gap adjustment is necessary during installation.
Q6: What materials can it detect?
A: Conductive materials such as steel shafts.
Q7: How is the signal transmitted?
A: Through a coaxial cable to a proximitor interface.
Q8: Is it resistant to electromagnetic interference?
A: Yes, shielding ensures stable signal output.
Q9: Which industries use this probe?
A: Power generation, oil & gas, chemical, and heavy industry.
Q10: What are common installation mistakes?
A: Misalignment, incorrect gap, or using incompatible sensor or cable components.
