Product Overview
The Bently Nevada 21000-28-05-20-038-04-02 is a Proximity Probe Housing Assembly designed for the 3300 XL Proximity Transducer System. It provides a robust, precise, and durable mounting solution for proximity probes, ensuring accurate monitoring of rotating machinery vibration, shaft displacement, and rotor position.
This assembly is widely used in power generation, petrochemical, oil & gas, and heavy industrial applications where reliable machinery protection and condition monitoring are critical.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 21000-28-05-20-038-04-02 |
| Product Type | Proximity Probe Housing Assembly |
| Compatible System | 3300 XL Proximity Transducer System |
| Housing Body Diameter | 83.3 mm |
| Weight | 1.1 kg |
| Mounting Type | External machine or bearing housing installation |
| Housing Material | Industrial-grade metal alloy |
| Probe Compatibility | 3300 XL proximity probes |
| Cable Entry Type | Threaded conduit connection |
| Measurement Functions | Shaft vibration, shaft displacement, rotor position |
| Application Category | Machinery protection and condition monitoring |
| Environmental Suitability | Industrial operating environments |
Function and Working Principle
The housing assembly serves as a protective enclosure and precision alignment platform for proximity probes.
Working Principle
- Install a 3300 XL proximity probe inside the housing.
- Position the probe near the rotating shaft without physical contact.
- Shaft vibration, displacement, and rotor position changes are detected by the probe.
- Signals are transmitted to monitoring and protection systems.
- The housing ensures stable alignment and protection from mechanical and environmental stress.
This setup ensures continuous and accurate condition monitoring of rotating machinery.
Role in Condition Monitoring Systems
- Provides secure and stable probe installation
- Maintains precise alignment for accurate measurements
- Protects probes and cabling from dust, moisture, and mechanical impacts
- Supports continuous monitoring of vibration and shaft displacement
- Enhances the reliability of machinery protection systems
- Reduces maintenance and recalibration requirements
Industrial Applications
- Steam turbines
- Gas turbines
- Hydroelectric turbines
- Centrifugal compressors
- Industrial pumps
- Electric motors
- Gearboxes
- Power generation plants
- Oil and gas processing facilities
- Petrochemical plants
Installation Guidelines
- Mount securely on machine casing or bearing housing
- Maintain proper probe-to-shaft clearance
- Route cables through threaded conduit connections
- Verify probe alignment before commissioning
- Confirm stable signal output in the monitoring system
- Follow standard industrial installation procedures
Correct installation ensures long-term reliability and measurement accuracy.
Compatible Components
- 3300 XL proximity probes
- Proximitor sensor systems
- Extension cables and connectors
- Machinery protection systems
- Turbine supervisory instrumentation (TSI) systems
- Industrial vibration monitoring platforms
Alternative Models
| Model | Description |
|---|---|
| 21000-28-05-20-038-04-02 | Standard 3300 XL probe housing assembly (this model) |
| 21000 Series Variants | Different mounting and configuration options |
| 24701 Series | Stainless steel housing assemblies |
| Compact Housing Assemblies | For space-constrained installations |
| Heavy-Duty Housing Assemblies | Designed for harsh industrial environments |
Key Advantages
- Rugged industrial-grade construction
- Accurate and stable probe positioning
- Protection against environmental and mechanical damage
- Supports precise vibration and displacement measurements
- Reduces maintenance and alignment efforts
- Fully compatible with 3300 XL systems
- Long operational service life
Technical FAQs
What is the purpose of this housing assembly?
It provides secure mounting, precise alignment, and protection for 3300 XL proximity probes.
Does the housing measure vibration itself?
No, the installed proximity probe performs all measurements; the housing ensures accurate positioning.
Which equipment commonly uses this assembly?
Turbines, compressors, pumps, motors, and other critical rotating machinery.
Why is probe alignment important?
Proper alignment ensures reliable vibration, displacement, and rotor position measurements.
Is this housing suitable for harsh industrial environments?
Yes, it is engineered for continuous operation in demanding industrial conditions.
Conclusion
The Bently Nevada 21000-28-05-20-038-04-02 Proximity Probe Housing Assembly is a durable, precision-engineered solution for mounting 3300 XL proximity probes. Its robust design and precise alignment capabilities make it essential for effective machinery protection and condition monitoring applications.
