Product Overview
The Allen Bradley 1791D-8B8P is a CompactBlock I/O Combination Dock designed for integrated digital input and output control in distributed automation systems. With dimensions of 150 × 38 × 48 mm and a weight of 0.18 kg, this module offers a compact, lightweight, and versatile solution for applications requiring both input monitoring and output control. It is fully compatible with Allen Bradley CompactBlock I/O racks, providing a modular and scalable platform for industrial automation.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen Bradley |
| Model | 1791D-8B8P |
| Product Type | CompactBlock I/O Combination Dock |
| Dimensions | 150 × 38 × 48 mm |
| Weight | 0.18 kg |
| Module Type | Digital Input/Output Combination |
| Number of Channels | 8 input / 8 output channels |
| Input/Output Type | Sinking or sourcing (configurable) |
| Mounting | CompactBlock I/O rack |
| Environmental Rating | Industrial-grade, suitable for harsh conditions |
| Compatibility | Allen Bradley CompactBlock I/O racks and controllers |
Function and Working Principle
The 1791D-8B8P operates by:
- Receiving digital input signals from sensors, switches, or other field devices
- Transmitting input status to a PLC or controller
- Activating output devices such as actuators, relays, or indicators
- Providing 8 discrete input channels and 8 output channels for combined monitoring and control
- Integrating into CompactBlock I/O systems for flexible, modular expansion
This module functions as a versatile interface between control systems and field devices, allowing simultaneous input acquisition and output control in a compact form factor.
Role in Industrial Automation
The 1791D-8B8P is used to:
- Monitor field device inputs and control outputs in one module
- Expand both input and output capacity in CompactBlock I/O networks
- Support modular and scalable system architectures
- Provide reliable combined input/output operation in industrial environments
Industrial Applications
- Factory and process automation
- Distributed I/O systems with mixed input/output needs
- Remote monitoring and control of industrial devices
- Integration into modular CompactBlock I/O networks
Installation and Usage
- Mount the 1791D-8B8P in a CompactBlock I/O rack
- Connect input wiring from sensors or field devices and output wiring to relays or actuators
- Configure the module through PLC or controller software
- Test all input and output channels for proper operation
- Ensure stable power supply and environmental conditions
Its compact and modular design allows easy installation, maintenance, and system expansion.
Compatible System Components
- Allen Bradley CompactBlock I/O racks
- Allen Bradley PLCs and controllers
- Field devices such as sensors, actuators, relays, and indicators
- Other CompactBlock I/O modules
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| 1791D-8B8P | CompactBlock I/O Combination Dock | 8 input + 8 output channels | Mixed I/O applications |
| 1791D-0B16P | CompactBlock I/O Output Module | 16 output channels | Output control only |
| 1791D-16B0 | CompactBlock I/O Input Module | 16 input channels | Input monitoring only |
Key Advantages
- 8 input and 8 output channels for versatile control and monitoring
- Compact 150 × 38 × 48 mm design
- Lightweight module at 0.18 kg
- Industrial-grade durability for harsh environments
- Modular design allows flexible system expansion
Technical FAQs
What is the primary function?
To acquire 8 digital input signals and control 8 digital outputs for field devices in automation systems.
Which systems is it compatible with?
Compatible with Allen Bradley CompactBlock I/O racks and PLC controllers.
Can it operate in harsh industrial environments?
Yes, it is industrial-grade, suitable for vibration, dust, and temperature extremes.
How many channels does it provide?
It provides 8 digital input channels and 8 digital output channels.
Conclusion
The Allen Bradley 1791D-8B8P CompactBlock I/O Combination Dock is a compact, versatile, and reliable solution for digital input and output control in distributed automation systems. Its 8+8 channel capacity, modular design, and industrial-grade construction make it ideal for scalable, flexible, and dependable industrial control networks.
