Product Overview
The Allen Bradley 1790-T8BV8BX is a CompactBlock LDX I/O Extension Block designed to expand the digital input/output (I/O) capabilities of existing CompactBlock LDX systems. With compact dimensions of 104 × 42 × 52 mm and a lightweight 0.1 kg profile, it is perfect for space-constrained installations. This extension block provides modular I/O expansion, enabling additional channels for enhanced system scalability and flexibility.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen Bradley |
| Model | 1790-T8BV8BX |
| Product Type | CompactBlock LDX I/O Extension Block |
| Dimensions | 104 × 42 × 52 mm |
| Weight | 0.1 kg |
| Module Type | Digital I/O Extension |
| Channel Configuration | Typically 8 digital inputs + 8 digital outputs |
| Mounting | DIN-rail or modular rack installation |
| Environmental Rating | Industrial-grade, suitable for harsh conditions |
| Compatibility | CompactBlock LDX I/O system components |
Function and Working Principle
The 1790-T8BV8BX functions by:
- Providing additional digital I/O channels to an existing LDX I/O module
- Receiving input signals from sensors and transmitting output commands to actuators
- Integrating seamlessly with LDX controllers and primary I/O modules
- Enabling modular expansion without significantly increasing system footprint
This module acts as a reliable digital I/O extension, ensuring efficient signal processing and system scalability.
Role in Industrial Automation
The module is used to:
- Increase digital I/O points in CompactBlock LDX automation systems
- Interface with additional field devices, such as sensors, switches, and actuators
- Enable flexible modular system design for evolving automation requirements
- Maintain reliable signal communication and control in industrial environments
Industrial Applications
- Factory and process automation requiring extra digital I/O channels
- Expansion of existing LDX digital I/O systems
- Monitoring and control of additional actuators and sensors
- Compact, modular automation networks
Installation and Usage
- Mount the 1790-T8BV8BX on a DIN rail or within a modular rack
- Connect the module to the primary LDX I/O module
- Attach additional digital input and output devices to the extension terminals
- Configure I/O addresses and parameters via LDX controller software
- Test and verify the operation of all additional channels
Its compact and lightweight design allows efficient modular expansion while preserving system integrity.
Compatible System Components
- CompactBlock LDX controllers
- Primary CompactBlock LDX I/O modules
- Field devices such as sensors, actuators, and switches
- DIN-rail or modular automation racks
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| 1790-T8BV8BX | LDX I/O Extension Block | 8-in / 8-out digital channels | Modular I/O expansion |
| 1790-T16BV0X | LDX I/O Extension Block | 16 additional digital channels | Larger-scale digital I/O expansion |
| 1790-T0B16X | LDX I/O Extension Block | 16-channel expansion | Standard LDX system extension |
Key Advantages
- Compact 104 × 42 × 52 mm form factor
- Lightweight 0.1 kg module
- Provides 16 digital I/O channels (8 inputs + 8 outputs)
- Modular design for scalable system expansion
- Industrial-grade durability for harsh environments
Technical FAQs
What is the primary function?
To expand the number of digital input/output channels in a CompactBlock LDX automation system.
Which systems is it compatible with?
Compatible with CompactBlock LDX controllers and primary LDX I/O modules.
Can it operate in harsh industrial environments?
Yes, it is industrial-grade, suitable for vibration, dust, and temperature extremes.
Is it suitable for space-constrained installations?
Yes, its compact and lightweight design allows easy integration in tight modular racks.
Conclusion
The Allen Bradley 1790-T8BV8BX CompactBlock LDX I/O Extension Block is a reliable, compact, and industrial-grade solution for expanding digital I/O channels in existing LDX systems. Its modular design, 16-channel capacity, and lightweight profile make it ideal for scalable, flexible, and space-efficient automation networks.
