Product Overview
The Allen Bradley 1790-T16BV0X is a CompactBlock LDX I/O Extension Block designed to expand the digital I/O capacity of existing CompactBlock LDX systems. Its compact dimensions of 104 × 42 × 52 mm and lightweight 0.1 kg design make it ideal for space-constrained automation setups. This module allows efficient and modular expansion, enabling additional digital input and output channels without replacing the primary I/O module.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Allen Bradley |
| Model | 1790-T16BV0X |
| Product Type | CompactBlock LDX I/O Extension Block |
| Dimensions | 104 × 42 × 52 mm |
| Weight | 0.1 kg |
| Module Type | Digital I/O Extension |
| Channel Configuration | Typically 16 additional digital channels |
| Mounting | DIN-rail or modular rack installation |
| Environmental Rating | Industrial-grade, suitable for harsh environments |
| Compatibility | CompactBlock LDX I/O system components |
Function and Working Principle
The 1790-T16BV0X operates by:
- Providing additional digital input and output channels to an existing LDX I/O module
- Receiving signals from field devices and transmitting them to the LDX controller
- Expanding modular I/O systems without increasing rack footprint significantly
- Ensuring seamless communication with the primary LDX I/O module
This module functions as a reliable extension block to increase I/O channel availability in CompactBlock LDX networks.
Role in Industrial Automation
The module is primarily used to:
- Increase the number of digital I/O points in CompactBlock LDX systems
- Interface with additional field devices, such as switches, sensors, and actuators
- Provide flexible modular expansion for evolving automation needs
- Ensure reliable and continuous signal communication in industrial networks
Industrial Applications
- Factory and process automation requiring extra digital I/O channels
- Expansion of existing LDX digital I/O systems
- Control and monitoring of additional sensors and actuators
- Compact and modular industrial automation designs
Installation and Usage
- Mount the 1790-T16BV0X on a DIN rail or in a modular rack
- Connect the extension block to the primary LDX I/O module
- Attach additional digital input and output devices to the module terminals
- Configure I/O addresses and parameters via the LDX controller software
- Verify the operation of all newly added channels
Its compact and lightweight form factor allows efficient expansion while maintaining modular system integrity.
Compatible System Components
- CompactBlock LDX controllers
- Primary CompactBlock LDX I/O modules
- Field devices such as sensors, actuators, and switches
- DIN-rail or modular automation racks
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| 1790-T16BV0X | LDX I/O Extension Block | 16 additional digital channels | Modular I/O expansion |
| 1790-T0B16X | LDX I/O Extension Block | 16-channel expansion | Standard extension for LDX systems |
| 1790D-T32BV0 | DeviceNet Universal Input Module | 32 universal input channels | Large-scale I/O networks |
Key Advantages
- Compact 104 × 42 × 52 mm size
- Lightweight 0.1 kg module
- Provides 16 additional digital I/O channels
- Modular design for seamless expansion
- Industrial-grade reliability
Technical FAQs
What is the primary function?
To expand digital input/output capacity in CompactBlock LDX automation systems.
Which systems is it compatible with?
Compatible with CompactBlock LDX controllers and primary LDX I/O modules.
Can it operate in harsh industrial environments?
Yes, it is industrial-grade, suitable for dust, vibration, and temperature variations.
Is it suitable for space-constrained installations?
Yes, its compact and lightweight design allows easy integration in tight racks.
Conclusion
The Allen Bradley 1790-T16BV0X CompactBlock LDX I/O Extension Block is a compact, reliable, and industrial-grade solution for adding digital I/O channels to existing LDX automation systems. Its modular design, 16-channel expansion, and lightweight form factor make it ideal for scalable, flexible, and space-efficient automation networks.
