- ABB
- 5SHY3545L0016 3BHB020720R0002
- IGCT Module
- Sweden (SE)
- 290 × 100 × 40 mm
- 1.5 kg
- Xiamen, China
- New & In Stock
- T/T, PayPal, Western Union
- 1 Year
- 1-3 Working Days
- DHL, UPS, TNT, FedEx and EMS.
- 24-Hour Service
- COO
- 0
Our advantage
Global Logistics
We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.
Brand new and original
Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.
24-hour service
We provide 7*24 hours service to our customers. We will be there whenever you need us.
Price advantage
All our products are priced very favorably because we have our own warehouse and supply.
| Company Information | |||
| [email protected] | |||
| Mobile | +8615980777398 | ||
| +8615980777398 | |||
| 15980777398 |
Introduction
The ABB Ltd. 5SHY3545L0016 (3BHB020720R0002) IGCT Module is a high-power semiconductor switching device based on Integrated Gate-Commutated Thyristor (IGCT) technology. It combines the high current-handling capability of traditional thyristors with the fast switching performance of modern power semiconductors.
This module is ideal for medium-voltage drives, industrial power converters, and energy systems where efficient, reliable, and high-speed switching is required. Its dimensions are 290 × 100 × 40 mm (H x W x D) and it weighs 1.5 kg, making it suitable for integration into industrial power electronics cabinets.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 5SHY3545L0016 |
| Ordering Number | 3BHB020720R0002 |
| Product Type | IGCT Power Semiconductor Module |
| Manufacturer | ABB |
| Dimensions | 290 × 100 × 40 mm (H x W x D) |
| Weight | 1.5 kg |
| Rated Voltage | Up to 4500 V |
| Rated Current | Up to 3500–4000 A |
| Device Technology | Integrated Gate-Commutated Thyristor (IGCT) |
| Switching Speed | Fast turn-on and turn-off times |
| Cooling Method | Heat-sink or forced cooling |
| Mounting | Industrial power converter or drive cabinet |
The module is designed for high-efficiency switching, low conduction losses, and robust performance in demanding industrial power applications.
Applications
The 5SHY3545L0016 IGCT Module is commonly used in:
-
Medium-voltage motor drive systems
-
Industrial power converters and inverters
-
High-voltage direct current (HVDC) transmission systems
-
Static VAR compensators (SVC) and grid stabilization equipment
-
Heavy industrial machinery and large motor control systems
These applications demand high reliability, efficient switching, and precise control of large electrical loads.
Advantages
-
High voltage and current handling capability
-
Fast switching performance with low energy losses
-
Robust press-pack semiconductor design for industrial environments
-
Precise gate-controlled operation
-
Suitable for large-scale industrial power conversion and drive applications
Technical FAQs
Q1: What is the primary function of the 5SHY3545L0016 module?
It serves as a high-power semiconductor switch for controlling and converting electrical energy in industrial drives and converters.
Q2: What technology does this module use?
It uses IGCT (Integrated Gate-Commutated Thyristor) technology for fast, reliable switching of high currents.
Q3: Where is this module typically installed?
It is installed in medium-voltage drive cabinets, power converter systems, or industrial power electronics assemblies.
Q4: Which industries commonly use this module?
Power generation, heavy industry, mining, oil and gas, and industrial automation requiring high-power motor and drive control.
Q5: Why are IGCT modules preferred in industrial power systems?
They provide efficient switching, high current capacity, and reliable performance for controlling large electrical loads.
