Yokogawa ANR11D-420 S1 Fiber Optic ESB Bus Node Unit
Product Description
The Yokogawa ANR11D-420 S1 is a Fiber Optic ESB (Ethernet-based Serial Bus) Node Unit designed to integrate industrial field devices with advanced monitoring and control systems. The ANR11D-420 S1 is part of Yokogawa’s cutting-edge range of communication modules, ensuring stable and reliable data transmission over fiber optic networks. This node unit acts as an interface between field devices and the central control system, providing robust data exchange and allowing for real-time monitoring of critical process parameters.
Compact in design (130 x 100 x 40 mm and weighing 0.4 kg), the ANR11D-420 S1 is easily mountable and integrates smoothly into existing systems. Its fiber optic communication capabilities make it highly resistant to electrical interference, ensuring reliable performance in harsh industrial environments such as power plants, oil refineries, and chemical processing plants.
Product Specifications
| Specification | Details |
|---|---|
| Dimensions | 130 x 100 x 40 mm |
| Weight | 0.4 kg |
| Communication Protocol | ESB (Ethernet-based Serial Bus) |
| Communication Type | Fiber Optic |
| Power Supply | 24 VDC ± 20% |
| Operating Temperature | -20°C to +60°C |
| Mounting Type | DIN rail or panel mountable |
| Connector Type | Fiber Optic (LC Connector) |
| Environmental Rating | IP20 |
| Compliance | CE, UL certified |
Product Applications
The Yokogawa ANR11D-420 S1 Fiber Optic ESB Node Unit is used in a variety of industrial applications that require secure, high-speed communication across distances. Some common applications include:
-
Process Control Systems: It facilitates communication between field devices (such as sensors and actuators) and the central control system, ensuring seamless data flow in real-time.
-
Energy and Power Systems: Used in power plants for monitoring and control of critical equipment, ensuring reliable data transfer between distributed devices and centralized control systems.
-
Chemical and Pharmaceutical Manufacturing: Provides reliable communication for controlling and monitoring the processes within the production line, including temperature, pressure, and flow control systems.
-
Automation Systems: Connects various pieces of equipment within an automated facility, enabling centralized control and remote monitoring capabilities.
-
Oil & Gas Industry: Facilitates the communication and control of field devices in oil rigs, refineries, and pipelines, ensuring real-time data availability and improving operational efficiency.
Product Advantages
-
Fiber Optic Communication: The ANR11D-420 S1 utilizes fiber optic technology, which provides high-speed data transmission while eliminating concerns about electromagnetic interference, making it ideal for challenging industrial environments.
-
Compact and Lightweight Design: With dimensions of 130 x 100 x 40 mm and weighing just 0.4 kg, this unit can be easily integrated into tight spaces and mounted on DIN rails or panels, making installation quick and easy.
-
Wide Temperature Range: The unit operates effectively in temperatures ranging from -20°C to +60°C, making it suitable for a wide range of industrial applications, even in extreme environmental conditions.
-
Reliable Data Transmission: Supports Ethernet-based serial bus communication, ensuring high reliability and minimal downtime in mission-critical systems.
-
Durable and Robust: Built to withstand industrial conditions, the ANR11D-420 S1 ensures long-lasting performance even in environments exposed to vibration, moisture, and other harsh conditions.
-
Easy Integration with Existing Systems: This unit is compatible with a wide range of Yokogawa products, ensuring seamless integration with existing industrial control systems and automation setups.
Brand Information
Yokogawa is a leading provider of industrial automation, control, and measurement solutions, known for delivering high-quality products designed to improve the safety, efficiency, and reliability of industrial processes. With a legacy of innovation spanning over 100 years, Yokogawa’s products are trusted by industries worldwide, including energy, chemicals, pharmaceuticals, and manufacturing. The ANR11D-420 S1 Fiber Optic ESB Node Unit is part of Yokogawa’s broader range of solutions designed to enable efficient, real-time communication between industrial equipment and control systems, enhancing overall process performance.
Recommended Related Models from the ANR Series
| Model | Description | Specifications |
|---|---|---|
| ANR11D-430 S1 | Advanced fiber optic ESB node unit with extended functionality | 130 × 100 × 40 mm; 0.45 kg; Modbus RTU |
| ANR11D-440 S1 | High-speed fiber optic communication module | 130 × 100 × 40 mm; 0.45 kg; EtherNet/IP |
| ANR12D-420 S1 | Compact fiber optic communication node for small systems | 125 × 100 × 35 mm; 0.3 kg; Modbus RTU |
| ANR13D-410 S1 | Fiber optic communication module with multiple I/O support | 130 × 100 × 45 mm; 0.5 kg; Modbus RTU |
| ANR14D-420 S1 | Extended range fiber optic ESB node unit | 135 × 105 × 50 mm; 0.6 kg; Modbus RTU |
Recommended Popular Models from Yokogawa
| Model | Description | Dimensions (mm) | Weight (kg) | Key Features |
|---|---|---|---|---|
| AMN32-S1 | Yokogawa multi-function communication module | 130 × 125.5 × 32.8 | 0.3 | Serial/Ethernet communication, modular design |
| ADV161-P50 | High-precision pressure transmitter | 160 × 130 × 60 | 1.5 | High accuracy, robust, explosion proof |
| PW301-S3 | Power supply unit for process control systems | 125 × 120 × 50 | 0.8 | Stable power output, wide voltage range |
| ALR121-SE1 | Serial communication module | 126.7 × 32.8 × 130 | 0.3 | Supports RS-485, easy installation |
| AMM42T | RTD input multiplexing module | 125 × 130 × 248 | 2.0 | Multiple RTD inputs, robust for harsh environments |
FAQ (Frequently Asked Questions)
-
Q: What is the primary function of the Yokogawa ANR11D-420 S1?
A: It is a fiber optic ESB node unit that facilitates reliable communication between field devices and central control systems using Ethernet-based serial bus communication. -
Q: What are the input and output protocols supported by the ANR11D-420 S1?
A: The module supports Modbus RTU communication. -
Q: How many devices can the ANR11D-420 S1 connect to?
A: It is designed to connect to multiple devices via fiber optic communication, depending on the configuration of the system. -
Q: What is the operating temperature range of the ANR11D-420 S1?
A: The module operates in temperatures ranging from -20°C to +60°C. -
Q: What is the communication speed of the ANR11D-420 S1?
A: The module supports high-speed communication over fiber optic networks, ensuring reliable and fast data transmission. -
Q: Can the ANR11D-420 S1 be mounted on DIN rails?
A: Yes, the module can be mounted on DIN rails or directly on panels. -
Q: What is the power supply requirement for the ANR11D-420 S1?
A: The module operates on a 24 VDC power supply with a ±20% tolerance. -
Q: Is the ANR11D-420 S1 suitable for use in hazardous environments?
A: While the ANR11D-420 S1 is built for industrial environments, it is recommended to verify suitability for specific hazardous environments and requirements. -
Q: What is the environmental rating of the ANR11D-420 S1?
A: The module is rated for indoor use with an IP20 environmental rating. -
Q: Can the ANR11D-420 S1 be integrated with other Yokogawa systems?
A: Yes, it is designed to integrate seamlessly with other Yokogawa products and systems for enhanced automation and monitoring.
