Yokogawa AFS30S Product Overview

Product Introduction

The Yokogawa AFS30S is a sophisticated function generator designed for precise signal generation in a wide array of electronic testing applications. With a frequency range from 1 Hz to 30 MHz, this device delivers high-performance functionality in a compact and user-friendly package. It is part of the AFS Series, which is known for providing reliable and accurate waveforms for professionals across various industries, including telecommunications, electronics, automotive, and education.

The AFS30S is equipped with a range of signal types, including sine, square, triangle, and pulse waveforms, along with the ability to generate modulated signals such as AM (Amplitude Modulation), FM (Frequency Modulation), and PM (Phase Modulation). It is also capable of generating arbitrary waveforms to simulate complex real-world signals, making it versatile for both research & development (R&D) and test & measurement tasks.

This function generator features high signal accuracy, low distortion, and easy integration into existing testing setups. It can also be controlled remotely through USB and LAN interfaces, facilitating automated testing or integration into larger testing systems.

Product Parameters

Product Applications

The Yokogawa AFS30S is designed for a wide variety of professional applications, making it a valuable tool in different industries:

1. Telecommunications: It can generate modulated signals (AM, FM, PM) to test and calibrate communication devices such as radios, transmitters, and receivers.

2. R&D and Electronics: In research and development, the AFS30S can simulate complex signals to test and validate components such as semiconductors, circuits, and components in electronic devices.

3. Audio Testing: With its ability to produce sine and square waves, the AFS30S is ideal for audio testing, ensuring equipment such as amplifiers, mixers, and sound processors meet quality standards.

4. Automotive: It is used in the automotive industry to simulate various signals for testing automotive electronics, including ECUs (Engine Control Units), sensors, and power systems.

5. Education: The AFS30S is also widely used in educational settings to teach electronic principles, signal generation, and waveform analysis, making it a valuable tool for students and engineers.

Product Advantages

1. High Frequency Range: The AFS30S covers a wide frequency range from 1 Hz to 30 MHz, making it suitable for both low-frequency and high-frequency applications.

2. Multiple Waveforms: The generator supports several waveform types, including sine, square, triangle, pulse, and arbitrary waveforms. It offers maximum flexibility for various testing needs.

3. Modulation Capabilities: It can generate AM, FM, and PM modulated signals, making it an excellent choice for testing communication equipment and audio systems.

4. Precise Signal Generation: The AFS30S delivers high accuracy, with a specification of ±1%, ensuring that the output signals meet precise testing requirements.

5. Compact Design: The compact and lightweight design (weighing just 2.6 kg) makes it easy to transport and integrate into both small labs and portable test environments.

6. Remote Control: The USB and LAN interfaces allow for remote control, facilitating automated testing or integration into larger test setups.

7. Low Distortion: The AFS30S is engineered for low distortion, providing clean and accurate signals even at higher frequencies.

8. User-Friendly Interface: The 4.3-inch TFT-LCD provides easy access to settings, and the intuitive menu system ensures smooth operation even for less experienced users.

9. Durability: The device is built to last with an IP20 protection rating, meaning it is resistant to dust and can withstand indoor environments.

10. Cost-Effective: Given its robust performance and wide range of features, the AFS30S offers excellent value for professionals needing high-quality signal generation without breaking the bank.

Brand and Series

• Brand: Yokogawa

• Series: AFS Series (Function Generators)

The AFS Series from Yokogawa is designed to deliver high-performance and versatility for signal generation in testing environments. Whether you are working in telecommunications, R&D, electronics testing, or audio systems, the AFS Series provides engineers with the tools they need to simulate, generate, and test complex waveforms across a wide frequency range.
